Associated Numbers
0001109417 0001218822 062911023 062911023X 0986023860 114304 254148 300.553.093 3111 6010380 6033AB1J00 88214286 BOS0001109417 CST10380 CST10380AS CST10380ES CST10380GS CST10380OS CST10380RS UD12950S00010EA6EE Bosch
0001109417 Bosch
0001218820 Bosch
0001218822 Bosch
062911023 PSH
0986023860 Bosch ruil
11090142 EuroTec
1206377A PIC
12090 EAI
253265 Elstock
300553093 PSH
32710 Lester
32710R WAI
6033AB1J00 Bosch
8080304F Friesen
910044 EDR
A77650 ATL
DRS0044 Remy
LRS01710 Lucas
UD12950S ASPL
0001109417 BOSCHList
0001218822 BOSCHList
0986023860 BOSCH
6033AB1J00 BOSCHList
114304 CARGO
CST10380 CASCO
3111 CEVAM
88214286 POWERMAX
300.553.093 PSH
6010380 SANDO
062911023 VW
062911023X VW
BOS0001109417 WOODAUTO
AEY1710 AUTOELECTRO
00010EA6EE BOSCH
0001218822 BOSCHList
6033AB1J00 BOSCHList
CST10380AS CASCO
CST10380GS CASCO
DRS0044 DELCO
EAA121180 EAA
253265 ELSTOCK
22.3088 LAUBER
22.3088M LAUBER
LRS01710 LUCAS
20401083BN REAL
20401083OE REAL
RNL218822 RNL
6010380 SANDO
SS373 SOVEREIGN
062911023 VW
062911023X VW
STR50461 WOODAUTO
Specifications
| Kilowatt | 2.3 kW |
| Length (L.1) | 246 mm |
| Mount Hole Center - Center (O.1) | 103 mm |
| Mount Hole Center - Center (O.2) | 146 mm |
| Mount Hole Center - Center (O.3) | 103 mm |
| Mount Hole Diameter (C.1) | 12 mm |
| Mount Hole Diameter (C.2) | 12 mm |
| Mount Hole Diameter (C.3) | 12 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 27 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 110 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VW | LT 28-35 2.8 TDi | [AGK] | 02.1997-12.1998 |
| VW | LT 28-35 2.8 TDi | [AGK] | 06.1997-12.1998 |
| VW | LT 28-35 2.8 TDi | [ATA] | 01.1999- |
| VW | LT 28-35 2.8 TDi | [AUH] | 04.2002- |
| VW | LT 28-35 2.8 TDi | [BCQ] | 04.2002- |
| VW | LT 28-35 2.8 TDi | [BCQ] | 05.2001-06.2006 |
| VW | LT 40-55 2.8 TDi | [AGK] | 06.1997-12.1998 |
| VW | LT 40-55 2.8 TDi | [ATA] | 01.1999- |
| VW | LT 40-55 2.8 TDi | [AUH] | 04.2002- |
| VW | LT 40-55 2.8 TDi | [BCQ] | 04.2002- |
Reference Information
88214286 93278011 6033AB1J00 5010438 BOS0001109417 114304 20401083BN CST10380AS 300.553.093.011 300.553.093.210 300.553.093.010 STX200262 9.0572E+11 STX200262R 300.553.093.211 20401083OE CGB-28820 0001109417 STR1667 EAA-121180 331204 S0588 6010380 DRS0044 32710R LRS1710 6010380.1 0001218822 STRL719 AEY1710 UD12950S STM764 12090 254148 25-3265 SS373 CST10380GS CGB-53265 22.3088 3111 062911023X PRSL719 RNL218822 S12BH0443A2 62911023 STB4822 22.3088M ANM12264X STR50461 00010EA6EE 0986023860 LRS01710Video/Publications
