Associated Numbers
06H903017E Volkswagen 06H903017EX 06H903023S 06H903023SX 06J903023N 06J903023NX 06J903023Q 06J903023QX 115547 Cargo 12090559 EuroTec 12090586 2015486 Sando 20154861 2113761402 DRI 224465 EAA 224475 224484 224538 224543 2543396A Valeo 2610087A 2610087D 2617852A 286621 Elstock 305574140 PSH 439725 show 439792 439851 440315 440429 440591 543396 57306 EAI 610087 617852 6H903023S 6H903023SX 6J903023Q 6J903023QX 9090708 Friesen 931186 EDR AL1746 AMK AVA486 AutoTeam DRA1186 Remy DRA1213 DRA1295 L51760 ATL LRA03511 Lucas LRA3511 NAL1890 Napa (UK) NAL1906 RNLTG14C019INA RNL TG14C017 TG14C019 TG14C037 TG14C055 06J903023R 06J903023RX 305911140 439831 440556 442299 617853 6J903023R 6J903023RX AEK3511 Auto Electro DRA1875 TG14C056 UD13577A ASPL AUTOELECTRO CARGO CAL15486 CASCO 4167 CEVAM DELCO A9591 DIXIE ELSTOCK LUCAS 89215745 POWERMAX 305.574.140 VALEO List VW UNIT BOM 2085086A WAI / TRANSPO 90225689 WILSON VALTG14C037 WOODAUTO 012067 Da Silva 11810N 14201271 AES 209227 Messmer 442590 Logistik 444495 Alanko 553578RI DAS 553578RIV 6H903017E 6H903017EX PowerMax A132101 Short code A147855 A158599 A3307 AS-PL A3307PR A3307S AA6511 Charge AA7326 AAL1890 Apec AL03123 TMI ALT14378 Wood ALT14524 ALT2330 Rolling Components ALT2330CP AVE1503 Everkraft AVE1506 AVE1510 Casco CAL15486GS DS012067 IR5719 Protech VAL439725 VAL439851 WOOALT14378 WOOALT14524Specifications
| Amp | 140 A |
| Diameter (D.1) | 9.5 mm |
| Diameter (D.2) | 9.5 mm |
| Diameter (D.3) | 9.5 mm |
| Diameter (D.4) | 9.5 mm |
| Length (L.1) | 189 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57 mm |
| OEM Product | Yes |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Product Line | Premium Line |
| Product Type | Brand New |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | CLUTCH |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | Q3 2.0 TFSi Quattro | [CCZC] | 01.2011- |
| AUDI | Q3 2.0 TFSi Quattro | [CPSA | 01.2011- |
| AUDI | Q3 2.0 TFSi Quattro | [CPSA] | 01.2011- |
| AUDI | TT 1.8 TFSi | [CDAA] | 01.2011- |
| AUDI | TT 1.8 TFSi | [CDAB] | 01.2011- |
| AUDI | TT 2.0 TFSi | [CESA] | 05.2010- |
| AUDI | TT 2.0 TFSi | [CETA] | 01.2011- |
| AUDI | TT 2.0 TFSi Quattro | [CESA] | 05.2010- |
| AUDI | TT 2.0 TFSi Quattro | [CETA] | 05.2010- |
| VW | Passat 1.8 TSi | [CDAA] | 01.2011- |
| VW | Passat 1.8 TSi | [CDAB] | 11.2008-05.2010 |
| VW | Passat 1.8 TSi | [CGYA] | 11.2008-05.2010 |
| VW | Passat 2.0 TSi | [CCZB] | 11.2010- |
| VW | Passat Alltrack 1.8 TSi | [CDAA] | 01.2012-12.2014 |
| VW | Passat CC 1.8 TSi | [CDAA] | 01.2011- |
| VW | Passat CC 1.8 TSi | [CDAB] | 01.2011- |
| VW | Passat CC 2.0 TSi | [CCZB] | 01.2011- |
Reference Information
|
012067 |
Da Silva |
|---|---|
|
06H903017E |
Volkswagen |
|
06H903017EX |
Volkswagen |
|
06H903023S |
Volkswagen |
|
06H903023SX |
Volkswagen |
|
06J903023N |
Volkswagen |
|
06J903023NX |
Volkswagen |
|
06J903023Q |
Volkswagen |
|
06J903023QX |
Volkswagen |
|
115547 |
Cargo |
|
11810N |
WAI |
|
12090559 |
EuroTec |
|
12090586 |
EuroTec |
|
14201271 |
AES |
|
2015486 |
Sando |
|
20154861 |
Sando |
|
209227 |
Messmer |
|
2113761402 |
DRI |
|
224465 |
EAA |
|
224475 |
EAA |
|
224484 |
EAA |
|
224538 |
EAA |
|
224543 |
EAA |
|
2543396A |
Valeo |
|
2610087A |
Valeo |
|
2610087D |
Valeo |
|
2617852A |
Valeo |
|
286621 |
Elstock |
|
305574140 |
PSH |
|
4167 |
CEVAM |
|
439725 |
Valeo |
|
439792 |
Valeo |
|
439851 |
Valeo |
|
440315 |
Valeo |
|
440429 |
Valeo |
|
440591 |
Valeo |
|
442590 |
Logistik |
|
444495 |
Alanko |
|
543396 |
Valeo |
|
553578RI |
DAS |
|
553578RIV |
DAS |
|
57306 |
EAI |
|
610087 |
Valeo |
|
617852 |
Valeo |
|
6H903017E |
Volkswagen |
|
6H903017EX |
Volkswagen |
|
6H903023S |
Volkswagen |
|
6H903023SX |
Volkswagen |
|
6J903023Q |
Volkswagen |
|
6J903023QX |
Volkswagen |
|
89215745 |
PowerMax |
|
9090708 |
Friesen |
|
931186 |
EDR |
|
A132101 |
Short code |
|
A147855 |
Short code |
|
A158599 |
Short code |
|
A3307 |
AS-PL |
|
A3307PR |
AS-PL |
|
A3307S |
AS-PL |
|
AA6511 |
Auto Charge |
|
AA7326 |
Auto Charge |
|
AAL1890 |
Apec |
|
AL03123 |
TMI |
|
AL1746 |
AMK |
|
ALT14378 |
Wood Auto |
|
ALT14524 |
Wood Auto |
|
ALT2330 |
Rolling Components |
|
ALT2330CP |
Rolling Components |
|
AVA486 |
AutoTeam |
|
AVE1503 |
Everkraft |
|
AVE1506 |
Everkraft |
|
AVE1510 |
Everkraft |
|
CAL15486 |
Casco |
|
CAL15486GS |
Casco |
|
DRA1186 |
Remy |
|
DRA1213 |
Remy |
|
DRA1295 |
Remy |
|
DS012067 |
Da Silva |
|
IR5719 |
Protech |
|
L51760 |
ATL |
|
LRA03511 |
Lucas |
|
LRA3511 |
Lucas |
|
NAL1890 |
Napa (UK) |
|
RNLTG14C019INA |
RNL |
|
TG14C017 |
Valeo |
|
TG14C019 |
Valeo |
|
TG14C037 |
Valeo |
|
TG14C055 |
Valeo |
|
VAL439725 |
Wood Auto |
|
VAL439851 |
Wood Auto |
|
VALTG14C037 |
Wood Auto |
|
WOOALT14378 |
Wood Auto |
|
WOOALT14524 |
Wood Auto |
