S0005 - Brand new AS-PL Starter motor

Name: Brand new AS-PL Starter motor
Brand: AS-PL
SKU: S0005
Price: 237.02 NZD
Availability: InStock

Brand new AS-PL Starter motor

STANDARD LINE

Manufacturer:

AS-PL

Replacement For:

BOSCH

Price:

NZ$ 237.02 including GST

NZ$ 206.10 excluding GST

or four payments of $59.26 with
Learn More

UOM:

each

Alternative Item:

S3026

Product Code:

S0005

Quantity In Stock Nationally:

Associated Numbers
Specifications
Vehicle Applications
Reference Information
Video/Publications

WAI New 17750N Old 2-1531-BO To Be Superseded 17231N 17231R ACE Zorkos CM17231N Alltech 111-17231 American Power Systems APS17231 Andre Niermann 01110061 ARC S1930 Armature G Roy 17231 Arrow Automotive Industries 35-2539 Atelier Dynamo S17231 Audi Volkswagen 02B-911-023C 02B-911-023CX Auto Electric Suppliers Autoelectro AES1233 AES9164 Beck Arnley Remanufactured 187-0508 Bepco 80-17231 Bosch 0 001 110 061 062 SR0404X Service Europe 986 016 190 197 601 699 Casco CST10211AS CPC CPI KIT Delphi SX3214 DNS DRI A/S Denmark 311041102 EGI S-17231 Elpar 0104036353 ERA 220054 220085 Excel 21142 Expom ER-316 HC Parts CS598 Hella 8EA 726 221-001 222-001 Knight Rebuilding S6287 Lester Letrika (Iskra) Sales IS 1042 Tech. AZE2625 Lucas Electrical LRS00964 Elektrik LES0269 S7261 Mahle MS 384 Marelli 943251225010 944280161900 Metro Industrial 172310 Metron Minnpar 57-3604 6883604 Mondial 70-212-40 70-212-40N Nastra Tech N17231 Our Part Number # PASCO S-300214 Select Powerite Precision Remanufacturing BOS440 Quality Rebuilders Raw Rayloc 4460002 Reliance 61461 Road Warrior Rotex Sovereign SS359 Stratoline Suncoast Techno CVC IMP-S1930 TSA UCP USA Valeo 455628 Wood Supplies STR2205 Zorko 0001110061 show 0001110062 028911023C VW 02B911023C 02B911023CX 0986016190 ruil 108288 PIC 11016190 EuroTec 112167 Cargo 11718 EAI 120214 1456 1456SP Spidan 251311 Elstock 300512103 PSH 3325 CEVAM 3812 726991 8016190F Friesen 91156988 Wilson 91157118N A16190 ATL DRS6190 Remy HCS598 S27009 Hitachi Unipoint ARROWHEAD SBO0032 BOSCH 0001124005 0001124006 0001125001 0001125002 0001125011 0001125031 0001125032 0986016197 DAF1516812R DELCO 438077 70-1086 SNB5031 LESTER 17750 LUCAS ELECTRIC LRS964 MAGNETON 443-115-141-319 9141319 MAHLE 11.131.056 IS1042 MS0384 MS384 MARELLI 943251225 943251228 MSR658 MSR766 VALEO 458041 D7R131 D7RS131 D7RS31 VS507 VOLKSWAGEN 02A911-303B 02B911-023AX 02B911-023B 02B911-023BX 02B911-023C 02B911-023CX 02B911-023D 02B911-023DX 02B911-023J 02B911-023L 02B911-023LX 02B911-023N 02B911-023NX BXS0177

