Associated Numbers
Arrowhead SND0081
Denso 028000841, 0280008410, 0280008411, 1280002950, 9702889028
Honda 312002A1003, 31200ZA0701
Lester 18350
PIC Picture ID 190522
Stens 435090
Wilson 712918350, 91295397
J&N 41052100
Denso 0280008410, 0280008411, 1280002950, 9702889028
Honda 31200ZA10030, DB5D6
Lester 18350
PIC Picture ID 190522, 190522E
Arrowhead ND9702889028
J&N 41052100
Denso 0280008411
Honda 31200ZA1003RM
Wilson 91295397
Arrowhead SND0081
Denso 0280008410, 9702889028
Honda 31100ZA1003, 31200ZA1003, 31200ZA10030
Lester 18350
PIC Picture ID 190522
028000841 Denso
0280008410 Denso
0280008411 Denso
112246 Cargo
120021142 PSH
128000295 Denso
1280002950 Denso
1280005290 Denso
18350 Lester
18350N WAI
22641ND WAI
251113 Elstock
31200ZA0701 Honda
31200ZA1003 Honda
31200ZE8801 Honda
A90450 ATL
DB5X8 Honda
LRS01149 Lucas
SNJ308 SMX041 709075
Specifications
| Diameter (D.1) | 92 mm |
| Kilowatt | 0.6 kW |
| Length (L.1) | 193 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 14 qty |
| Pinion at Rest (B) | 8 mm |
| Pinion/Drive OD | 29.5 mm |
| Rotation | ACW |
| Unit Type | SMALL MOTOR( Briggs, Kohler, UT etc) |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | GX360 | ||
| HONDA | GX360K1 | ||
| HONDA | GX660K1 | 21.5H | |
| HONDA | GXV270 | 9 h | |
| HONDA | GXV340 | 11 h | |
| HONDA | GXV390 | 13H |
