Associated Numbers
0001109379 0001109380 0001109397 0001109398 08676896 0986025370 115588 12292 25-4356 254798 254798B 30268N 31327066 3399 36001408 6010533 810.531.122 AEY2684 BOS0001109397 CST10533 CST10533AS CST10533ES CST10533GS CST10533OS CST10533RS DRS0446 LRS02684 S0612S UD13018S
S0612S ASPLList
UD13018S ASPL
AEY2684 AUTOELECTRO
0001109379 BOSCHList
0001109380 BOSCH
0001109397 BOSCHList
0001109398 BOSCHList
0986025370 BOSCH
115588 CARGO
CST10533 CASCO
3399 CEVAM
DRS0446 DELCO
12292 EAI
254356 ELSTOCK
LRS02684 LUCAS
810.531.122 PSH
6010533 SANDO
08676896 VOLVO
31327066 VOLVO
36001408 VOLVO
30268N WAI / TRANSPO
BOS0001109397 WOODAUTO
0001109379 Bosch
0001109380 Bosch
0001109397 Bosch
0001109398 Bosch
08676896
0986025370 Bosch ruil
11025370 EuroTec
12292 EAI
30268N WAI
31327066 Volvo
36001122 Volvo
36001408 Volvo
810531122 PSH
910446 EDR
DRS0446 Remy
LRS02684 Lucas
STM1257 Rolling Components
S0612S ASPLList
UD13018S ASPL
AEY2684 AUTOELECTRO
0001109379 BOSCHList
0001109380 BOSCH
0001109397 BOSCHList
0001109398 BOSCHList
0986025370 BOSCH
115588 CARGO
CST10533 CASCO
3399 CEVAM
DRS0446 DELCO
12292 EAI
254356 ELSTOCK
LRS02684 LUCAS
810.531.122 PSH
6010533 SANDO
08676896 VOLVO
31327066 VOLVO
36001408 VOLVO
30268N WAI / TRANSPO
BOS0001109397 WOODAUTO
Specifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 245 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 1 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VOLVO | C30 2.0 D | [D5204T] | 10.2010- |
| VOLVO | C30 2.0 D | [D5204T5] | 10.2010- |
| VOLVO | C30 2.4 D D5 | [D5244T13] | 10.2006- |
| VOLVO | C30 2.4 D D5 | [D5244T8] | 10.2006- |
| VOLVO | C30 2.4 D D5 | [D5244T9] | 10.2006- |
| VOLVO | C70 2.0 D | [D5204T] | 10.2010- |
| VOLVO | C70 2.0 D | [D5204T5] | 10.2010- |
| VOLVO | S40 2.0 D D3 | [D5204T5] | 10.2010- |
| VOLVO | S40 2.0 D D4 | [D5204T] | 10.2010- |
| VOLVO | S60 2.0 D3 | [D5204T7] | 05.2012- |
| VOLVO | S60 2.0 D4 | [D5204T3] | 05.2012- |
| VOLVO | S60 2.0 D D3 | [D5204T2] | 04.2010-04.2012 |
| VOLVO | S60 2.0 D D3 | [D5204T3] | 04.2010-04.2012 |
| VOLVO | S60 2.4 D | [D5244T11] | 06.2011- |
| VOLVO | S60 2.4 D | [D5244T15] | 06.2011- |
| VOLVO | S60 2.4 D D5 | [D5244T10] | 04.2010- |
| VOLVO | S60 2.4 D D5 AWD | [D5244T10] | 04.2010- |
| VOLVO | S60 2.4 D D5 AWD | [D5244T15] | 06.2011- |
| VOLVO | S80 2.0 | [D5204T7] | 05.2012- |
| VOLVO | S80 2.0 D D3 | [D5204T2] | 01.2010- |
| VOLVO | S80 2.0 D D3 | [D5204T3] | 01.2010- |
| VOLVO | S80 2.4 D D5 | [D5244T10] | 01.2010- |
| VOLVO | S80 2.4 D D5 | [D5244T11] | 06.2011- |
| VOLVO | S80 2.4 D D5 | [D5244T15] | 06.2011- |
