Associated Numbers
0125711044 0125711051 0125711090 06H903017J 06H903017JX 06H903017T 06H903017TX 11157 2010474 205.545.150 28-7517 554171RIB 57426 A-6644 AEK3907 ALB0461 ALT10770 BOS0125711044 CAL10474 CAL10474AS CAL10474ES CAL10474GS CAL10474OS CAL10474RS DRA1029 EAA-223210 LRA03907 UD13163A UD13508A UNIT BOM 220-020
65-1734g
11725N
Armature G Roy 11725
Audi, Volkswagen 06H-903-017J, 06H-903-017JX, 06H-903-017T, 06H-903-017TX
Autoelectro AEK3907
Bosch 0 125 711 044, 0 125 711 051, 0 125 711 090, 0986083150
Bosch Service Europe 0 986 083 150
Casco CAL10474GS
DRI A/S Denmark 2115241502
EGI A-11725
ERA 209254
Farcom 113925
Lester 11725
Lucas Electrical Europe LRA03907
Mondial 60-220-50, 60-285-050
Our Part Number 11725N
Part # 11725
PIC Old 220-025
Power Select 11725N
Powerite Automotive 11725
Raw Power 11725N
Road Warrior 11725N
Techno CVC IMP-A11725
Wood Auto Supplies ALT10770, BOS0125711044
Zorko 11725
0121711044 Bosch
0121711051 Bosch
0121711090 Bosch
0125711044 Bosch show
0125711051 Bosch show
0125711090 Bosch show
0125711090OR +line
06H903017 VW
06H903017J VW
06H903017T VW
06H903017X VW
0986083150 Bosch ruil
12090694 EuroTec
205545150 PSH
287517 Elstock
57426 EAI
931029 EDR
DRA1029 Remy
LRA03907 Lucas
06H903017J
AUDI 06H903017T
BOSCH 0125711044
BOSCH 0125711051
BOSCH 0125711090
BOSCH 0986083150
BOSCH 8315
LUCAS LRA03907
LUCAS LRA3907
VW (VOLKSWAGEN) 06H903017J
VW (VOLKSWAGEN) 06H903017JX
VW (VOLKSWAGEN) 06H903017T
VW (VOLKSWAGEN) 06H903017TX
65-1734g
Specifications
Fitted with OEM Regulator and INA Clutch Pulley (if fitted)
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 56.5 mm |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | 9 mm |
| Diameter (D.4) | 9 mm |
| Length (L.1) | 192 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Product Line | +Plus Line Pro |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 30.5 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A4 1.8 TFSi | [CDHA] | 01.2012- |
| AUDI | A4 1.8 TFSi | [CJEB | 01.2012- |
| AUDI | A4 1.8 TFSi | [CJEB] | 01.2012- |
| AUDI | A4 1.8 TFSi Quattro | [CJEB] | 01.2012- |
| AUDI | A4 2.0 TFSi | [CAE.] | 01.2012- |
| AUDI | A4 2.0 TFSi | [CDN.] | 01.2012- |
| AUDI | A4 2.0 TFSi | [CNCD] | 01.2012- |
| AUDI | A4 2.0 TFSi Quattro | [CAEB] | 01.2012- |
| AUDI | A4 2.0 TFSi Quattro | [CAED] | 01.2012- |
| AUDI | A4 2.0 TFSi Quattro | [CDNC] | 01.2012- |
| AUDI | A5 1.8 TFSi | [CJEB] | 01.2012- |
| AUDI | A5 2.0 TFSi | [CDNB] | 01.2012- |
| AUDI | A5 2.0 TFSi | [CDNC] | 01.2012- |
| AUDI | A5 2.0 TFSi | [CNCD] | 01.2012- |
| AUDI | A5 2.0 TFSi Quattro | [CAEB] | 01.2012- |
| AUDI | A5 2.0 TFSi Quattro | [CAED] | 01.2012- |
| AUDI | A5 2.0 TFSi Quattro | [CDNC] | 01.2012- |
| AUDI | A5 2.0 TFSi Quattro | [CNCD] | 01.2012- |
| AUDI | Q5 2.0 TFSi Quattro | [CNCB] | 01.2012- |
| AUDI | Q5 2.0 TFSi Quattro | [CNCD] | 01.2012- |
Reference Information
0125711044 0125711051 0125711090 06H903017J 06H903017JX 06H903017T 06H903017TX 11157 2010474 205.545.150 28-7517 554171RIB 57426 A-6644 AEK3907 ALB0461 ALT10770 BOS0125711044 CAL10474 CAL10474AS CAL10474ES CAL10474GS CAL10474OS CAL10474RS DRA1029 EAA-223210 LRA03907 UD13163A UD13508A UNIT BOM 220-020View your shopping basket or Browse other items in Alternators.
