- Associated Numbers
- Specifications
- Vehicle Applications
- Alternatives >>>
- Reference Information
- Video/Publications
Associated Numbers
0009060126 000906012680 0061514501 006151450180 0986025940 114305 12256 190-20505 20432223OE 20432223RC 220670 25-4159 254698D 254698K 254698R 30219N 3207 42428551 428000-5510 428000-5511 550.546.122 6040322 6519060026 651906002680 88214327 8EA011611-481 8EA012140-531 91-29-5873 943215271010 A0009060126 A000906012680 A0061514501 A006151450180 A6519060026 A651906002680 AEY2487 CS1527 CST40322 CST40322AS CST40322ES CST40322GS CST40322OS CST40322RS DENDSN967 DRS0628 DS1738 DSN967 EAA-141311 LRS02487 LRS2487 MSRC1527 RAS31739 S-80635 S6055 STN1527 STR70369 ASPLList AUTOELECTRO BOSCH CARGO CASCO CEVAM DELCO 4280005510 DENSOList 4280005511 S80635 DIXIE EAA141311 EAA EAI 254159 ELSTOCK ERA HC PARTS 8EA011611481 HELLA 8EA012140531 HERTH+BUSS KRAUF LUCAS MAGNETI MARELLI MERCEDES MERCEDESList POWERMAX PSH REAL 19020505 ROBERT'S SANDO WAI / TRANSPO 91295873 WILSON WOODAUTO dxs4030 708596 Mercedes Benz Bosch ruil 11090197 EuroTec Cargo 15130057 AES 15130078 20130011 Elstock 325058122 DRI Denso 4280805511 50201671 REEX 550546122 6519060025 8080384F Friesen 910628 EDR 944280803840 A79310 ATL Casco Remy Lucas OSM11841 Optimum STM1211 Rolling Components STR6276sa Electrolog STR6553sa TRS017 TWA Arrowhead SND0771 Delco Lester 30219 A6519060025 PIC Picture ID 1909104 J N 41052340 20432223Specifications
Kilowatt | 1.8 kW |
Length (L.1) | 200 mm |
Mount Hole Center - Center (O.1) | 100 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 12 qty |
No./Teeth (Replaces) | 12 qty |
OEM Product | No |
Pinion at Rest (B) | 15 mm |
Product Line | Standard Line |
Product Type | Brand new |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MERCEDES BENZ | C 180 2.1 CDi | (S204)[OM651.913] | 01.2011-08.2014 |
MERCEDES BENZ | C 180 2.1 CDi | (W204)[OM651.913] | 01.2011-01.2014 |
MERCEDES BENZ | C 200 2.1 CDi | (S204)[OM651.913] | 08.2010-08.2014 |
MERCEDES BENZ | C 200 2.1 CDi | (W204)[OM651.913] | 01.2011-01.2014 |
MERCEDES BENZ | C 220 2.1 CDi | (C204)[OM651.911] | 06.2011- |
MERCEDES BENZ | C 220 2.1 CDi | (S204)[OM651.911] | 12.2008-08.2014 |
MERCEDES BENZ | C 220 2.1 CDi | (W204)[OM651.911] | 12.2008-01.2014 |
MERCEDES BENZ | C 250 2.1 CDi | (C204)[OM651.911] | 06.2011- |
MERCEDES BENZ | C 250 2.1 CDi | (S204)[OM651.911] | 01.2009-08.2014 |
MERCEDES BENZ | C 250 2.1 CDi | (W204)[OM651.911] | 08.2008-01.2014 |
MERCEDES BENZ | C 250 2.1 CDi 4-Matic | (S204)[OM651.912] | 04.2010-08.2014 |
MERCEDES BENZ | C 250 2.1 CDi 4-Matic | (W204)[OM651.912] | 01.2011-01.2014 |
MERCEDES BENZ | CLS 250 2.1 BlueTec | (C218)[OM651.924] | 04.2011- |
MERCEDES BENZ | CLS 250 2.1 CDi | (C218)[OM651.924] | 04.2011- |
MERCEDES BENZ | E 200 2.1 BlueTec | (S212)[OM651.925] | 11.2009- |
MERCEDES BENZ | E 200 2.1 BlueTec | (W212)[OM651.925] | 01.2009- |
MERCEDES BENZ | E 200 2.1 CDi | (S212)[OM651.925] | 11.2009- |
MERCEDES BENZ | E 200 2.1 CDi | (W212)[OM651.925] | 01.2009- |
MERCEDES BENZ | E 220 2.1 BlueTec | (A207)[OM651.911] | 01.2010- |
MERCEDES BENZ | E 220 2.1 BlueTec | (S212)[OM651.924] | 11.2009- |
MERCEDES BENZ | E 220 2.1 BlueTec | (W212)[OM651.924] | 01.2009- |
MERCEDES BENZ | E 220 2.1 CDi | (A207)[OM651.911] | 01.2010- |
MERCEDES BENZ | E 220 2.1 CDi | (C207)[OM651.911] | 01.2010- |
MERCEDES BENZ | E 220 2.1 CDi | (S212)[OM651.924] | 11.2009- |
MERCEDES BENZ | E 220 2.1 CDi | (W212)[OM651.924] | 01.2009- |
MERCEDES BENZ | E 250 2.1 BlueTec | (A207)[OM651.911] | 01.2010- |
MERCEDES BENZ | E 250 2.1 BlueTec | (C207)[OM651.911] | 01.2009- |
MERCEDES BENZ | E 250 2.1 BlueTec | (S212)[OM651.924] | 11.2009- |
MERCEDES BENZ | E 250 2.1 BlueTec | (W212)[OM651.924] | 01.2009- |
MERCEDES BENZ | E 250 2.1 BlueTec 4-Matic | (S212)[OM651.924] | 07.2010- |
MERCEDES BENZ | E 250 2.1 BlueTec 4-Matic | (W212)[OM651.924] | 01.2009- |
