Associated Numbers
0124325086 0986046120 195.530.110 195.550.100 2040209 209366 270600H080 301907RI 89213536 ALB1907 BOS0124325082 CAL40209 CAL40209AS CAL40209ES CAL40209GS CAL40209OS CAL40209RS DRB6120 UD14825A 0124325082 UD11469A AS-PL 0124325085 BOSCHList BOSCH 102211-0750 DENSOList 102211-0920 102211-0921 DENSO 104210-1360 104210-2462 104210-3780 DAN952 EAA-222140 EAA 28-4652 ELSTOCK JA1613IR HC PARTS LRA02189 LUCAS 27060-0H070 TOYOTA 27060-28070 27060-28160 TOYOTAList 27060-28260 ALT30187 WOODAUTO DXA565 DXA582 UD01139A AS-PL BXA026 ASHDOWN INGRAM DXA566 CAL40327AS CASCO 65-8459 CIVIC/DA 65-8498 104210-4810 104210-4811 104210-4880 104210-4881 A1046D PRESTOLITE 20132723BN REAL 2040327 SANDO 27060-0H110 27060-0H111 27060-28320 27060-28321 11195R WAI / TRANSPO 0986082060 Bosch ruil 1022110750 Denso 1022110920 1022110921 1042101360 1042103780 11034N 11034R 11088 11088N 11088R 12060826 EuroTec 195550100 PSH 23192 Lester 2706025260 Toyota 2706028070 2706028150 2706028160 2706028260 284652 Elstock 2905153 PIC 57070 EAI 6094SP Spidan 930468 EDR ATA917 ATK Casco DRA0468 Remy HJA1613IR Lucas N5112116 Nipparts TNA085 TWA 0124325084 115416 Cargo 12060778 195530100 2205531 23189 270600H070 286610 6358SP 9046120F Friesen 941620 946120 ALT1244sa Electrolog ALT6255 CA1907IR EF40216 HCA1907IR KTR391060200 KTR L46120 ATL LRA03500 OAN10407 Optimum dxa582 bxa062 658499 0124325071 195530110 270600H221 AEB1613 401613RI 401613RID 1042109060 104210-9060 270600H120 27060-0H120 ASPL BOSCHList DENSOList 1042102462 EAA222140 EAA PARTS TOYOTA CASCO 658459 658498 1042104810 1042104811 1042104880 1042104881 REAL 270600H110 270600H111 2706028320 2706028321 LRA2189 A0224 List AUTOELECTRO DELCO EAA-221362 9046120 FRIESEN 11.1907 LAUBER 11.1907M 20132902BN 20132902OE SA900 SOVEREIGN ERA KRAUF POWERMAX KTR391100200 ANB235 ANJ234 11.1613M EAA221362 UD20709A 114273 CAL40382AS 40388 DRA0459 A-80287 8EL012241-001 J5112149 ALN1316 89213906 20132283BN 2040382.0 90-29-5610N 90-29-5610 DENDAN952 65-8303Specifications
| Amp | 100 A |
| Bottom Mounting Foot Width (B) | 18 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | M8x1.25 mm |
| Diameter (D.3) | M10x1.25 mm |
| Length (L.1) | 177 mm |
| Mount Inside Length or Pad Mount C-C (C) | 45.5 mm |
| OEM Product | No |
| Plug Code | PL_4000 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 7 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 36 mm |
| Pulley Type | SOLID |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Avensis 2.0 | [1AZ-FE] | 04.2003-11.2008 |
| TOYOTA | Avensis 2.0 | [1AZ-FSE] | 03.2003-11.2008 |
| TOYOTA | Avensis 2.0 | [1AZ-FSE] | 04.2003-11.2008 |
| TOYOTA | Avensis 2.4 | [2AZ-FSE] | 09.2003-11.2008 |
| TOYOTA | Avensis 2.4 | [2AZ-FSE] | 10.2003-10.2008 |
| TOYOTA | Camry 2.4 | [2AZ-FE] | 11.2001-11.2006 |
Alternatives >>>
A0224 - Brand New 100 amp Bosch Style
A0224R Remanufactured 100 Amp Bosch Style
A6055(P)R Remanufactured Denso type with Clutch Pulley
A6055R - Remanufactured Denso Type with solid Pulley
A6142 - Brand new Denso Style 100 Amp with Clutch Pulley
A6142R - Remanufactured Denso Style 100 Amp with Clutch Pulley
Reference Information
CAL40209OS ALT422090 0124325086 2706028070 CAL40209ES 209366 CAL40209GS 270600H070 002-T917 2040209 CAL40209 UD14825A 2706028160 2T917 STX100251 301907RI STX100251R BOS0124325082 CAL40209RS 89213536 195.550.100 270600H080 5510580 CAL40209AS 0986046120 ALT1244 ALT917 ALB1907 311859 DRB6120 195.530.110Video/Publications
