S6156 - Brand new AS-PL Starter motor

Associated Numbers

059911024K 059911024KX 116000 19989N 20432703OE 25-4253 255121 255121D 300.914.153 428000-7220 428000-7221 428000-7222 428000-7223 428000-7224 428000-7720 6040307 95860410900 958604109X AEY2581 CST40307 CST40307AS CST40307ES CST40307GS CST40307OS CST40307RS DENDSN965 DSN965 LRS02581 S6156 STN7720 STR70409 UD11435S

S6156 ASPLList
UD11435S ASPL
AEY2581 AUTOELECTRO
116000 CARGO
CST40307 CASCO
CST40307GS CASCO
428000722 DENSO
4280007220 DENSOList
4280007221 DENSOList
4280007222 DENSO
4280007223 DENSOList
4280007224 DENSO
4280007720 DENSOList
DSN965 DENSO
254253 ELSTOCK
STN7720 KRAUF
LRS02581 LUCAS
95860410900 PORSCHE
958604109X PORSCHE
300.914.153 PSH
20432703OE REAL
6040307 SANDO
059911024K VW
059911024KX VW
19989N WAI / TRANSPO
DENDSN965 WOODAUTO
STR70409 WOODAUTO
059911024K VW
059911024KX VW
11090305 EuroTec
19989 Lester
19989N WAI
300914153 PSH
4280007220 Denso
4280007221 Denso
4280007222 Denso
4280007223 Denso
4280007224 Denso
4280007720 Denso
4280007721 Denso
4280007722 Denso
4280007723 Denso
910784 EDR
95860410900 Porsche
DRS0784 Remy
DSN965 Denso
LRS02581 Lucas
STR6445sa Electrolog

Specifications

Kilowatt	2 kW
Length (L.1)	248 mm
Mount Hole Center - Center (O.1)	101.5 mm
Mount Hole Center - Center (O.2)	24 mm
Mount Hole Center - Center (O.3)	104 mm
Mount Hole Diameter (C.1)	11.5 mm
Mount Hole Diameter (C.2)	M10x1.75 mm
Mount Hole Diameter (C.3)	11.5 mm
No./Mount holes	3 qty
No./Mount holes with thread	1 qty
No./Teeth	15 qty
OEM Product	No
Pinion at Rest (B)	25.5 mm
Product Line	Standard Line
Product Type	Brand new
Rotation	CW
Spigot Diameter (A)	76 mm
Unit Type	DENSO
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
AUDI	Q7 3.0 TDi	[CASA]	11.2007-
AUDI	Q7 3.0 TDi	[CASA]	11.2007-08.2015
AUDI	Q7 3.0 TDi	[CCMA]	06.2009-
AUDI	Q7 3.0 TDi	[CCMA]	11.2007-08.2015
AUDI	Q7 3.0 TDi	[CJGA]	06.2009-
AUDI	Q7 3.0 TDi	[CJGA]	11.2007-08.2015
AUDI	Q7 3.0 TDi	[CJGC]	05.2010-
AUDI	Q7 3.0 TDi	[CJGC]	05.2010-08.2015
AUDI	Q7 3.0 TDi	[CJGD]	05.2011-
AUDI	Q7 3.0 TDi	[CJGD]	05.2011-08.2015
AUDI	Q7 3.0 TDi	[CJMA]	05.2010-
AUDI	Q7 3.0 TDi	[CJMA]	05.2010-08.2015
AUDI	Q7 3.0 TDi	[CLZB]	05.2011-
AUDI	Q7 3.0 TDi	[CLZB]	05.2011-08.2015
AUDI	Q7 3.0 TDi	[CNRB]	06.2009-
AUDI	Q7 3.0 TDi	[CNRB]	11.2007-08.2015
AUDI	Q7 3.0 TDi	[CRCA]	05.2011-
AUDI	Q7 3.0 TDi	[CRCA]	05.2011-08.2015
PORSCHE	Cayenne 3.0 D	[MCR.C]	06.2011-
PORSCHE	Cayenne 3.0 D	[MCR.CB]	06.2010-
PORSCHE	Cayenne 3.0 Diesel	[M05.9E]	01.2010-12.2011
PORSCHE	Cayenne 3.0 Diesel	[MCR.CA]	01.2011-
PORSCHE	Cayenne 3.0 Diesel	[MCR.CB]	01.2011-
PORSCHE	Panamera 3.0 Diesel	[MCR.CB]	01.2011-
VW	Touareg 3.0 TDi	[CASD]	01.2010-
VW	Touareg 3.0 TDi	[CJGD]	05.2011-
VW	Touareg 3.0 TDi	[CJMA]	01.2010-
VW	Touareg 3.0 TDi	[CRCA]	05.2011-
VW	Touareg 3.0 TDi	[CVWA]	01.2010-
VW	Touareg 3.0 TDi V6		01.2010-
VW	Touareg 3.0 V6 TDi	[CASA]	04.2010-
VW	Touareg 3.0 V6 TDi	[CNRB]	04.2010-
VW	Touareg 3.0 V6 TDi	[CVVA]	09.2014-

Alternatives >>>

S6156(DENSO) Genunie DENSO Version

Reference Information

AEY2581 S12DE0449A2 011-001-000879R ST01755 AC-CBS5930 DSN965 3117014 3117013 255121D 958604109X 10040307AV CST40307AS S12DE0449 10438779 RNL428000-7221 300.914.153.050 25-4253 STX210285R DENDSN965 ANM99563 IR8594 428000-7720 116000 5040588 UD11435S SDN307 RNL4280007221 WG1920251 AZMT-53-010-1492 11090305 300.914.153.460 300.914.153.461 S6156 300.914.153.260 STX210285 255121 LRS02581 STR6445 STN7720 STR70409 311277152 WOOSTR70409 12417 SG2112RB 95860410900 SG2112 ASM1641 059911024KX CST40307GS NPANSM1641 059911024K 20432703BN 19989N 20432703OE 428000-7224 A92240 108090 428000-7220 428000-7221 428000-7222 428000-7223 3388 221075A 88214405 LRS2581 10040307OV 6040307.1 6040307.0

Video/Publications

S6156
