Associated Numbers
021080-0230 021080-0231
UD13827A ASPLList
AEG1265 AUTOELECTRO
CAL40400 CASCO
DRA1577 DELCO
1042106420 DENSOList
1042106421 DENSO
DAN1112 DENSO
A80660 DIXIE
287719 ELSTOCK
209437 ERA
ALN0459 KRAUF
LRA04110 LUCAS
455.535.180 PSH
CPLA10300AB ROVER
CPLA10300AC ROVER
LR034013 ROVER
LR054994 ROVER
2040400 SANDO
DENDAN1112 WOODAUTO
1042106420 Denso
1042106420OR
1042106421 Denso
12090752 EuroTec
287719 Elstock
455535180 PSH
CPLA10300AB Ford
DAN1112 Denso
DRA1577 Remy
LR034013 Rover Group
LR054994 Rover Group
LR072764 Rover Group
104210-6420 104210-6421 2040400 209437 28-7719 455.535.180 554843RI A-80660 AEG1265 ALN0459 CAL40400 CAL40400AS CAL40400ES CAL40400GS CAL40400OS CAL40400RS CPLA-10300-AB CPLA-10300-AC DAN1112 DENDAN1112 DRA1577 LR034013 LR054994 LRA04110 UD13827A
Specifications
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 46.2 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 11.5 mm |
| Diameter (D.3) | 12.5 mm |
| Length (L.1) | 204 mm |
| Mount Inside Length or Pad Mount C-C (C) | 48 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 50 mm |
| Pad mount thickness (E.2) | 50 mm |
| Pad mount thickness (E.3) | 50 mm |
| Plug Code | PL_2305 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 22 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LAND ROVER | Discovery 3.0 4x4 | [306PS] | 08.2013- |
| LAND ROVER | Discovery 3.0 4x4 | [306PS] | 09.2016- |
| LAND ROVER | Discovery 3.0 4x4 | [30HD0D] | 08.2013- |
| LAND ROVER | Range Rover 3.0 4x4 | [30HD0D] | 06.2015- |
| LAND ROVER | Range Rover 3.0 4x4 | [30HD0D] | 10.2013- |
| LAND ROVER | Range Rover 5.0 4x4 | [508PN] | 12.2013- |
| LAND ROVER | Range Rover 5.0 4x4 | [508PS] | 06.2015- |
| LAND ROVER | Range Rover 5.0 4x4 | [508PS] | 08.2012- |
| LAND ROVER | Range Rover Sport 3.0 4x4 | [30HD0D] | 04.2013- |
| LAND ROVER | Range Rover Sport 3.0 4x4 | [30HD0D] | 06.2015- |
| LAND ROVER | Range Rover Sport 5.0 4x4 | [508PS] | 04.2013- |
| LAND ROVER | Range Rover Sport 5.0 4x4 | [508PS] | 09.2014- |
Alternatives >>>
UD804951(DENSO)A - Genuine Denso Version
Reference Information
LR034013 CPLA-10300-AC CPLA-10300-AB DAN1112 A-80660 455.535.180.260 20132004OE 2040400.1 A12DE0894AS LR072764 5540866 104210-6421 104210-6420 PRAE489 20132004BN DENDAN1112 455.535.180.058 UD13827A CAL40400GS LRA4110 455.535.180.054 554843RI 2040400 455.535.180.050 209437 ALN0459 14016N ALT2372CP CAL40400AS 14016-OS LR054994 AEG1265 LRA04110 021080-0230 446589 28-7719 DRA1577 ALT6730 ALTE489Video/Publications
