Associated Numbers
0986038491 0986045001 0986045073 11.0761 111267 20110199 20145901BN 2020109 21262N 22246N 28-0908 28-1743 28-1795 28-2584 40761RI 40873RI 437113 56475 89213071 8941224884 8943820590 8943820591 8943820600 8944195190 8944195191 8970377241 8970739241 8971137700 8971370090 8971876540 8971876570 8EL730094-001 9051913 9213071 9300 94382059 97113770 A2004 AEA1299 ALH0761 ALT32180 CAL20109AS DRA3376 DRA3376N EAA-221344 JA761IR LR150-421 LR150-421C LR150-434 LR150-434B LR150-441 LR150-441C LR150-441E LR150-442 LR150-442B LR150-444 LR150-444B LR150-448 LR150-449 LR150-449B LR150-449C LR150-453 LR150-453B LRA01514 LRA02656 LRB00199 SA454 SA845
hxa078 14-022
Specifications
| Amp | 50 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Length (L.1) | 235 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81.5 mm |
| OEM Product | No |
| Plug Code | PL_4500 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 16 mm |
| Pulley Outside Diameter (O.D.1) | 49 mm |
| Pulley Outside Diameter (O.D.2) | 82 mm |
| Pulley to Mount Distance (A) | 48.5 mm |
| Pulley Type | SOLID |
| Unit Type | HITACHI |
| Vacuum Pump | Yes |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ISUZU | Campo 2.5 Diesel 4WD | [4JA1] | 08.1989-12.1990 |
| ISUZU | Trooper 2.8 TD | [4JB1T] | 10.1987-12.1991 |
| ISUZU | Trooper 2.8 TD | [4JB1-TC] | 10.1988-12.1991 |
| OPEL | Campo 2.5 Diesel | [4JA1] | 09.1991-11.1995 |
| OPEL | Campo 2.5 TD | [4JA1] | 02.1989-08.1997 |
| OPEL | Campo 2.5 TD | [4JA1T] | 10.1989-08.2001 |
| OPEL | Campo 2.5 TD 4x4 | [4JA1T] | 07.1994-08.2001 |
| OPEL | Campo 3.1 TD | [4JG2T] | 12.1992-08.1997 |
| OPEL | Campo 3.1 TD 4x4 | [4JG2T] | 12.1992-07.1995 |
| OPEL | Monterey A 3.1 TD | [4JG2TC] | 09.1991-12.1997 |
| VAUXHALL | Brava 2.5 Diesel | [4JA1] | 08.1991-06.1994 |
| VAUXHALL | Brava 2.5 Diesel 4x4 | [4JA1T] | 06.1990-12.1996 |
| VAUXHALL | Brava 2.5 TD | [4JA1T] | 07.1994-03.1998 |
| VAUXHALL | Brava 2.5 TD 4x4 | [4JA1T] | 07.1994-03.1998 |
| VAUXHALL | Monterey A 3.1 TD 4x4 | [4JG2TC] | 09.1991-07.1998 |
Reference Information
LR150-444 LR140-433B LR150-442 LR150-441 8EL730094-001 LR150-442B 9120606 LRA2656 LR160448C LR140-433 8970377241 8971137700 SA845 LR150-448 LR150-449 LR150-441B 40761RI LR150-441C 97134762 LR150-434 LR150-441E LR140433 4310890 9512324 A2004 LR150-449B LR150-449C 97037724 LR140-426 LR140-427 LR150-449E LR160-446 LR140433B LR150-453B LR160505 LR160447F LR160507 8971370090 445810 20110199 LR160447C LR160447B LR160447E 94382059 8941224884 8971876540 8941224883 311938 DRA3376N LR150449E LR150449F 21262N LRA02656 LRB199 LR150-448B LR15078E LR150441F LR15078B 8-97134-762-0 97147851 28-1743 89213071 8943820590 8971876531 8943820591 8982840070 11.0761 8-97134-781-0 97134781 97187655 97187653 9051913 LR150-453 20145901BN LR160-446E 9512268 LR160-446B SA454 LR160-446C 8-97073924-0 6204169 94419519 9213071 LR160448 9120578 8971876520 9300 ALT32180 9512813 LR150-434B 8943820600 6204054 40873RI 8943301860 ALT3131 JA761IR R1030083 111267 8983003350 ALTS149 8-97074-611-0 8-97187-655-0 LR150-421C 8-97147-851-0 LRA1514 8970739230 STX100744 8-97071-611-0 LR15078 0986038491 8971876582 8971876581 93175833 R1530063 28-2584 8971876580 AEA1299 LR150-421 2020109 LR150-444B ALH0761 LR150-78E 8970739241 894122-4883 0986045001 56475 HAL160507 LR150-78C LR150-78B PRAS149 LR140426 9119720 CAL20109AS LR140427 2U303 9119721 R1030068 8971876571 8971876570 ALT5370 437113 LRA01514 LRB00199 97074611 LR150449WA 002-U303 CGB-13001 ALU303 ANM35596X 28-0908 0986045073 EAA-221344 22246N 28-1795 STX100646 DRA3376 8944195190 8944195191 97113770 93175976 LR150-78Video/Publications
