Associated Numbers
Arrowhead SFD0007
JANNCO 41014026R
Bosch F042005010, SR7520N, SR7520X
Denso 2805117
Ford F07U11000AA, F0TZ11002A, F87U11000B1A, FO7U11000AA, SA775
Lester 3228, 3232
Lucas S2913
Remy Light Duty 25515, 27008, 97118
Wilson 91025852, 91025852N, 91025889
21165FD WAI
3232 Lester
3232R WAI
502201 WAI
880513102 PSH
91025852 Wilson
F07U11000AA Ford
F0TZ11002A Ford
ZZL018400 Mazda
AAP 3232 AC DELCO 323515 AC DELCO 3361117 AC DELCO 3361795 AC DELCO 3371045 ACE CM3232N ACE CM7002 ACE CM7002 ACE CM7102 AES 3232N AIM 76089 AIM 76089N AIM SG00109R ALLTECH 1063232 AMPERE 3168 AMPERE 3168S AMSCO FS958 ANDRE NIERMANN 10776 ARC 5081 ARMATURE G ROY 3232 ARROW 352448 ARROWHEAD SFD0007 BARSANCO 5203232 BBB INDUSTRIES 3232 BBB INDUSTRIES N3232 BECK ARNLEY 1876089 BECK ARNLEY 1896089 BEPCO 803232 BOSCH SR7520N BOSCH SR7520X BOSCH SR7545N BOSCH SR7545X BOSTON AUTO 3150316 CANADIAN TIRE 195754 CANADIAN TIRE 195924 CANADIAN TIRE 195950 CARDONE 393240SN CARGO 112030 CARQUEST 3232S COSMOS 805907 COSMOS 903232 DELCO REMY 10465342 DELCO REMY 19011934 DIXIE 20209131 DIXIE S2057 DIXIE S2057N DIXIE S2093 DNS NS03232 DNS S03232 DNS S03240 DUBOIS 903232 DYNAMIC DS00660 EGR 3232 ELPAR 11603617 EXCEL 2406 EXIDE 3213S EXIDE 3224S FORD F07U11000AA FORD F07U11000AA FORD F0TZ11002A FORD F0TZ11002A FORD F87U11000B1A FORD F87U11000B1B FORD F87U11000B2B FORD F87U11000B2B FORD F87U11000BA FORD F87Z11002BA FORD F87Z11002BARM FORD FO7U11000AA FORD FO7UAA FORD FOTZ11002A FORD FOTZ11002A FORD FOTZ11002ARM GARNER 3232S GARNER 5232 GENCO 3232 J & N 41014026 LESTER 3228 LESTER 3232 LTD 3232 LTD N3232 LUCAS S2913 MAZDA ZZL018400 MET METS7545 METRON 3232 METRON D3232S MINNPAR 572542 MONDIAL 7051360 MONMARY 593232 MOTORCRAFT SA775 MOTORCRAFT SA775RM MOTORCRAFT SAV775RM MPA 12192 MPA 12192N MPA 3240SN NAPA 2449244 NAPA 2449286 NAPA 449244 NAPA 449286 NAPA 4N9244 NASTRA 3232 NASTRA 883232 NEW ADVANTAGE 3240N NEW GENERATION 602400 NEW TECH N3240 NSA STR2802 NSA STR2827 OCA S3002 OE PLUS ST6228 OE PLUS ST6228N PACE B3232 PACE E3232S PASCO S600316 PIC 150316 PLATINUM 3240 PPR FOS700 QUALITY 3201 RAYLOC 2449244 RAYLOC 449244 RCP ST775 RELIANCE 3197 REMY 25515 REMY 97118 ROADFORCE RF669168897 ROMAINE 3240N ROMAINE 413232 ROTEX 3232 SPIDER MARINE S3232 STRATOLINE 803232 SUNCOAST 303232 SUNCOAST 3232 TECHNO CVC AME5081 TSA 3232N UNI SELECT 3232 UNIPOINT STR2802 UNIPOINT STR2827 USA 3232 USA 602400 WAI 21895FD WAI 21895FD1 WAI 3240N WAI 3240NWB WAI 50220 WAI 502201 WESTLING 723118S WHATCOM 67312 WM 723118SN WM 723118SX WORLD WIDE 25515 WORLD WIDE 97118 ZORKOS 3232
Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 232 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 4 mm |
| Pinion/Drive OD | 27.7 mm |
| Rotation | CW |
| Spigot Diameter (A) | 103 mm |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Explorer | 4.0L/245CI V6 | 2002 |
| FORD | Explorer Sport Trac | 4.0L/245CI V6 | 2001 - 2003 |
| FORD | Explorer Sport TracXLS | 4.0L/245CI V6 | 2003 |
| FORD | Mustang | 4.0L/245CI V6 | 2005 - 2010 |
| FORD | Ranger | 4.0L/245CI V6 | 2001 - 2005 |
| MAZDA | B4000 | 4.0L V6 | 1994 - 2009 |
| MAZDA | Navajo | 4.0L V6 | 1991 - 1994 |
Alternatives >>>
410-14027 Long Nose Version
