Associated Numbers
0009060126 000906012680 0061514501 006151450180 0986025940 114305 12256 190-20505 20432223 220670 25-4159 254698D 254698K 254698R 30219N 3207 42428551 428000-5510 428000-5511 550.546.122 6040322 6519060026 651906002680 88214327 8EA011611-481 8EA012140-531 91-29-5873 943215271010 A0009060126 A000906012680 A0061514501 A006151450180 A6519060026 A651906002680 AEY2487 CS1527 CST40322 CST40322AS CST40322ES CST40322GS CST40322OS CST40322RS DENDSN967 DRS0628 DS1738 DSN967 EAA-141311 LRS02487 LRS2487 MSRC1527 RAS31739 S-80635 STN1527 STR70369
S6055 ASPLList
AEY2487 AUTOELECTRO
0986025940 BOSCH
114305 CARGO
CST40322 CASCO
CST40322GS CASCO
CST40322RS CASCO
3207 CEVAM
DRS0628 DELCO
DS1738 DELCO
RAS31739 DELCO
4280005510 DENSOList
4280005511 DENSOList
4280005510 DENSOList
DSN967 DENSOList
S80635 DIXIE
EAA141311 EAA
12256 EAI
254159 ELSTOCK
220670 ERA
CS1527 HC PARTS
8EA011611481 HELLA
8EA012140531 HELLA
42428551 HERTH+BUSS
STN1527 KRAUF
LRS02487 LUCAS
LRS2487 LUCAS
943215271010 MAGNETI MARELLI
MSRC1527 MAGNETI MARELLI
0009060126 MERCEDES
000906012680 MERCEDES
0061514501 MERCEDESList
006151450180 MERCEDES
6519060026 MERCEDESList
651906002680 MERCEDES
A0009060126 MERCEDES
A000906012680 MERCEDES
A0061514501 MERCEDESList
A006151450180 MERCEDES
A6519060026 MERCEDESList
A651906002680 MERCEDES
88214327 POWERMAX
550.546.122 PSH
20432223OE REAL
20432223RC REAL
19020505 ROBERT'S
6040322 SANDO
30219N WAI / TRANSPO
91295873 WILSON
DENDSN967 WOODAUTO
STR70369 WOODAUTO
dxs4030 708596 4280005510
0009060126 Mercedes Benz
000906012680 Mercedes Benz
0061514501 Mercedes Benz
006151450180 Mercedes Benz
0986025940 Bosch ruil
11090197 EuroTec
114305 Cargo
12256 EAI
15130057 AES
15130078 AES
20130011 AES
254159 Elstock
30219N WAI
325058122 DRI
4280005510 Denso
4280005511 Denso
4280805511 Denso
50201671 REEX
550546122 PSH
6519060025 Mercedes Benz
6519060026 Mercedes Benz
651906002680 Mercedes Benz
8080384F Friesen
910628 EDR
944280803840 Denso
A0009060126 Mercedes Benz
A000906012680 Mercedes Benz
A0061514501 Mercedes Benz
A006151450180 Mercedes Benz
A6519060026 Mercedes Benz
A651906002680 Mercedes Benz
A79310 ATL
CS1527 HC
CST40322 Casco
DRS0628 Remy
DSN967 Denso
LRS02487 Lucas
OSM11841 Optimum
STM1211 Rolling Components
STR6276sa Electrolog
STR6553sa Electrolog
TRS017 TWA
Arrowhead SND0771
Delco DRS0628
Denso 4280005510, 4280005511, 4280805511
Lester 30219
Lucas LRS02487
Mercedes 6519060025, 6519060026, A0061514501, A6519060026, A6519060025
PIC Picture ID 1909104
J&N 41052340
Mercedes A0061514501
Specifications
Kilowatt | 1.8 kW |
Length (L.1) | 202 mm |
Mount Hole Center - Center (O.1) | 101 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 12 qty |
No./Teeth (Replaces) | 12 qty |
OEM Product | Yes |
Pinion at Rest (B) | 15 mm |
Product Line | Premium Line |
Product Type | Brand new |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MERCEDES BENZ | C 180 2.1 CDi | (S204)[OM651.913] | 01.2011-08.2014 |
