Information
1012119590Associated Numbers
114362 Denso 1012110951, 1012110952, 1012114132, 1012119590, 1022115040, 1022115041, 1022115042, ALND039 KRAUF ALN4362, ALN4362GB, ALN4362ZD Motorherz ALN4362RB, ALN4362WA Toyota 2706062160, 270606216084, 2706062180, 2706062190 Unipoint ALT5115 WAI 1223801ND WPS 13671N, 13794N
a13277 DXA515 658460 ANJ203 Original Number
1012119590
13794
195599080
270600H040
2706062160
1012114130
1012114131
1012114132
1012115040
1012115041
1022115042
1205301ND
13671
195599070
2706062180
2706062190
290385
90295282
ATA570
AND0158
Bosch AL3290X
Denso 1012114130, 1012114131, 1012114132, 1022115040, 1022115041, 1022115042, 2100180, 2100447
Lester 13671
PIC Picture ID 290385, 290385A
Wilson 90295282, 90295383
Specifications
| Amp | 80 A |
| Bottom Mounting Foot Width (B) | 57.7 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 8 mm |
| Length (L.1) | 160.8 mm |
| OEM Product | No |
| Plug Code | PL_3314 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 4 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 90 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | 4 Runner 3.4 | [5VZ-FE] | 11.1995-07.2002 |
| TOYOTA | 4 Runner 3.4i | [5VZ-FE] | 11.1995-03.1996 |
| TOYOTA | Hilux 3.4 | 08.2001-07.2005 | |
| TOYOTA | Hilux 3.4 4x4 | [5VZ-FE] | 08.1994-07.2000 |
| TOYOTA | Land Cruiser 3.4 4WD | [5VZ-FE] | 04.1996- |
Reference Information
101211-9590 ALT6736 ALT-5115 27060-62184 13794N STX101995 27060-62160 553777RI A6115Video/Publications
