Associated Numbers
AEY1728 AUTOELECTRO
0986019200 BOSCH
CST15118 CASCO
3113 CEVAM
DRS0398 DELCO
DS1508 DELCO
S6558 DIXIE
12154 EAI
253285 ELSTOCK
220428 ERA
STV4760 KRAUF
LRS1728 LUCAS
88214164 POWERMAX
300.579.093 PSH
6015118 SANDO
438161 VALEOList
458181 VALEOList
D7G6 VALEOList
079911023C VW
079911023D VW
079911023DX VW
UNIT BOM 108478 WAI / TRANSPO
91203543 WILSON
VAL438161 WOODAUTO
Bosch SR9500X
Remy Light Duty 16070
Valeo 438161
Wilson 91203543
References:
Beck Arnley 1870865
Bosch 0986018200, 1920, SR9500X
Lester 17887
Lucas LRS01728, LRS1728
Paris Rhone D7G6
PIC Picture ID 108464, 108478
Remy Light Duty 16070
Valeo 191143, 438161, 458161, A191143, D7G6, G7GP21
Volkswagen 077911023D, 079911023C, 079911023D
Youtech/PartRef 419724
Wilson 91203543
&N 41040051
Wilson 91203543
References:
Arrowhead BSR9500X
J&N 41040051
Audi 079911023D, 079911023DX
Valeo 191143, 438161, 458181, A191143, D7G6
Volkswagen 079911023DX
J&N 41040051
References:
J&N 41040051
Bosch SR9500X
Lester 17887
PIC Picture ID 108464, 108478
Valeo D7G6
Substitutes:
J&N 41040051
Bosch SR9500X
References:
Arrowhead V438161
J&N 41040051
Bosch 0001110029, 0001110030, 0986019200
Delco DRS3806
Lester 17887
Paris Rhone D7G6
Valeo 191143, 458181, D7G6
Volkswagen 077911023C, 077911023CX, 079911023D
0001110029 Bosch
0001110030 Bosch
077911023C VW
077911023CX VW
079911023C VW
079911023D VW
079911023DX VW
0986019200 Bosch ruil
11019200 EuroTec
11090177 EuroTec
11677 EAI
120198 PIC
12154 EAI
17226 Lester
191143 Valeo
253285 Elstock
263056 Elstock
300564092 PSH
300579093 PSH
438161 Valeo
4437SP Spidan
458181 Valeo
8080101 Friesen
8080101F Friesen
8080175 Friesen
910398 EDR
91156962 Wilson
913806 EDR
A19200 ATL
A19205 ATL
CAR10168PS Casco
CS985 HC
CST15118GS Casco
D7G6 Valeo
D7GP21 Valeo
DRS0398 Remy
DRS3806 Remy
HCS985 HC
LES0239 Lucas
LRS01728 Lucas
LRS01795 Lucas
STR00108sa Electrolog
S3168S
Specifications
Product features:
| Voltage [ V ] | 12 |
| Power [ kW ] | 1.70 |
| Rotation | CW |
| Size A [ mm ] | 76.00 |
| Size B [ mm ] | 23.00 |
| No./teeth [ szt ] | 9 |
| No./teeth (fits into) [ szt ] | 9 |
| No./mount. holes [ szt ] | 3 |
| No./mount. holes with thread [ szt ] | 2 |
| L.1 [ mm ] | 217.00 |
| O.1 [ mm ] | 36.00 |
| O.2 [ mm ] | 101.00 |
| O.3 [ mm ] | 102.00 |
| C.1 [ mm ] | M8x1.25 |
| C.2 [ mm ] | 12.50 |
| C.3 [ mm ] | 10.50 |
| Kilowatt | 1.7 kW |
| Length (L.1) | 215.5 mm |
| Mount Hole Center - Center (O.1) | 36 mm |
| Mount Hole Center - Center (O.2) | 101 mm |
| Mount Hole Center - Center (O.3) | 101 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| Mount Hole Diameter (C.3) | M12x1.75 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| OEM Product | Yes |
| Pinion at Rest (B) | 23 mm |
| Product Line | Premium Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A6 4.2 FSi Quattro | [BVJ] | 05.2006-12.2010 |
| AUDI | A6 4.2 FSi Quattro | [BVJ] | 06.2006-03.2011 |
| AUDI | A6 4.2 FSi Quattro | [BVJ] | 06.2006-08.2011 |
| AUDI | A6 4.2 Quattro | [BAT] | 03.2005-05.2006 |
| AUDI | A6 4.2 Quattro | [BAT] | 05.2004-05.2006 |
| AUDI | A8 4.2 FSi Quattro | [BVJ] | 06.2006-07.2010 |
| AUDI | RS4 4.2 Quattro | [BNS] | 06.2006-03.2009 |
| AUDI | RS4 4.2 Quattro | [BNS] | 09.2005-06.2008 |
| AUDI | S4 4.2 Quattro | [BBK] | 03.2003-12.2004 |
| AUDI | S4 4.2 Quattro | [BBK] | 03.2004-03.2009 |
| AUDI | S4 4.2 Quattro | [BBK] | 11.2004-06.2008 |
| AUDI | S4 4.2 V8 Quattro | [ABH] | 10.1992-07.1994 |
| AUDI | S6 4.2 Plus Quattro | [AHK] | 04.1996-10.1997 |
| AUDI | S6 4.2 Plus Quattro | [AHK] | 04.1996-12.1997 |
| AUDI | S6 4.2 Quattro | [AEC] | 06.1994-10.1997 |
| AUDI | S6 4.2 Quattro | [AEC] | 06.1994-12.1997 |
| AUDI | V8 3.6 Quattro | [PT] | 04.1993-02.1994 |
| AUDI | V8 3.6 Quattro | [PT] | 10.1988-02.1994 |
| AUDI | V8 4.2 Quattro | [ABH] | 10.1991-02.1994 |
Reference Information
STX210282 STV4760 12154 20479811OE 6015118.1 300.579.093.500 AEY1728 S12VA0253 300.579.093.000 LRS1728 3113 438161 077911023CX LRS01728 DRS0398 25-3285 D7G6 17887R 91-20-3543 220428 17887N 300.579.093 254890V G7GP21 S-6558 D7GP21 79911023D CST15118GS 079911023DX 458181 077911023C UD800048(VALEO)S STX210282R 079911023C STR00108 S12VA0253A2 077911023D 079911023DVideo/Publications
