Associated Numbers
0124425059 0124425097 0986080380 114088 1202116 1204427 13229992 13308508 13308508CY 135.560.140 20101623 2010326 210689 23817N 23817R 28-5656 301994RI 301994RIB 32080370 32081410 4748 57176 6204279 89212910 8EL012428-441 8EL738212-191 93191922 95520016 A0215 AEK3045 AG0133 ALB1994 ALT10573 ALT495CP BOS0124425097 CA1994IR CAL10326 CAL10326AS CAL10326ES CAL10326GS CAL10326OS CAL10326RS DA1328 DRA0218 EAA-221063 GA425059-A LRA03045 RAA11329
6584821 658482-1 anb5097 bxa060 dxa563
0124425059 Bosch show
0124425059OR +line
0124425097 Bosch show
0986080380 Bosch ruil
114088 Cargo
1202116 Opel
1204427 Opel
12044710 EuroTec
12048800 EuroTec
12090284 EuroTec
13229992 Opel
13308508 Opel
13308508CY Opel
135560140 PSH
2205614 PIC
2281751402 DRI
23817 Lucas
285656 Elstock
4748 CEVAM
57176 EAI
6204279 Opel
6445SP Spidan
8EL738212191 Hella
9090534 Friesen
9090534F Friesen
930218 EDR
93191922 Opel
95520016 Opel
ALTH190 Unipoint
CA1994IR HC
DRA0218 Remy
F042A0H190 Bosch
HCA1994IR HC
L82755 ATL
LRA03045 Lucas
LRA3045 Lucas
OAN12359 Optimum
SP6445 Spidan
0124425058 Bosch
0124425058OR +line
0124425096 Bosch
0986048791 Bosch ruil
0986080370 Bosch ruil
1202115 Opel
12048790 EuroTec
12048800 EuroTec
12090151 EuroTec
12090284 EuroTec
13229991 Opel
13308507
135560120 PSH
2205614A PIC
285737 Elstock
57175 EAI
6204278 Opel
6496SP Spidan
9090325F Friesen
9090533F Friesen
930437 EDR
93191921 Opel
CA2045IR HC
DRA0437 Remy
H648643C Valeo
HCA2045IR HC
L82745 ATL
LRA03125 Lucas
OAN12403 Optimum
UD16475A AS-PL
0124425058 BOSCHList
0124425096 BOSCHList
0986080370 BOSCH
114510 CARGO
CAL10334 CASCO
CAL10334AS CASCO
CAL10334ES CASCO
CAL10334GS CASCO
CAL10334OS CASCO
CAL10334RS CASCO
4744 CEVAM
DA1547 DELCO
DRA0437 DELCO
RAA11548 DELCO
EAA-221039 EAA
57175 EAI
28-5737 ELSTOCK
AG0874 GHIBAUDI
CA2045IR HC PARTS
8EL011712-371 HELLA
8EL738212-491 HELLA
ALB0278 KRAUF
553269RI KUHNER
553269RIB KUHNER
LRA03125 LUCAS
943319094010 MAGNETI MARELLI
MAR1994 MAGNETI MARELLI
1202115 OPELList
1204422 OPEL
13229991 OPELList
13308507 OPEL
55564350 OPEL
6204278 OPELList
93191921 OPELList
95520015 OPEL
89214844 POWERMAX
135.560.120 PSH
20101433 REAL
2010334 SANDO
23816R WAI / TRANSPO
ALT10619 WOODAUTO
ALT10619R WOODAUTO
BOS0124425096 WOODAUTO
A0252 AS-PLList
0124325172 BOSCHList
0124325221 BOSCHList
0986081410 BOSCH
114202 CARGO
CAL10439 CASCO
CAL10439AS CASCO
CAL10439ES CASCO
CAL10439GS CASCO
CAL10439OS CASCO
CAL10439RS CASCO
4746 CEVAM
DA1551 DELCO
DA1551N DELCO
DRA0441 DELCO
DRA0441N DELCO
RAA11552 DELCO
57174 EAI
28-5885 ELSTOCK
210826 ERA
CA2005IR HC PARTS
8EL738212-621 HELLA
ALB2005 KRAUF
553270RI KUHNER
553270RIB KUHNER
553851RI KUHNER
553851RIB KUHNER
LRA03273 LUCAS
LRA3273 LUCAS
063732005010 MAGNETI MARELLI
MQA2005 MAGNETI MARELLI
13229990 OPELList
13308506 OPELList
13308506CW OPEL
93191920 OPEL
89214993 POWERMAX
135.560.100 PSH
20101934OE REAL
2010439 SANDO
440796 VALEO
