- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001109403Associated Numbers
0001109403 0001109404 10879N 10879N-OS 116082 120-10225 20401665BN 220818 25-4497 255209B 6010566 68080460AA 68080460AB 830.928.102 91-15-7340 AEY3824 BOS0001109403 CST10566 CST10566AS CST10566ES CST10566GS CST10566OS CST10566RS DRS0932 EAA-122319 K68080460AA LRS03824 S-6324 STB9403 STR50678 UD11998S
SNB174 70-1714
Bosch 0001109404
References:
Bosch 0001109404
Chrysler 68080460AA
0001109403 Bosch
0001109404 Bosch
10879N WAI
10879NOS WAI
11090319 EuroTec
68080460AA Chrysler
830928102 PSH
910932 EDR
DRS0932 Remy
LRS03824 Lucas
Reference number (26)
UD11998S ASPL
AEY3824 AUTOELECTRO
0001109403 BOSCHList
0001109404 BOSCHList
116082 CARGO
CST10566 CASCO
CST10566AS CASCO
68080460AA CHRYSLER
68080460AB CHRYSLER
DRS0932 DELCO
S6324 DIXIE
EAA122319 EAA
254497 ELSTOCK
220818 ERA
K68080460AA FIAT
STB9403 KRAUF
LRS03824 LUCAS
830.928.102 PSH
20401665BN REAL
12010225 ROBERT'S
6010566 SANDO
10879N WAI / TRANSPO
10879NOS WAI / TRANSPO
91157340 WILSON
BOS0001109403 WOODAUTO
STR50678 WOODAUTO
Specifications
| Kilowatt | 1.7 kW |
| Length (L.1) | 241 mm |
| Mount Hole Center - Center (O.1) | 122 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 22 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | 300 C 3.0 CRD | [EXF] | 09.2011- |
| CHRYSLER | 300C 3.0 CRD | [EXF] | 09.2011- |
| DODGE | Ram 1500 3.0 V6 D | [EXF] | 01.2014- |
| JEEP | Grand Cherokee 3.0 CRD | [EXF] | 01.2011- |
| JEEP | Grand Cherokee 3.0 CRD V6 4x4 | [EXF] | 01.2011- |
| JEEP | Grand Cherokee 3.0 CRD V6 4x4 | [EXF] | 02.2011- |
| JEEP | Grand Cherokee 3.0 CRD V6 4x4 | [EXF] | 07.2013- |
| JEEP | Grand Cherokee 3.0 CRD V6 4x4 | [EXN] | 01.2011- |
| JEEP | Grand Cherokee 3.0 CRD V6 4x4 | [EXN] | 02.2011- |
| JEEP | Grand Cherokee 3.0 CRD V6 4x4 | [EXN] | 07.2013- |
| JEEP | Grand Cherokee 3.0 TD V6 4x4 | 04.2014- | |
| JEEP | Grand Cherokee 3.0 V6 CRD | [EXF] | 02.2011- |
| LANCIA | Thema 3.0 CRD | [EXF] | 01.2011- |
| LANCIA | Thema 3.0 D | [EXF] | 09.2011-10.2014 |
| LANCIA | Thema 3.0 V6 CRD | [EXF] | 09.2011- |
Reference Information
LRS3824 ANM99773 MAV125660A 830.928.102.280 IR1010 S12BH0957 SG2172 5010998G S0555 DRS0932 25-4497 10438611 10010566OV 3126362 STR10173 CH9064 255209S 331929 120-10225NOE S100256 BREF032116082 CMA-622319 S101585 91-15-7340 88214828 SBO566A F032116082 SBO566 116082 10010566AV STRF974 68080460AA BREF0321986S00747 68080460AB 42007001 ST01972 AC-CBS5951 220818 CST10566AS 662ST21 10879N STR50678 4799056 255209B 1986S00747 6010566.0 11090319 K68080460AA 6010566.1 670019102 LRS03824 WOOSTR50678 830.928.102.010 830.928.102.210 STB9403 STRF974B 20401665BN 20401665OE CST10566GS 3740 12662 UD11998S 0001109403 0001109404 255209Video/Publications