Kilowatt	2 kW
Length (L.1)	235 mm
Mount Hole Center - Center (O.1)	101.5 mm
Mount Hole Center - Center (O.2)	101.5 mm
Mount Hole Center - Center (O.3)	106.5 mm
Mount Hole Diameter (C.1)	9 mm
Mount Hole Diameter (C.2)	9 mm
Mount Hole Diameter (C.3)	9 mm
No./Mount holes	3 qty
No./Mount holes with thread	0 qty
No./Teeth	10 qty
No./Teeth (Replaces)	10. 11 qty
OEM Product	No
Pinion at Rest (B)	53 mm
Product Line	Standard Line
Product Type	Brand new
Rotation	ACW
Spigot Diameter (A)	76 mm
Unit Type	BOSCH
Voltage	12 V

Make	Model	Type	Year
VW	California T4 2.4 D	[AJA]	05.1998-04.2002
VW	California T4 2.5	[AEU]	05.1998-04.2002
VW	Eurovan 2.4	[AAB]	01.1993-01.1996
VW	Eurovan 2.4 Camper	[AAB]	01.1995-
VW	Eurovan 2.4 CL	[AAB]	01.1993-
VW	Eurovan 2.4 GL	[AAB]	01.1993-
VW	Multivan 2.5	[AET]	08.1996-04.2003
VW	Multivan 2.5	[APL]	08.1996-
VW	Multivan 2.5	[AVT]	08.1996-
VW	Transporter 1.9 D	[1X]	07.1990-12.1995
VW	Transporter 1.9 D	[1X]	09.1990-12.1995
VW	Transporter 1.9 TD	[ABL]	10.1992-04.2003
VW	Transporter 2.4 D	[AAB]	09.1990-04.1998
VW	Transporter 2.4 D	[AJA]	08.1997-04.2003
VW	Transporter 2.4 D Syncro	[AAB]	10.1992-09.1998
VW	Transporter 2.5	[ACU]	11.1990-03.2004
VW	Transporter 2.5	[ACU]	11.1990-04.2003
VW	Transporter 2.5	[AEN]	11.1990-03.2004
VW	Transporter 2.5	[AEN]	11.1990-04.2003
VW	Transporter 2.5	[AET]	08.1996-03.2004
VW	Transporter 2.5	[AEU]	11.1990-03.2004
VW	Transporter 2.5	[AEU]	11.1990-04.2003
VW	Transporter 2.5	[APL]	08.1996-03.2004
VW	Transporter 2.5	[AVT]	08.1996-03.2004
VW	Transporter 2.5 Syncro	[ACU]	10.1992-03.2004
VW	Transporter 2.5 Syncro	[ACU]	10.1992-04.2003
VW	Transporter 2.5 Syncro	[ACU]	11.1992-04.2003
VW	Transporter 2.5 Syncro	[AEN]	09.1995-12.1995
VW	Transporter 2.5 Syncro	[AET]	07.1996-04.2003
VW	Transporter 2.5 Syncro	[AET]	08.1996-03.2004
VW	Transporter 2.5 Syncro	[AEU]	10.1992-03.2004
VW	Transporter 2.5 Syncro	[APL]	07.1996-04.2003
VW	Transporter 2.5 Syncro	[APL]	08.1996-
VW	Transporter 2.5 Syncro	[APL]	08.1996-03.2004
VW	Transporter 2.5 Syncro	[AVT]	07.1996-04.2003
VW	Transporter 2.5 Syncro	[AVT]	08.1996-
VW	Transporter 2.5 Syncro	[AVT]	08.1996-03.2004
VW	Transporter 2.5 TD	[AJT]	05.1998-04.2003
VW	Transporter 2.5 TD	[AYY]	05.1998-04.2003
VW	Transporter 2.5 TDi	[ACV]	09.1995-03.2004
VW	Transporter 2.5 TDi	[ACV]	09.1995-04.2003
VW	Transporter 2.5 TDi	[AHY]	05.1998-03.2004
VW	Transporter 2.5 TDi	[AJT]	05.1998-03.2004
VW	Transporter 2.5 TDi	[AUF]	09.1995-03.2004
VW	Transporter 2.5 TDi	[AUF]	09.1995-04.2003
VW	Transporter 2.5 TDi	[AXG]	09.2000-04.2003
VW	Transporter 2.5 TDi	[AYC]	09.1995-03.2004
VW	Transporter 2.5 TDi	[AYC]	09.1995-04.2003
VW	Transporter 2.5 TDi	[AYY]	05.1998-03.2004
VW	Transporter 2.5 TDi	[AYY]	12.1998-04.2003
VW	Transporter 2.5 TDi Syncro	[ACV]	01.1996-03.2004
VW	Transporter 2.5 TDi Syncro	[ACV]	05.1998-04.2003
VW	Transporter 2.5 TDi Syncro	[ACV]	09.1995-04.2003