MERCEDES BENZ | C 180 2.1 CDi | (W204)[OM651.913] | 01.2011-01.2014 |
MERCEDES BENZ | C 200 2.1 CDi | (S204)[OM651.913] | 08.2010-08.2014 |
MERCEDES BENZ | C 200 2.1 CDi | (W204)[OM651.913] | 01.2011-01.2014 |
MERCEDES BENZ | C 220 2.1 CDi | (C204)[OM651.911] | 06.2011- |
MERCEDES BENZ | C 220 2.1 CDi | (S204)[OM651.911] | 12.2008-08.2014 |
MERCEDES BENZ | C 220 2.1 CDi | (W204)[OM651.911] | 12.2008-01.2014 |
MERCEDES BENZ | C 250 2.1 CDi | (C204)[OM651.911] | 06.2011- |
MERCEDES BENZ | C 250 2.1 CDi | (S204)[OM651.911] | 01.2009-08.2014 |
MERCEDES BENZ | C 250 2.1 CDi | (W204)[OM651.911] | 08.2008-01.2014 |
MERCEDES BENZ | C 250 2.1 CDi 4-Matic | (S204)[OM651.912] | 04.2010-08.2014 |
MERCEDES BENZ | C 250 2.1 CDi 4-Matic | (W204)[OM651.912] | 01.2011-01.2014 |
MERCEDES BENZ | CLS 250 2.1 BlueTec | (C218)[OM651.924] | 04.2011- |
MERCEDES BENZ | CLS 250 2.1 CDi | (C218)[OM651.924] | 04.2011- |
MERCEDES BENZ | E 200 2.1 BlueTec | (S212)[OM651.925] | 11.2009- |
MERCEDES BENZ | E 200 2.1 BlueTec | (W212)[OM651.925] | 01.2009- |
MERCEDES BENZ | E 200 2.1 CDi | (S212)[OM651.925] | 11.2009- |
MERCEDES BENZ | E 200 2.1 CDi | (W212)[OM651.925] | 01.2009- |
MERCEDES BENZ | E 220 2.1 BlueTec | (A207)[OM651.911] | 01.2010- |
MERCEDES BENZ | E 220 2.1 BlueTec | (S212)[OM651.924] | 11.2009- |
MERCEDES BENZ | E 220 2.1 BlueTec | (W212)[OM651.924] | 01.2009- |
MERCEDES BENZ | E 220 2.1 CDi | (A207)[OM651.911] | 01.2010- |
MERCEDES BENZ | E 220 2.1 CDi | (C207)[OM651.911] | 01.2010- |
MERCEDES BENZ | E 220 2.1 CDi | (S212)[OM651.924] | 11.2009- |
MERCEDES BENZ | E 220 2.1 CDi | (W212)[OM651.924] | 01.2009- |
MERCEDES BENZ | E 250 2.1 BlueTec | (A207)[OM651.911] | 01.2010- |
MERCEDES BENZ | E 250 2.1 BlueTec | (C207)[OM651.911] | 01.2009- |
MERCEDES BENZ | E 250 2.1 BlueTec | (S212)[OM651.924] | 11.2009- |
MERCEDES BENZ | E 250 2.1 BlueTec | (W212)[OM651.924] | 01.2009- |
MERCEDES BENZ | E 250 2.1 BlueTec 4-Matic | (S212)[OM651.924] | 07.2010- |
MERCEDES BENZ | E 250 2.1 BlueTec 4-Matic | (W212)[OM651.924] | 01.2009- |
MERCEDES BENZ | E 250 2.1 CDi | (A207)[OM651.911] | 01.2010- |
MERCEDES BENZ | E 250 2.1 CDi | (C207)[OM651.911] | 01.2009- |
MERCEDES BENZ | E 250 2.1 CDi | (S212)[OM651.924] | 07.2010- |
MERCEDES BENZ | E 250 2.1 CDi | (S212)[OM651.924] | 11.2009- |
MERCEDES BENZ | E 250 2.1 CDi | (W212)[OM651.924] | 01.2009- |
MERCEDES BENZ | GLK 200 2.1 CDi | (X204)[OM651.913] | 07.2010-06.2015 |
MERCEDES BENZ | GLK 200 2.1 CDi | (X204)[OM651.916] | 07.2010-06.2015 |
MERCEDES BENZ | GLK 220 2.1 CDi | (X204)[OM651.916] | 12.2018-06.2018 |
MERCEDES BENZ | GLK 220 2.1 CDi 4-Matic | (X204)[OM651.912] | 12.2018-06.2018 |
MERCEDES BENZ | GLK 250 2.1 CDi 4-Matic | (X204)[OM651.912] | 09.2009-06.2015 |
MERCEDES BENZ | Mixto 113 2.1 CDi | (W639)[OM651.940] | 09.2010- |
MERCEDES BENZ | Mixto 116 2.1 CDi | (W639)[OM651.940] | 09.2010- |
MERCEDES BENZ | SLK 250 2.1 CDi | (R172)[OM651.980] | 01.2012- |