MERCEDES BENZ | E 250 2.1 CDi | (A207)[OM651.911] | 01.2010- |
MERCEDES BENZ | E 250 2.1 CDi | (C207)[OM651.911] | 01.2009- |
MERCEDES BENZ | E 250 2.1 CDi | (S212)[OM651.924] | 07.2010- |
MERCEDES BENZ | E 250 2.1 CDi | (S212)[OM651.924] | 11.2009- |
MERCEDES BENZ | E 250 2.1 CDi | (W212)[OM651.924] | 01.2009- |
MERCEDES BENZ | GLK 200 2.1 CDi | (X204)[OM651.913] | 07.2010-06.2015 |
MERCEDES BENZ | GLK 200 2.1 CDi | (X204)[OM651.916] | 07.2010-06.2015 |
MERCEDES BENZ | GLK 220 2.1 CDi | (X204)[OM651.916] | 12.2018-06.2018 |
MERCEDES BENZ | GLK 220 2.1 CDi 4-Matic | (X204)[OM651.912] | 12.2018-06.2018 |
MERCEDES BENZ | GLK 250 2.1 CDi 4-Matic | (X204)[OM651.912] | 09.2009-06.2015 |
MERCEDES BENZ | Mixto 113 2.1 CDi | (W639)[OM651.940] | 09.2010- |
MERCEDES BENZ | Mixto 116 2.1 CDi | (W639)[OM651.940] | 09.2010- |
MERCEDES BENZ | SLK 250 2.1 CDi | (R172)[OM651.980] | 01.2012- |
MERCEDES BENZ | SLK 250 2.1 D | (R172)[OM651.980] | 01.2012- |
MERCEDES BENZ | Sprinter 213 2.1 CDi | (906)[OM651.955] | 03.2009-05.2016 |
MERCEDES BENZ | Sprinter 213 2.1 CDi | (906)[OM651.956] | 03.2009-05.2016 |
MERCEDES BENZ | Sprinter 213 2.1 CDi | (906)[OM651.957] | 03.2009-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.955] | 05.2009- |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.955] | 06.2006-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.955] | 08.2011-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.956] | 05.2009- |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.956] | 06.2006-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.956] | 08.2011-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.955] | 05.2009- |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.955] | 06.2006-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.955] | 08.2011-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.956] | 05.2009- |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.956] | 06.2006-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.956] | 08.2011-05.2016 |
MERCEDES BENZ | Sprinter 316 2.1 CDi | (906)[OM651.955] | 03.2009- |
MERCEDES BENZ | Sprinter 316 2.1 CDi | (906)[OM651.957] | 03.2009- |
MERCEDES BENZ | Sprinter 316 2.1 CDi 4x4 | (906)[OM651.955] | 03.2009- |
MERCEDES BENZ | Sprinter 316 2.1 CDi 4x4 | (906)[OM651.955] | 08.2011- |
MERCEDES BENZ | Sprinter 316 2.1 CDi 4x4 | (906)[OM651.957] | 03.2009- |
MERCEDES BENZ | Sprinter 316 2.1 CDi 4x4 | (906)[OM651.957] | 08.2011- |
MERCEDES BENZ | Viano 2.0 CDi | (W639)[OM651.940] | 07.2010- |
MERCEDES BENZ | Viano 2.0 CDi 4-Matic | (W639)[OM651.940] | 07.2010- |
MERCEDES BENZ | Viano 2.2 CDi | (W639)[OM651.940] | 07.2010- |
MERCEDES BENZ | Viano 2.2 CDi 4-Matic | (W639)[OM651.940] | 07.2010- |
MERCEDES BENZ | Vito 113 2.1 CDi | (W639)[OM651.940] | 09.2010- |
MERCEDES BENZ | Vito 113 2.1 CDi 4x4 | (W639)[OM651.940] | 09.2010- |
MERCEDES BENZ | Vito 116 2.1 CDi | (W639)[OM651.940] | 09.2010- |
MERCEDES BENZ | Vito 116 2.1 CDi 4x4 | (W639)[OM651.940] | 09.2010- |
Alternatives >>>
S6055(DENSO) - Genuine Denso Option
Reference Information
550.546.122.050 DSN967 S6055 91-29-5873 STX210315R CST40322RS STX200390R 114305 CST40322 428000-5511 0399707152 428000-5510 61514501 6151450180 S12DE0049 CST40322AS 20432223RC UD102376S 42428551 CST40322ES 550.546.122.280 CST40322GS A0061514501 CS1527 6003 RAS31739 DS1738 STN1527 9.43215E+11 6.51906E+11 CST40322OS 8EA012140-531 A006151450180 STX200390 DENDSN967 STX210315 8EA011611-481 254698R 3207 STR6276 220670 STR6553 254698K 5040102 S-80635 A6519060026 254698D LRS2487 A6519064500 0986025940 9060126 906012680 AEY2487 A0009060126 STRS230 6519060026 ANM12848X 25-4159 6519064500 6040322 336498 30219N MSRC1527 STR70369 UD102580S 550.546.122.266 12256 STM1211 S12DE0049A2 550.546.122.260 A651906002680 SX 20432223OE DRS0628 EAA-141311 RNL428000-5510 LRS02487 88214327 550.546.122.058 S1276D A000906012680 190-20505Video/Publications
