Associated Numbers
0001107034 0001107045 0001107056 0001107100 0001107101 0001107108 0986016883 0986017923 0986019853 10519 10519H 10519V 10727 10879 111848 20510107 20510121 20513050 35258790 4805518 55351638 6202008 6202066 8212596 9000794 9000795 90508037 9200961 92064181 93176061 96208783 96208785 96430345 96450663 96473777 96627035 96840345 96843582 96952007 B001110097 CS879 D6RA92 S1101(DELCO)S1101(DELCO) ASPL
0001107034 BOSCHList
0001107045 BOSCHList
0001107056 BOSCHList
0001107100 BOSCHList
0001107101 BOSCHList
0001107108 BOSCHList
0986016883 BOSCH
0986017923 BOSCH
0986019853 BOSCH
B001110097 BOSCHList
111848 CARGO
96840345 CHEVROLET
96952007 CHEVROLET
96430345 DAEWOOList
96450663 DAEWOO
9000794 DELCOList
9000795 DELCOList
96208783 DELCOList
96208785 DELCOList
96473777 DELCOList
96843582 DELCO
CS879 HC PARTS
4805518 OPEL
55351638 OPEL
6202008 OPEL
6202066 OPEL
90508037 OPEL
9200961 OPEL
92064181 OPEL
93176061 OPEL
96627035 OPEL
8212596 POWERMAX
20510107 PRESTOLITE
20510121 PRESTOLITE
20513050 PRESTOLITE
35258790 PRESTOLITEList
D6RA92 VALEOList
S0098 ASPLList
AES1207 AUTOELECTRO
AES1290 AUTOELECTRO
0001107034 BOSCHList
0001107045 BOSCHList
0001107056 BOSCHList
0001107100 BOSCHList
0001107101 BOSCHList
0001107108 BOSCHList
0986016880 BOSCH
0986017920 BOSCH
B001110097 BOSCHList
F005M00001 BOSCHList
111848 CARGO
CST10200AS CASCO
3668 CEVAM
96430345 DAEWOOList
96450663 DAEWOO
9000794 DELCOList
9000795 DELCOList
96473779 DELCO
96843579 DELCO
96952007 DELCO
DRS3553 DELCO
DRS6880 DELCO
DRS6880N DELCO
DRS7920 DELCO
EAA121171 EAA
11768 EAI
252079 ELSTOCK
252264 ELSTOCK
253031 ELSTOCK
253384 ELSTOCK
8016880 FRIESEN
CS879 HC PARTS
8EA732658001 HELLA
42016880 HERTH+BUSS
42017920 HERTH+BUSS
11.130.010 ISKRA / LETRIKA
AZE2113 ISKRA / LETRIKAList
8920641810 ISUZU
22.0879 LAUBER
LRS02084 LUCAS
LRS02213 LUCAS
LRT00107 LUCAS
LRT00190 LUCAS
943251334 MAGNETI MARELLI
943253114 MAGNETI MARELLI
1202029 OPEL
1202140 OPEL
1202145 OPEL
1202159 OPEL
4805518 OPEL
55351638 OPEL
6202008 OPEL
6202066 OPEL
90370766 OPEL
90371766 OPEL
90508037 OPEL
90512189 OPEL
9200961 OPEL
93176061 OPEL
96627035 OPEL
8212596 POWERMAX
88212596 POWERMAX
20510107 PRESTOLITE
20510121 PRESTOLITE
20513050 PRESTOLITE
35258790 PRESTOLITEList
S1039B PRESTOLITE
20401002BN REAL
RNL1688 RNL
6010200 SANDO
SS831 SOVEREIGN
438131 VALEO
455879 VALEO
458184 VALEO
D6RA92 VALEOList
17770N WAI / TRANSPO
33083N WAI / TRANSPO
6750N WAI / TRANSPO
STR50008 WOODAUTO
706210 DXS503 SND006GQ
0001107034 Bosch
0001107045 Bosch
0001107056 Bosch
0001107100 Bosch
0001107101 Bosch
0001107108 Bosch
0001107113 Bosch
0001110097 Bosch
09200961
0986016880 Bosch ruil
0986017920 Bosch ruil
11016880 EuroTec
11017920 EuroTec
11040662 EuroTec
111848 Cargo
11768 EAI
1202029 Opel
1202145 Opel
1202158 Opel