MERCEDES BENZ | SLK 250 2.1 D | (R172)[OM651.980] | 01.2012- |
MERCEDES BENZ | Sprinter 213 2.1 CDi | (906)[OM651.955] | 03.2009-05.2016 |
MERCEDES BENZ | Sprinter 213 2.1 CDi | (906)[OM651.956] | 03.2009-05.2016 |
MERCEDES BENZ | Sprinter 213 2.1 CDi | (906)[OM651.957] | 03.2009-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.955] | 05.2009- |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.955] | 06.2006-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.955] | 08.2011-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.956] | 05.2009- |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.956] | 06.2006-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi | (906)[OM651.956] | 08.2011-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.955] | 05.2009- |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.955] | 06.2006-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.955] | 08.2011-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.956] | 05.2009- |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.956] | 06.2006-05.2016 |
MERCEDES BENZ | Sprinter 313 2.1 CDi 4x4 | (906)[OM651.956] | 08.2011-05.2016 |
MERCEDES BENZ | Sprinter 316 2.1 CDi | (906)[OM651.955] | 03.2009- |
MERCEDES BENZ | Sprinter 316 2.1 CDi | (906)[OM651.957] | 03.2009- |
MERCEDES BENZ | Sprinter 316 2.1 CDi 4x4 | (906)[OM651.955] | 03.2009- |
MERCEDES BENZ | Sprinter 316 2.1 CDi 4x4 | (906)[OM651.955] | 08.2011- |
MERCEDES BENZ | Sprinter 316 2.1 CDi 4x4 | (906)[OM651.957] | 03.2009- |
MERCEDES BENZ | Sprinter 316 2.1 CDi 4x4 | (906)[OM651.957] | 08.2011- |
MERCEDES BENZ | Viano 2.0 CDi | (W639)[OM651.940] | 07.2010- |
MERCEDES BENZ | Viano 2.0 CDi 4-Matic | (W639)[OM651.940] | 07.2010- |
MERCEDES BENZ | Viano 2.2 CDi | (W639)[OM651.940] | 07.2010- |
MERCEDES BENZ | Viano 2.2 CDi 4-Matic | (W639)[OM651.940] | 07.2010- |
MERCEDES BENZ | Vito 113 2.1 CDi | (W639)[OM651.940] | 09.2010- |
MERCEDES BENZ | Vito 113 2.1 CDi 4x4 | (W639)[OM651.940] | 09.2010- |
MERCEDES BENZ | Vito 116 2.1 CDi | (W639)[OM651.940] | 09.2010- |
MERCEDES BENZ | Vito 116 2.1 CDi 4x4 | (W639)[OM651.940] | 09.2010- |
Alternatives >>>
S6055 - Aftermarket Version
Reference Information
550.546.122.050 DSN967 91-29-5873 STX210315R CST40322RS STX200390R 114305 CST40322 428000-5511 0399707152 428000-5510 61514501 6151450180 S12DE0049 CST40322AS 42428551 CST40322ES 550.546.122.280 CST40322GS A0061514501 CS1527 6003 RAS31739 DS1738 STN1527 9.43215E+11 6.51906E+11 CST40322OS 8EA012140-531 A006151450180 STX200390 DENDSN967 STX210315 8EA011611-481 254698R 3207 STR6276 220670 STR6553 254698K S-80635 A6519060026 254698D LRS2487 A6519064500 0986025940 9060126 906012680 AEY2487 A0009060126 6519060026 25-4159 6519064500 6040322 30219N MSRC1527 STR70369 550.546.122.266 12256 STM1211 S12DE0049A2 550.546.122.260 A651906002680 SX DRS0628 EAA-141311 LRS02487 20432223 88214327 550.546.122.058 S1276D A000906012680 190-20505Video/Publications