20007R WAI / TRANSPO
UNIT BOM 920-3123 WAI / TRANSPO
ALT10708 WOODAUTO
0124325172 Bosch
0124325172OR +line
0124325221 Bosch
12090304 EuroTec
13229990 Opel
13308506 Opel
13308506CW Opel
135560100 PSH
4746 CEVAM
57174 EAI
6456SP Spidan
738212621 Hella
8EL738212621 Hella
9090546F Friesen
9203123 PIC
930441 EDR
CA2005IR HC
DRA0441 Remy
HCA2005IR HC
LRA03273 Lucas
OAN12360 Optimum
OAN12644 Optimum
Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 140 A |
| Bottom Mounting Foot Width (B) | 63 mm |
| Diameter (D.1) | 12.5 mm |
| Diameter (D.2) | 12.5 mm |
| Length (L.1) | 191 mm |
| OEM Product | No |
| Plug Code | PL_2200 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 116 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| OPEL | Astra H 1.9 CDTi | [Z19DT] | 09.2005- |
| OPEL | Astra H 1.9 CDTi | [Z19DTH] | 09.2005- |
| OPEL | Astra H 1.9 CDTi | [Z19DTL] | 09.2005- |
| OPEL | Astra H 1.9 CDTi 16V | [Z19DTH] | 04.2004- |
| OPEL | Astra H 1.9 CDTi 16V | [Z19DTJ] | 08.2004- |
| OPEL | Astra H 1.9 CDTi 16V GTC | [Z19DTH] | 03.2005- |
| OPEL | Astra H 1.9 CDTi 16V GTC | [Z19DTJ] | 03.2005- |
| OPEL | Astra H 1.9 CDTi GTC | [Z19DT] | 09.2005- |
| OPEL | Astra H 1.9 CDTi GTC | [Z19DTL] | 01.2006- |
| OPEL | Signum 1.9 CDTi | [Z19DT] | 08.2005- |
| OPEL | Signum 1.9 CDTi | [Z19DTH] | 04.2004- |
| OPEL | Vectra C 1.9 CDTi | [Z19DT] | 10.2005- |
| OPEL | Vectra C 1.9 CDTi | [Z19DTH] | 04.2004- |
| OPEL | Vectra C 1.9 CDTi GTS | [Z19DT] | 04.2004- |
| OPEL | Vectra C 1.9 CDTi GTS | [Z19DTH] | 04.2004- |
| OPEL | Vectra C 1.9 CDTi GTS | [Z19DTL] | 10.2005- |
| OPEL | Zafira B 1.9 CDTi | [Z19DT] | 07.2005- |
| OPEL | Zafira B 1.9 CDTi | [Z19DTH] | 07.2005- |
| SAAB | 9-3X 1.9 TTiD | [A19DTR] | 02.2009- |
| SAAB | 9-3X 1.9 TTiD | [Z19DTR] | 02.2009- |
| VAUXHALL | Astra 1.9 CDTi | [Z19DTH] | 01.2006-11.2010 |
| VAUXHALL | Astra 1.9 CDTi LE | [Z19DTL] | 08.2005-11.2010 |
| VAUXHALL | Astra Mk V 1.9 CDTi | [Z19DT] | 08.2005- |
| VAUXHALL | Astra Mk V 1.9 CDTi | [Z19DTH] | 02.2005-11.2010 |
| VAUXHALL | Astra Mk V 1.9 CDTi | [Z19DTL] | 08.2005- |
| VAUXHALL | Astra Mk V 1.9 CDTi 16V | [Z19DTJ] | 08.2004- |
| VAUXHALL | Astravan 1.9 CDTi | [Z19DTH] | 03.2005-11.2011 |
| VAUXHALL | Astravan 1.9 CDTi | [Z19DTJ] | 03.2005-11.2011 |
| VAUXHALL | Signum 1.9 CDTi | [Z19DT] | 04.2004- |
| VAUXHALL | Signum 1.9 CDTi 16V | [Z19DTH] | 04.2004- |
| VAUXHALL | Signum 1.9 Turbo | [Z19DTL] | 01.2005-05.2008 |
| VAUXHALL | Vectra 1.9 CDTi | [Z19DT] | 04.2004- |
| VAUXHALL | Vectra 1.9 CDTi 16V | [Z19DTH] | 04.2004- |
| VAUXHALL | Vectra 1.9 CDTi 16V GTS | [Z19DTH] | 04.2004- |
| VAUXHALL | Vectra 1.9 CDTi GTS | [Z19DT] | 04.2004- |
| VAUXHALL | Vectra 1.9 CDTi GTS | [Z19DTL] | 10.2005- |
| VAUXHALL | Zafira Mk II 1.9 CDTi | [Z19DT] | 07.2005- |
| VAUXHALL | Zafira Mk II 1.9 CDTi | [Z19DTH] | 07.2005- |
| VAUXHALL | Zafira Mk II 1.9 CDTi | [Z19DTL] | 07.2005- |
Reference Information