1202159 Opel
120247 PIC
130518092 PSH
130534092 PSH
17770 Lester
17770N WAI
17770R WAI
187683 Valeo
20510107 Prestolite
24422272 Opel
252079 Elstock
252264 Elstock
253031 Elstock
33083 Lester
33083N WAI
33083R WAI
4143SP Spidan
438131 Valeo
455879 Valeo
458184 Valeo
458564 Valeo
55351638
6202053 Opel
6202066 Opel
6724 Lester
8000159 Remy
8016880F Friesen
8017920F Friesen
8EA012526831 Hella
9000961 Remy
90371765 Opel
90371766 Opel
90449689 Opel
90451825 Opel
90487345 Opel
90508037 Opel
90512189 Opel
90518627 Opel
91157199 Wilson
913553 EDR
916880 EDR
9200961 Opel
92066449 Opel
92087059 Opel
93175888 Opel
93175906 Opel
93176061 Opel
9512770 EDR
96208785 Remy
96430345 Opel
96450663 Opel
96473779 Opel
96627035 Opel
96843579 Opel
96843582 Opel
96952007 Opel
A16880 ATL
A16885 ATL
A17920 ATL
CS1563 HC
CS879 HC
CST10200 Casco
D6RA92 Valeo
DRS3553 Remy
DRS3553N Remy
DRS6880 Remy
DRS6880N Remy
DRS7920 Remy
F005M00024 Bosch
HCS879 HC
J5210904 Nipparts
LRT00107 Lucas
LRT00190 Lucas
OSM10739 Optimum
S27330 Hitachi
S9710181
STM1045 Rolling Components
STM527 Rolling Components
STR1130sa Electrolog
STR1715SA Electrolog
STR2632 Unipoint
STR2661 Unipoint
STR2703SA Electrolog
TRS040 TWA
Specifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 212 mm |
| Mount Hole Center - Center (O.1) | 116 mm |
| Mount Hole Diameter (C.1) | M12x1.75 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| OEM Product | Yes |
| Pinion at Rest (B) | 18 mm |
| Product Line | Premium Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82.5 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | Captiva 2.4 | [Z24SED] | 06.2006- |
| CHEVROLET | Captiva 2.4 4WD | [Z24SED] | 06.2006- |
| CHEVROLET | Captiva 2.4 LPG | [Z24SED] | 01.2007- |
| CHEVROLET | Captiva 2.4 LPG 4WD | [Z24SED] | 01.2007- |
| CHEVROLET | Evanda 2.0 | [X20SED] | 03.2005- |
| CHEVROLET | Lacetti 1.8 | [F18D3] | 08.2005- |
| CHEVROLET | Lacetti 1.8 | [T18SED] | 03.2005- |
| CHEVROLET | Nubira 1.8 | [F18D3] | 08.2005- |
| CHEVROLET | Nubira 1.8 | [T18SED] | 03.2005- |
| CHEVROLET | Rezzo 2.0 | [T20SED] | 03.2005- |
| CHEVROLET | Rezzo 2.0 | [T20SED] | 08.2005- |
| CHEVROLET | Tacuma 2.0 | [T20SED] | 03.2005- |
| DAEWOO | Evanda 2.0 | [L88] | 08.2002- |
| DAEWOO | Lacetti 1.8 | [T18SED] | 02.2004- |
| DAEWOO | Leganza 1.8 CD | [C18LE] | 06.1997-07.2003 |
| DAEWOO | Leganza 2.0 | [T20SED] | 01.2001-12.2002 |
| DAEWOO | Leganza 2.0 16V | [X20SED] | 06.1997-12.2002 |
| DAEWOO | Leganza 2.2 | 01.1999-01.2000 | |
| DAEWOO | Leganza 2.2 16V | [T22SED] | 04.1999-12.2002 |
| DAEWOO | Nubira 1.8 | [T18SED] | 07.2003- |
| DAEWOO | Nubira 2.0 | [C20SED] | 06.1999-07.2003 |
| DAEWOO | Nubira 2.0 | 01.1999-01.2000 | |
| DAEWOO | Nubira 2.0 16V | [T20SED] | 12.2000- |
| DAEWOO | Nubira 2.0 16V | [X20SED] | 05.1997- |
