Associated Numbers
10932N
1553164012
1553164013
1553164015
1553164016
1553164017
5KB10
695506014
AKA971
AL14K1
10930
695515020
8970489700
8970489701
8970489702
90371000
tlantic Quality Parts 19000507
Kubota 1553164013, 1553164016, 1553164017, 6C04059250, 6C04059252, EG67364010, KEARA15531
Lester 10932, 10935
Onan 01855431
PIC Picture ID 299144, 299146
Stens 435264
Wilson 703710935
APM0012
J&N 40058002
dxa4042 anj262 658724
Specifications
| Amp | 17 A |
| Bottom Mounting Foot Width (B) | 16 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | M8x1.25 mm |
| Length (L.1) | 79 mm |
| OEM Product | No |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Pulley Outside Diameter (O.D.1) | 36.5 mm |
| Pulley to Mount Distance (A) | 64.5 mm |
| Pulley Type | SOLID |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KUBOTA | B1550D | 17HP Diesel | 1988 - 1996 |
| KUBOTA | B1550E | 17HP Diesel | 1988 - 1996 |
| KUBOTA | B1700DT | 17HP Diesel | 1995 - 1998 |
| KUBOTA | B1700E | 17HP Diesel | 1995 - 1998 |
| KUBOTA | B1700HSD | 17HP Diesel | 1995 - 1998 |
| KUBOTA | B1700HSDB | 17HP Diesel | 1995 - 1998 |
| KUBOTA | B20 | 20HP Diesel | 1990 - 1998 |
| KUBOTA | B20TL | 20HP Diesel | 1990 - 1998 |
| KUBOTA | B2100DT | 21HP Diesel | 1995 - 1998 |
| KUBOTA | B2100HSD | 21HP Diesel | 1995 - 1998 |
| KUBOTA | B2100HSDB | 21HP Diesel | 1995 - 1998 |
| KUBOTA | B2400HST-DB | 24HP Diesel | 1995 - 1998 |
| KUBOTA | B2400HST-E | 24HP Diesel | 1995 - 1998 |
| KUBOTA | B2410HSDB | 24HP Diesel | 1995 - 1998 |
| KUBOTA | B2410HSE | 24HP Diesel | 1995 - 1998 |
| KUBOTA | B2630HSD | 26HP Diesel | 2009 |
| KUBOTA | B2710HSD | 27HP Diesel | 1996 |
| KUBOTA | B2910HSD | 30HP Diesel | 1996 |
| KUBOTA | B3030HSD | Diesel | 2009 |
| KUBOTA | B3030HSDC | Diesel | 2009 |
| KUBOTA | B5200DT | 13HP Diesel | 1983 - 1996 |
| KUBOTA | B5200E | 13HP Diesel | 1983 - 1995 |
| KUBOTA | B6200DT | 15HP Diesel | 1983 - 1994 |
| KUBOTA | B6200E | 15HP Diesel | 1983 - 1994 |
| KUBOTA | B6200HSD | 15HP Diesel | 1983 - 1994 |
| KUBOTA | B6200HSDT | 15HP Diesel | 1983 - 1994 |
| KUBOTA | B6200HSE | 15HP Diesel | 1983 - 1994 |
| KUBOTA | B6200HST | 15HP Diesel | 1983 - 1994 |
| KUBOTA | B6200T | 15HP Diesel | 1983 - 1994 |
| KUBOTA | B7300HSD | 16HP Diesel | 1997 - 1998 |
| KUBOTA | B7400HSD | 16HP Diesel | 1997 - 1998 |
| KUBOTA | B7410DT-F | 18HP Diesel | 2005 |
| KUBOTA | B7410DT-R | 18HP Diesel | 2005 |
| KUBOTA | B7500DT | 21HP Diesel | 1996 |
| KUBOTA | B7800HSD-F | 30HP Diesel | 2003 - 2009 |
| KUBOTA | B7800HSD-R | 30HP Diesel | 2003 - 2009 |
| KUBOTA | B8200DT | 19HP Diesel | 1981 - 1990 |
| KUBOTA | B8200E | 19HP Diesel | 1981 - 1990 |
| KUBOTA | B8200HSD | 19HP Diesel | 1983 - 1990 |
| KUBOTA | B8200HSE | 19HP Diesel | 1983 - 1990 |
| KUBOTA | B8200HST | 19HP Diesel | 1983 - 1990 |
| KUBOTA | B9200DT | 22HP V12 Diesel | 1987 - 1990 |
| KUBOTA | B9200E | 22HP V12 Diesel | 1987 - 1990 |
| KUBOTA | B9200HSD | 22HP V12 Diesel | 1987 - 1990 |
| KUBOTA | B9200HSE | 22HP V12 Diesel | 1987 - 1990 |
| KUBOTA | BX1500D | Z602E | 2003 |
| KUBOTA | BX1800D | 18HP Diesel | 2001 - 2003 |
| KUBOTA | BX1830D | 18HP Diesel | 2004 - 2006 |
| KUBOTA | BX22 | 22HP Diesel | 2002 - 2003 |
| KUBOTA | BX2200D | 22HP Diesel | 2001 - 2003 |
| KUBOTA | BX2230D | 22HP Diesel | 2004 - 2006 |
| KUBOTA | BX23LB | 22HP Diesel | 2004 - 2005 |
| KUBOTA | F2000 | 20HP Diesel | 1986 - 1994 |
| KUBOTA | F2100E | 21HP Diesel | 1989 - 1995 |
| KUBOTA | G1800 | 16HP Diesel | 1989 - 1995 |
| KUBOTA | G1800S | 16HP Diesel | 1989 - 1995 |
| KUBOTA | G1900 | 18HP Diesel | 1989 - 1995 |
| KUBOTA | G2000 | 21HP | 1989 - 1995 |
| KUBOTA | G3200 | 10HP Diesel | 1983 - 1990 |
| KUBOTA | G4200H | 12HP Diesel | 1984 - 1990 |
| KUBOTA | G5200H | 14HP Diesel | 1984 - 1990 |
| KUBOTA | G6200H | 16HP Diesel | 1986 - 1990 |
| KUBOTA | GF1800E-R | 18HP Diesel | 2005 |
| KUBOTA | GF1800-R | 18HP Diesel | 2005 |
| KUBOTA | K008 | 10HP Diesel | 2000 |
| KUBOTA | K008-3 | 10HP Diesel | 2000 |
| KUBOTA | KH007 | 8HP Diesel | 1989 - 1993 |
| KUBOTA | KH35 | 13HP Diesel | 1985 |
| KUBOTA | KH41 | 17HP Diesel | 1988 |
| KUBOTA | KH61 | 22HP Diesel | 1988 |
| KUBOTA | RTV500 4x4 | 456cc | - |
| KUBOTA | T1600H | 13HP | 1990 - 1995 |
| KUBOTA | ZD18 | 18HP Diesel | 2005 |
| KUBOTA | ZD21 | 21HP Diesel | 2005 |
| KUBOTA | ZD25 | 28HP Diesel | 2005 |
| KUBOTA | ZD28 | 28HP Diesel | 2005 |
