- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- < Critical Notes >
Associated Numbers
077903015Q 077903015QX 07C903021H 07C903021HX 11246N 11246R 2020229 28-5629 4665 553512RI 57264 89215347 90-25-1201 A-80205 A-80214 AEK3017 ALH9090 ALT32236 CAL20229 CAL20229AS CAL20229ES CAL20229GS CAL20229OS CAL20229RS DA1740 DRA0630 LR1190-901 LR1190-901B LR1190-901C LR1190-905 LR1190-905B LR1190-905C LRA03017 LRA3017
AEK3017 AUTOELECTRO
CAL20229 CASCO
4665 CEVAM
DA1740 DELCO
DRA0630 DELCO
A80205 DIXIE
A80214 DIXIE
57264 EAI
285629 ELSTOCK
LR1190901 HITACHI
LR1190901B HITACHI
LR1190901C HITACHI
LR1190905 HITACHI List
LR1190905B HITACHI
LR1190905C HITACHI
ALH9090 KRAUF
LRA03017 LUCAS
LRA3017 LUCAS
89215347 POWERMAX
077903015Q VW
077903015QX VW
07C903021H VW
07C903021HX VW
11246N WAI / TRANSPO
11246R WAI / TRANSPO
90251201 WILSON
ALT32236 WOODAUTO
077903015Q VW
07C903021H VW
205408190 PSH
285629 Elstock
57264 EAI
930630 EDR
DRA0630 Remy
LR1190901 Hitachi
LR1190901B Hitachi
LR1190901C Hitachi
LR1190905 Hitachi
LR1190905B Hitachi
LR1190905C Hitachi
LRA03017 Lucas
Specifications
| Amp | 190 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 201 mm |
| Mount Inside Length or Pad Mount C-C (C) | 60 mm |
| OEM Product | No |
| Plug Code | PL_2303 |
| Product Line | Premium Line |
| Product Type | Remanufactured |
| Pulley Grooves | 7 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 29.5 mm |
| Pulley Type | SOLID |
| Unit Type | HITACHI |
| Voltage | 12 V |
| Water Cooled | Yes |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A8 3.7 Quattro | [BFL] | 01.2002-12.2006 |
| AUDI | A8 4.2 Quattro | [BFM] | 01.2002-12.2006 |
| AUDI | A8 6.0 W12 Quattro | [BHT] | 01.2004- |
| AUDI | A8 6.0 W12 Quattro | [BTE] | 01.2004- |
| VW | Phaeton 4.2 V8 | [BGH] | 01.2003- |
| VW | Phaeton 4.2 V8 | [BGJ] | 01.2003- |
Reference Information
89215347 A12HT0733A2 077903015Q HAL1190901C AEK3017 LR1190-901B LR1190-901C LR1190-901 57264 LR1190-905B 2020229 LR1190-905C 553512RI 90-25-1201 LR1190-905 LRA3017 ALT222290 CAL20229ES CAL20229GS CAL20229AS 28-5629 HAL1190905C 4665 A-80205 11246R CAL20229OS ALH9090 11246N CGB-85629 PRAE024 07C903021H 077903015QX CAL20229RS STX110244 CAL20229 LRA03017 ALTE024HI DRA0630 DA1740 ALT32236 STX110244R ALT3007 ALTE024 442601 A-80214 07C903021HXVideo/Publications
A2101PR< Critical Notes >
THIS ALTERNATOR IS ON EXCHANGE BASIS
We will add a $50 core charge to your invoice and credit it once the core has been sent back