VW	Transporter 2.5 TDi Syncro	[AXL]	01.1996-03.2004
VW	Transporter 2.5 TDi Syncro	[AXL]	05.1998-
VW	Transporter 2.8	[AES]	05.1996-05.2000
VW	Transporter 2.8 VR6	[AES]	11.1995-04.2000
VW	Transporter T4 1.9 D	[1X]	07.1990-12.1995
VW	Transporter T4 1.9 D	[1X]	09.1990-12.1995
VW	Transporter T4 1.9 TD	[ABL]	10.1992-04.2003
VW	Transporter T4 2.4 D	[AAB]	07.1990-04.1998
VW	Transporter T4 2.4 D	[AAB]	09.1990-04.1998
VW	Transporter T4 2.4 D	[AJA]	08.1997-04.2003
VW	Transporter T4 2.4 D Syncro	[AAB]	10.1992-09.1998
VW	Transporter T4 2.5	[AAF]	09.1990-06.2003
VW	Transporter T4 2.5	[AAF]	11.1990-04.2003
VW	Transporter T4 2.5	[ACU]	09.1990-06.2003
VW	Transporter T4 2.5	[ACU]	11.1990-04.2003
VW	Transporter T4 2.5	[AEN]	09.1990-06.2003
VW	Transporter T4 2.5	[AEN]	11.1990-04.2003
VW	Transporter T4 2.5	[AET]	08.1996-04.2003
VW	Transporter T4 2.5	[AEU]	09.1990-06.2003
VW	Transporter T4 2.5	[AEU]	11.1990-04.2003
VW	Transporter T4 2.5	[APL]	08.1996-04.2003
VW	Transporter T4 2.5	[AVT]	08.1996-04.2003
VW	Transporter T4 2.5 Syncro	[AAF]	08.1992-04.2003
VW	Transporter T4 2.5 Syncro	[AAF]	11.1992-11.2001
VW	Transporter T4 2.5 Syncro	[ACU]	08.1992-04.2003
VW	Transporter T4 2.5 Syncro	[ACU]	11.1992-11.2001
VW	Transporter T4 2.5 Syncro	[AET]	07.1996-04.2003
VW	Transporter T4 2.5 Syncro	[AET]	08.1996-04.2003
VW	Transporter T4 2.5 Syncro	[AEU]	08.1992-04.2003
VW	Transporter T4 2.5 Syncro	[AEU]	11.1992-11.2001
VW	Transporter T4 2.5 Syncro	[APL]	07.1996-04.2003
VW	Transporter T4 2.5 Syncro	[APL]	08.1996-04.2003
VW	Transporter T4 2.5 Syncro	[AVT]	07.1996-04.2003
VW	Transporter T4 2.5 Syncro	[AVT]	08.1996-04.2003
VW	Transporter T4 2.5 TDi	[ACV]	09.1995-04.2003
VW	Transporter T4 2.5 TDi	[AHY]	05.1998-04.2003
VW	Transporter T4 2.5 TDi	[AHY]	09.2000-04.2003
VW	Transporter T4 2.5 TDi	[AJT]	05.1998-04.2003
VW	Transporter T4 2.5 TDi	[AJT]	12.1998-04.2003
VW	Transporter T4 2.5 TDi	[AUF]	09.1995-04.2003
VW	Transporter T4 2.5 TDi	[AXG]	05.1998-04.2003
VW	Transporter T4 2.5 TDi	[AXG]	09.2000-04.2003
VW	Transporter T4 2.5 TDi	[AYC]	09.1995-04.2003
VW	Transporter T4 2.5 TDi	[AYY]	05.1998-04.2003
VW	Transporter T4 2.5 TDi	[AYY]	12.1998-04.2003
VW	Transporter T4 2.5 TDi Syncro	[ACV]	01.1996-04.2003
VW	Transporter T4 2.5 TDi Syncro	[ACV]	05.1998-04.2003
VW	Transporter T4 2.5 TDi Syncro	[ACV]	09.1995-04.2003
VW	Transporter T4 2.5 TDi Syncro	[AXL]	01.1996-04.2003
VW	Transporter T4 2.5 TDi Syncro	[AXL]	05.1998-04.2003
VW	Transporter T4 2.5 TDi Syncro	[AXL]	09.1995-04.2003
VW	Transporter T4 2.8	[AES]	05.1996-05.2000
VW	Transporter T4 2.8 VR6	[AES]	05.1996-05.2000
VW	Transporter T4 2.8 VR6	[AES]	11.1995-04.2000
VW	Transporter T4 2.8 VR6	[AMV]	04.2000-04.2003
VW	Transporter T4 2.8 VR6	[AMV]	06.2000-04.2003
VW	Transporter T4 2.8 VR6	[AXK]	04.2000-04.2003
VW	Transporter T4 2.8 VR6	[AXK]	06.2000-04.2003

