Associated Numbers
0001121022 0001121023 02M911023 0986018920 101337 101337V 12064 17919N 20401023BN 20401023RC 22.1337 22.1337M 25-3129 3096 6010320 8018920 8212563 88212563 8EA738242-001 AES2242 CS1337 CST10320AS CST10320RS DRS8920 EAA-121592 LRT00242 S0119 SS393 STR50296
S0119 ASPLList
AES2242 AUTOELECTRO
0001121022 BOSCHList
0001121023 BOSCHList
0986018920 BOSCH
CST10320AS CASCO
CST10320RS CASCO
3096 CEVAM
DRS8920 DELCO
EAA121592 EAA
12064 EAI
253129 ELSTOCK
8018920 FRIESEN
CS1337 HC PARTS
8EA738242001 HELLA
22.1337 LAUBER
22.1337M LAUBER
LRT00242 LUCAS
8212563 POWERMAX
88212563 POWERMAX
20401023BN REAL
20401023RC REAL
6010320 SANDO
SS393 SOVEREIGN
02M911023 VW
17919N WAI / TRANSPO
STR50296 WOODAUTO
snb041
0001121022 Bosch
0001121023 Bosch
02M911023 VW
02M911EA VW
0986018920 Bosch ruil
11018920 EuroTec
120435 PIC
12064 EAI
17919 Lester
17919N WAI
17919R WAI
253129 Elstock
300548102 PSH
3872 CEVAM
4797SP Spidan
8018920F Friesen
918920 EDR
A18920 ATL
CS1337 HC
DRS8920 Remy
HCS1337 HC
LRT00242 Lucas
STM945 Rolling Compone
Arrowhead SBO0182
Beck Arnley 1870882
Bosch 0001121022, 0001121023, SR0830X
Delco DRS8920
Denso 2805359
Ford YM2111000EA
Lester 17919
Lucas LRT00242, LRT242
PIC Picture ID 120435
Remy Light Duty 17357
Volkswagen 02M911023, 02M911023X
Youtech/PartRef 422678
Wilson 91157212
S0119 ASPLList
AES2242 AUTOELECTRO
0001121022 BOSCHList
0001121023 BOSCHList
0986018920 BOSCH
CST10320AS CASCO
CST10320RS CASCO
3096 CEVAM
DRS8920 DELCO
EAA121592 EAA
12064 EAI
253129 ELSTOCK
8018920 FRIESEN
CS1337 HC PARTS
8EA738242001 HELLA
22.1337 LAUBER
22.1337M LAUBER
LRT00242 LUCAS
8212563 POWERMAX
88212563 POWERMAX
20401023BN REAL
20401023RC REAL
6010320 SANDO
SS393 SOVEREIGN
02M911023 VW
17919N WAI / TRANSPO
STR50296 WOODAUTO
Specifications
| Kilowatt | 1.1 kW |
| Length (L.1) | 232 mm |
| Mount Hole Center - Center (O.1) | 111 mm |
| Mount Hole Diameter (C.1) | 12 mm |
| Mount Hole Diameter (C.2) | 12 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 62 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | ACW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | TT 1.8 Turbo | [BVP] | 09.2005- |
| AUDI | TT 1.8 Turbo Quattro | [APX] | 05.2001- |
| AUDI | TT 1.8 Turbo Quattro | [ARY] | 10.1998- |
| AUDI | TT 1.8 Turbo Quattro | [AWP] | 02.2000- |
| AUDI | TT 1.8 Turbo Quattro | [BAM] | 05.2001- |
| AUDI | TT 3.2 VR6 Quattro | [BHE] | 07.2003- |
| SEAT | Alhambra 1.8 Turbo 20V | [AWC] | 06.2000- |
| SEAT | Alhambra 2.0 i | [ATM] | 06.2000- |
| SEAT | Leon 1.8 T 20V | 09.2005- | |
| SEAT | Leon 1.8 Turbo 20V | [AUQ] | 08.2001-04.2004 |
| SEAT | Leon 1.8 Turbo 20V 4 Syncro | [ARY] | 08.2001-04.2004 |
| SEAT | Leon 1.8 Turbo Cupra R | [AMK] | 05.2002-05.2003 |
| SEAT | Leon 1.8 Turbo Cupra R | [BAM] | 05.2003- |
| SEAT | Toledo 1.8 Turbo 20V | [AUQ] | 05.2001-05.2006 |
| SKODA | Octavia 1.8 Turbo | [ARX] | 08.2000-01.2006 |
| SKODA | Octavia 1.8 Turbo | [AUM] | 08.2000- |
| VW | Bora 1.8 Turbo | [AUQ] | 05.2002-05.2003 |
| VW | Golf IV 1.8 GTi Turbo | [AUQ] | 06.2001- |
| VW | New Beetle 1.8 | [AWU] | 10.2000- |
| VW | New Beetle 1.8 | [AWV] | 06.2000-06.2004 |
| VW | New Beetle 2.0 | [AZJ] | 01.2003- |
| VW | New Beetle 2.0 | [BDC] | 01.2003-06.2003 |
| VW | New Beetle 2.0 | [BGD] | 01.2003-06.2005 |
| VW | Sharan 1.8 Turbo 20V | [AWC] | 05.2000- |
| VW | Sharan 2.0 | [ATM] | 05.2000- |
Reference Information
S12BH0629A2 EAA-121592 YM2111000EA 88212563 DRS8920 STR1551 LRT00242 20401023BN ANM11140X CS1337 17919N 220213 MAV123200 0986018920 8212563 331460 STRS611 114174 S0119 25-3129 101337V SS393 STR50296 0001121022 0001121023 8EA738242-001 22.1337 02M911023 5010488 22.1337M CST10320RS 12064 20401023RC 8018920 CST10320AS 3096 AES2242 02M911023X STX200350 6010320 101337Video/Publications
