Associated Numbers
111305 111380 11900 17217N 201004 22.3132 23300-4E100 254921 36100-32560 36100-32610 36100-32640 6035120 6035219 CST35120 CST35120AS CST35120ES CST35120GS CST35120OS CST35120RS CST35219 CST35219AS CST35219ES CST35219GS CST35219OS CST35219RS DRS3159 DRS3159N M001T73371 M001T73381ZC M001T73382 M001T73383 M001T73383ZC M001T73881 M1T73371 M1T73381 M1T73381ZC M1T73382 M1T73383 M1T73383ZC M1T73881 MD145183 MD162840 MD172861 MD172861R S1171M TM000A04201 TM000a04201
111305 CARGO
111380 CARGO
CST35120 CASCO
CST35219 CASCO
DRS3159 DELCO
DRS3159N DELCO
11900 EAI
3610032560 HYUNDAI / KIA
3610032610 HYUNDAI / KIA
3610032640 HYUNDAI / KIAList
22.3132 LAUBER
M001T73371 MITSUBISHI
M001T73381ZC MITSUBISHIList
M001T73382 MITSUBISHI
M001T73383 MITSUBISHIList
M001T73383ZC MITSUBISHIList
M001T73881 MITSUBISHIList
M1T73371 MITSUBISHI
M1T73381 MITSUBISHIList
M1T73381ZC MITSUBISHIList
M1T73382 MITSUBISHI
M1T73383 MITSUBISHIList
M1T73383ZC MITSUBISHIList
M1T73881 MITSUBISHIList
MD145183 MITSUBISHIList
MD162840 MITSUBISHIList
MD172861 MITSUBISHIList
MD172861R MITSUBISHI
233004E100 NISSANList
S1171M PRESTOLITE
6035120 SANDO
6035219 SANDO
TM000A04201 VALEO
17217N WAI / TRANSPO
mxs228 mxs361 706024 706031 706034 SNJ111 SNJ111gq
0986019081 Bosch ruil
11040102 EuroTec
111380 Cargo
11900 EAI
150519082 PSH
17217 Lester
17217N WAI
17217R WAI
3610022100 Hyundai
3610032560 Kia
3610032640 Kia
4464SP Spidan
600065 Valeo
91273088 Wilson
ACS147 ATK
DRS3159 Remy
F042001054 Bosch
F042S01054 Bosch
F042S01054FDB Bosch
HJS1004 HC
HSP112130 Halla
JS1004 HC
LRS00979 Lucas
M001T73381 Mitsubishi
M001T73383 Mitsubishi
M1T73381 Mitsubishi
M1T73381ZC Mitsubishi
M1T73383 Mitsubishi
M1T73383ZC Mitsubishi
MD145183 Mitsubishi
MD162840 Mitsubishi
MD172861 Mitsubishi
MP112033 Mitsubishi
MP112042 Mitsubishi
STR3053 Unipoint
TRS054 TWA
Hyundai MD172864
Lester 17217
Mitsuba M1T73381
Mitsubishi 3610032640, MD162840, MD172864
Valeo TM000A04201
Mitsubishi M1T73383
Valeo 438119
Wilson 91273088
References:
Arrowhead SMT0041
Bosch SR4166N, SR4166X
Denso 2804112
Lester 17217
Mitsubishi M1T73383, MD172861
PIC Picture ID 103177, 103177A
Valeo 438119, MP112042, TM000A04201
Wilson 91273088, 91273105, 91273119, 91273119N
Valeo MP112042, TM000A04201
Substitutes:
J&N 41048108
Bosch SR4166X
References:
J&N 41048108
Kia 3610032640
Mando MP112033, MP112042, TM000A04201
Valeo MP112042, TM000A04201
Specifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 207 mm |
| Mount Hole Center - Center (O.1) | 106 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 8 qty |
| No./Teeth (Replaces) | 8 qty |
| OEM Product | No |
| Pinion at Rest (B) | 27 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | Elantra 1.8 | [G4CN] | 01.1998-01.1998 |
| HYUNDAI | Lantra 1.6 i 16V | [G4CR] | 10.1990-11.1995 |
| HYUNDAI | Lantra 1.8 i 16V | [G4CN] | 10.1990-11.1995 |
| HYUNDAI | Santamo 2.0 16V | [G4CP] | 05.1999- |
| HYUNDAI | Sonata 1.8 i | [4G62] | 09.1988-10.1993 |
| HYUNDAI | Sonata 1.8 i | [G4CM] | 05.1993-06.1998 |
| HYUNDAI | Sonata 2.0 i | [G4CP] | 06.1994-08.1996 |
| HYUNDAI | Sonata 2.0 i | [G4CP] | 08.1996-06.1998 |
| HYUNDAI | Sonata 2.0 i | [G4CP] | 09.1988-08.1991 |
| HYUNDAI | Sonata 2.0 i 16V | [G4CP-D] | 01.1991-10.1993 |
| HYUNDAI | Sonata 2.4 | 01.1989-01.1991 | |
| HYUNDAI | Sonata 2.4 GL | 01.1989-01.1991 | |
| HYUNDAI | Sonata 2.4 i | [G4CS] | 09.1988-08.1991 |
| KIA | Joice 2.0 | [G4CP] | 02.2000- |
| KIA | Joice 2.0 | 09.2001- | |
| MITSUBISHI | Eclipse 1.8 | [4G37] | 12.1989-03.1994 |
| MITSUBISHI | Eclipse 2.0 i 16V | [4G63] | 04.1991-11.1995 |
| MITSUBISHI | Eclipse 2.0 Turbo | 04.1994-04.1999 | |
| MITSUBISHI | Galant 2.0 16V | [4G63] | 11.1987-10.1992 |
| MITSUBISHI | Space Wagon 1.8 | [4G93] | 10.1991-10.1998 |
| MITSUBISHI | Space Wagon 1.8 4WD | [4G93] | 10.1991-10.1998 |
Reference Information