MAV3450 4.43115E+11 STR79122 STR2027 6.0004.9 300.522.103.211 726018 1986S00808 10010101AV 20401101OE PRSS720 300.522.103.210 2B911023DV BST2148 VW9010 220085 6010101.1 2B911023DX 113387 STR0085 13883 910001EGT 17750N STR10251 2B911023LX 193167 CS801 TT15561 20510133 MAHMS384 2B911023D LRT00133 330953 S12VA0058 NES1233 20500964 STR50004 CST10101GS 0001124005 02A911303B IS1042 0001124006 20479112OE STB0801 WG2196563 0001125031 CGB-52167 EAA-121032 WOOSTR50004 103551 0001125032 CGB-26990 220054A 1638120080 BST2173 99831 DRS6990N DSN3016 63720801010 STV0801 2B911023L 028911023M QRS1968 STX200001 2B911023N 8EA011611-051 MAV172110 MAV123270 0001110061 63521250310 2B911023J 220054R 10010101OV MSR766 2B911023NX LRT133 10598 AZE2625 S-6199 300.522.103.505 ST00831 11016990 S1046B D7RS31 AZMT-53-010-1107 IR8457 S12BH0058A2 02B911023NX MS384 300.522.103.500 300.522.103.460 F032113387 300.522.103.340 300.522.103.461 5010020 460530 S0005 25-2167 726818 10801 S12BH0058 438077 6015211.1 D7RS131 06-10012-SX SBO101 191655 DS8100 STRL118 10801V RE81004N STR1256 300.522.103.018 0001125011 88212186 STR50619 RNL1699 300.522.103.010 CST10101AS 3116723 300.522.103.260 CST15211GS 10801B WG2045151 1516812R 10801D 11.131.056 ANM19210X A16990 20401101BN 3834 AC-CBS0801 02B911023DV WG2194573 300.522.103.006 02B911023DX SVA211 20479112BN 805ST11 0986016990 MQS801 300.522.103.000 9.4428E+11 02B911023LX 10441205 011-001-000012R STRS720 12108872 458041 LES0286 STX200001R 6010101 311061102 MAV3110 8016990 72736012 02B911023J PRSL118 02B911023N 02B911023L S-50004 STM523 300.522.103.280 WG2012715 11805 WG2012714 02B911023D CST15211AS SBO101A MRS16990 SG0019 DRS6990 STA0165R 0001125001 0001125002 02B911023JX EZ0367 42016990 6015211 220054 3116719 3116718 3116717

S0005
