Associated Numbers
0001125600 0001125601 070911023B 070911023BX 0986022460 101378 101378B 114723 20401382BN 20401382OE 22.1378M 25-3225 32700N 6010283 AEY1679 CST10283AS CST10283GS EAA-121453 LRS01679 S1055B SS214 STR504860001125600
AEY1679 AUTOELECTRO
0001125600 BOSCHList
0986022460 BOSCH
114723 CARGO
CST10283AS CASCO
CST10283GS CASCO
EAA121453 EAA
253225 ELSTOCK
22.1378M LAUBER
LRS01679 LUCAS
S1055B PRESTOLITE
20401382BN REAL
20401382OE REAL
6010283 SANDO
SS214 SOVEREIGN
0001125601 VW
070911023B VW
070911023BX VW
32700N WAI / TRANSPO
STR50486 WOODAUTO
0001125600 Bosch
0001125601 Bosch
070911023B VW
070911023BX VW
0986022460 Bosch ruil
11022460 EuroTec
114723 Cargo
120612 PIC
12070 EAI
253225 Elstock
300563092 PSH
3052 CEVAM
32700 Lester
32700N WAI
4814SP Spidan
8022460F Friesen
913928 EDR
A22460 ATL
CS1378 HC
DRS3928 Remy
HCS1378 HC
LRS01679 Lucas
STR1365sa Electrolog
Specifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 244 mm |
| Mount Hole Center - Center (O.1) | 131 mm |
| Mount Hole Diameter (C.1) | M12x1.75 mm |
| Mount Hole Diameter (C.2) | M12x1.75 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 59 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82.5 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VW | Touareg 2.5 TDi | [BAC] | 01.2003- |
| VW | Touareg 2.5 TDi R5 | [BLK] | 08.2003- |
Reference Information
22.1378M 300.563.092.215 MAV122830 AEY1679 114723 SS214 CS1378 300.563.092.010 300.563.092.395 EAA-121453 0986022460 CST10283GS 25-3225 0001125600 S1055B CST10283AS 070911023BX STR1365 101378B STRS265 300.563.092.461 STX201044 S12BH0444A2 S0403 300.563.092.280 6010283 332084 20401382OE 32700N 20401382BN 101378 070911023B LRS1679 5010439 LRS01679 1125601 STR50486Video/Publications