| DAEWOO | Nubira 2.0 16V | [Z20L] | 05.1997- |
| DAEWOO | Nubira 2.0 CDX | [T20SED] | 08.2002-07.2003 |
| DAEWOO | Rezzo 2.0 | [T20SED] | 09.2000- |
| DAEWOO | Rezzo 2.0 | [X20SED] | 09.2001- |
| DAEWOO | Tacuma 2.0 | [T20SED] | 09.2000- |
| DAEWOO | Tacuma 2.0 | [X20SED] | 09.2001- |
| HOLDEN | Astra 2.0 Turbo | [Z20LET] | 06.2002- |
| ISUZU | Amigo 2.2 | [X22SE] | 01.1999-01.2000 |
| ISUZU | Amigo 2.2 | 01.1998-01.1998 | |
| ISUZU | Rodeo 2.2 | [X22SE] | 01.1998-01.2000 |
| OPEL | Antara 2.4 | [Z24XE] | 09.2008- |
| OPEL | Antara 2.4 | [Z24XED] | 05.2006- |
| OPEL | Antara 2.4 4x4 | [Z24XE] | 01.2007- |
| OPEL | Antara 2.4 BiFuel LPG | [Z24XE] | 10.2008- |
| OPEL | Astra F 1.8 i 16V | [C18XEL] | 09.1994-01.1998 |
| OPEL | Astra F 1.8 i 16V | [C18XEL] | 11.1994-09.1998 |
| OPEL | Astra F 1.8 i 16V | [X18XE] | 09.1994-01.1998 |
| OPEL | Astra F 1.8 i 16V | [X18XE] | 11.1994-09.1998 |
| OPEL | Astra G 2.0 | [Z20LER] | 11.2002-01.2005 |
| OPEL | Astra G 2.0 | [Z20LET] | 11.2002-01.2005 |
| OPEL | Astra G 2.0 | [Z20LET] | 11.2002-07.2004 |
| OPEL | Astra G 2.0 16V | [Z20LET] | 03.2002-10.2005 |
| OPEL | Astra G 2.0 i 16V | [X20XER] | 11.1999-09.2002 |
| OPEL | Astra G 2.0 OPC | [Z20LET] | 09.2002-01.2005 |
| OPEL | Astra G 2.0 OPC | [Z20LET] | 09.2002-07.2004 |
| OPEL | Astra G 2.0 Turbo 16V | [Z20LET] | 08.2001-05.2005 |
| OPEL | Astra G 2.0 Turbo 16V | [Z20LET] | 09.2000-08.2001 |
| OPEL | Astra G 2.0 Turbo 16V | [Z20LET] | 11.2002-05.2005 |
| OPEL | Astra G 2.0 Turbo 16V | [Z20LET] | 11.2002-10.2005 |
| OPEL | Astra H 2.0 Turbo | [Z20LEH] | 03.2005- |
| OPEL | Astra H 2.0 Turbo | [Z20LEL] | 03.2004- |
| OPEL | Astra H 2.0 Turbo | [Z20LEL] | 08.2004- |
| OPEL | Astra H 2.0 Turbo | [Z20LEL] | 09.2005- |
| OPEL | Astra H 2.0 Turbo | [Z20LER] | 09.2004- |
| OPEL | Astra H 2.0 Turbo | [Z20LER] | 09.2005- |
| OPEL | Astra H 2.0 Turbo GTC | [Z20LEH] | 08.2005- |
| OPEL | Astra H 2.0 Turbo GTC | [Z20LEL] | 03.2005- |
| OPEL | Astra H 2.0 Turbo GTC | [Z20LER] | 03.2005- |
| OPEL | Frontera B 2.2 i | [X22SE] | 10.1998- |
| OPEL | Omega B 2.0 i 16V | [X20XEV] | 03.1994-09.1999 |
| OPEL | Omega B 2.2 i 16V | [Y22XE] | 09.1999-07.2003 |
| OPEL | Omega B 2.2 i 16V | [Z22XE] | 09.1999-07.2003 |
| OPEL | Sintra 2.2 i 16V | [X22XE] | 11.1996-04.1999 |
| OPEL | Speedster 2.0 Turbo | [Z20LET] | 04.2003- |
| OPEL | Vectra A 2.0 i 16V | [X20XEV] | 06.1994-11.1995 |
| OPEL | Vectra A 2.0 i 16V 4x4 | [X20XEV] | 06.1994-11.1995 |
| OPEL | Vectra B 1.8 16V | [X18XE] | 10.1995-09.2000 |
| OPEL | Vectra B 1.8 16V | [X18XE] | 11.1996-09.2000 |
| OPEL | Vectra B CC 1.8 16V | [X18XE] | 10.1995-09.2000 |
| OPEL | Zafira A 2.0 | [Z20LET] | 09.2001-06.2005 |
| OPEL | Zafira A 2.0 OPC | [Z20LET] | 11.2002-06.2005 |
| OPEL | Zafira B 2.0 | [Z20LEH] | 01.2006- |
