Associated Numbers
0124315021 02990301543 A0532S UD13495A UNIT BOM 220-5546Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 56 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10 mm |
| Length (L.1) | 201 mm |
| OEM Product | No |
| Plug Code | PL_2300 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 11 mm |
| Pulley Outside Diameter (O.D.1) | 46 mm |
| Pulley Outside Diameter (O.D.2) | 73.5 mm |
| Pulley to Mount Distance (A) | 110 mm |
| Pulley Type | SOLID |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VW | Gol | 01.1994- | |
| VW | Parati | 01.1995- | |
| VW | Pointer | 01.2002- | |
| VW | Saveiro | 01.1996- |
Reference Information
BOM UD13495A 220-5546 UNIT 0124315021 A0532S 2990301543Video/Publications