| VOLVO | S80 2.4 D D5 AWD | [D5244T10] | 01.2010- |
| VOLVO | S80 2.4 D D5 AWD | [D5244T15] | 06.2011- |
| VOLVO | V50 2.0 D D3 | [D5204T5] | 10.2010- |
| VOLVO | V50 2.0 D D4 | [D5204T] | 10.2010- |
| VOLVO | V60 2.0 D3 | [D5204T7] | 12.2012- |
| VOLVO | V60 2.0 D D3 | [D5204T2] | 09.2010- |
| VOLVO | V60 2.0 D D3 | [D5204T3] | 09.2010- |
| VOLVO | V60 2.4 D5 | [D5244T17] | 12.2012- |
| VOLVO | V60 2.4 D AWD | [D5244T11] | 06.2011- |
| VOLVO | V60 2.4 D AWD | [D5244T12] | 10.2013- |
| VOLVO | V60 2.4 D D5 | [D5244T10] | 09.2010- |
| VOLVO | V60 2.4 D D5 | [D5244T11] | 06.2011- |
| VOLVO | V60 2.4 D D5 AWD | [D5244T10] | 09.2010- |
| VOLVO | V70 2.0 | [D5204T7] | 03.2010- |
| VOLVO | V70 2.0 D D5 AWD | [D5204T3] | 03.2010-07.2011 |
| VOLVO | V70 2.4 4x4 | [D5244T17] | 01.2013- |
| VOLVO | V70 2.4 D | [D5244T10] | 12.2009- |
| VOLVO | V70 2.4 D | [D5244T14] | 10.2009-07.2010 |
| VOLVO | V70 2.4 D AWD | [D5244T10] | 12.2009- |
| VOLVO | V70 2.4 D AWD | [D5244T12] | 10.2013- |
| VOLVO | V70 2.4 D D5 | [D5244T11] | 06.2011- |
| VOLVO | V70 2.4 D D5 | [D5244T15] | 06.2011- |
| VOLVO | V70 2.4 D D5 AWD | [D5244T11] | 06.2011- |
| VOLVO | V70 2.4 D D5 AWD | [D5244T15] | 06.2011- |
| VOLVO | XC60 2.0 | [D5204T7] | 04.2012- |
| VOLVO | XC60 2.0 D DRIVe | [D5204T2] | 03.2010- |
| VOLVO | XC60 2.0 D DRIVe | [D5204T3] | 03.2010- |
| VOLVO | XC60 2.4 D | [D5244T11] | 06.2011- |
| VOLVO | XC60 2.4 D | [D5244T16] | 05.2008- |
| VOLVO | XC60 2.4 D AWD | [D5244T12] | 10.2013- |
| VOLVO | XC60 2.4 D D5 AWD | [D5244T11] | 06.2011- |
| VOLVO | XC60 2.4 D D5 AWD | [D5244T23] | 04.2014- |
| VOLVO | XC60 2.4 D DRIVe | [D5244T14] | 07.2009- |
| VOLVO | XC60 2.4 D SUV | [D5244T17] | 05.2008- |
| VOLVO | XC60 2.4 D SUV | [D5244T5] | 05.2008- |
| VOLVO | XC70 2.0 D | [D5204T2] | 08.2011- |
| VOLVO | XC70 2.0 D | [D5204T3] | 08.2011- |
| VOLVO | XC70 2.0 D AWD | [D5204T2] | 08.2011- |
| VOLVO | XC70 2.4 D AWD | [D5244T12] | 10.2013- |
| VOLVO | XC70 2.4 D AWD | [D5244T16] | 08.2007- |
| VOLVO | XC70 2.4 D AWD | [D5244T17] | 08.2007- |
| VOLVO | XC70 2.4 D AWD | [D5244T5] | 08.2007- |
| VOLVO | XC70 2.4 D D5 AWD | [D5244T11] | 06.2011- |
| VOLVO | XC70 2.4 D D5 AWD | [D5244T15] | 06.2011- |
Reference Information
BOS0001109397 12292 AEY2684 STR1531 S0612S CST10533 25-4356 STX200896R 36001122 0986025370 CST10533GS 3399 0001109397 31327066 0001109398 RNL109397 0001109379 CST10533OS 6010533 36001408 254798B UD13018S 5010542 810.531.122 115588 CST10533ES CST10533AS S12BH0743 STRL691 ANM12666X 254798 0001109380 30268N LRS02684 DRS0446 S12BH0743A2 CST10533RS 8676896 LRS2684 STX200896Video/Publications