| OPEL | Zafira B 2.0 | [Z20LER] | 07.2005- |
| VAUXHALL | Antara 2.4 | [Z24XED] | 05.2006- |
| VAUXHALL | Astra 2.0 16V Turbo | [Z20LER] | 01.2006-11.2010 |
| VAUXHALL | Astra 2.0 i | [Z20LEL] | 02.2006-11.2010 |
| VAUXHALL | Astra 2.0 Turbo | [Z20LET] | 03.2002-10.2005 |
| VAUXHALL | Astra 2.0 Turbo SRi | [Z20LET] | 07.2002-05.2005 |
| VAUXHALL | Astra G 2.0 16V | [X20XEV] | 02.1998-05.2005 |
| VAUXHALL | Astra G 2.0 16V | [X20XEV] | 09.1998-05.2005 |
| VAUXHALL | Astra Mk IV 2.0 | [Z20LET] | 08.2002-05.2005 |
| VAUXHALL | Astra Mk IV 2.0 | [Z20LET] | 09.2002-07.2006 |
| VAUXHALL | Astra MK IV 2.0 16V | [X20XER] | 10.1999-05.2005 |
| VAUXHALL | Astra MK IV 2.0 Turbo 16V | [Z20LET] | 09.2000-08.2005 |
| VAUXHALL | Astra MK V 2.0 Turbo | [Z20LEH] | 03.2005- |
| VAUXHALL | Astra MK V 2.0 Turbo | [Z20LEL] | 02.2005-11.2010 |
| VAUXHALL | Astra MK V 2.0 Turbo | [Z20LEL] | 03.2004- |
| VAUXHALL | Astra MK V 2.0 Turbo | [Z20LEL] | 08.2004-10.2010 |
| VAUXHALL | Astra MK V 2.0 Turbo | [Z20LER] | 03.2004- |
| VAUXHALL | Astra MK V 2.0 Turbo | [Z20LER] | 08.2004-10.2010 |
| VAUXHALL | Astra MK V 2.0 VXRacing Edition | [Z20LEH] | 02.2009-11.2010 |
| VAUXHALL | Calibra A 2.0 i 16V | [X20XEV] | 06.1990-07.1997 |
| VAUXHALL | Calibra A 2.0 i 16V 4x4 | [X20XEV] | 02.1994-07.1997 |
| VAUXHALL | Frontera B 2.2 i | [X22SE] | 10.1998-10.2004 |
| VAUXHALL | Frontera B 2.2 i | [Y22SE] | 10.1998-10.2004 |
| VAUXHALL | Omega 2.2 i 16V | [Y22XE] | 09.1999- |
| VAUXHALL | Omega 2.2 i 16V | [Z22XE] | 09.1999- |
| VAUXHALL | Sintra 2.2 i 16V | [X22XE] | 11.1996-04.1999 |
| VAUXHALL | Speedster 2.0 | [Z20LET] | 03.2001-09.2006 |
| VAUXHALL | Vectra 2.2 i | [C22SEL] | 10.1999-08.2001 |
| VAUXHALL | VX 2.0 i Turbo 220 | [Z20LET] | 04.2003-07.2005 |
| VAUXHALL | Zafira 2.0 | [Z20LER] | 06.2002-06.2005 |
| VAUXHALL | Zafira 2.0 Turbo 16V | [Z20LET] | 09.2001- |
| VAUXHALL | Zafira Mk II 2.0 | [Z20LEH] | 01.2006- |
| VAUXHALL | Zafira Mk II 2.0 | [Z20LER] | 07.2005- |
Reference Information
220119 92064181 90487345 96843582 0001107101 0001107100 20510121 CST46102GS 24422272 93176061 220434 20460201RE 9512770 90451825 0986019853 CST46102OS 96208783 96208785 9000961 55351638 93175888 0986017923 10519V STX200092R 6202008 0001107056 35258790 96627035 96473779 96843579 96473777 96840345 1202029 9647377 S12BH0202A2 10519H 1202145 90508037 90449689 R1540014 1202140 9000795 9000794 90518627 CST46102AS 96952007 0001107045 0986016883 1202159 1202158 6202053 9512270 96450663 10879 90371766 D6RA92 90371765 93175906 10519 6046102 B001110097 6046102.1 4805518 20460201OE 0001107034 6046102.4 S1101(DELCO) STX200092 9200961 111848 6202066 R1040000 8212596 20513050 96430345 10727 20460201BN 9119798 90512189 CS879 0001107108 20510107 9119794Video/Publications
