Information
37300-25201Associated Numbers
02131-9130 02131-9131 11.2122 11189N 11202N 11202R 114827 20193841OE 2032148 2655544 28-5848 37300-25201 37300-25301 37300-25310 553661RIV 9212254 9440 AEK3236 ALT14404 CA2122IR CAL32148GS DRA0453 LRA03236 TG11C076 UD10816A
ANJ528 65-6670
UD10816A ASPL
AEK3236 AUTOELECTRO
114827 CARGO
CAL32148GS CASCO
9440 CEVAM
DRA0453 DELCO
285848 ELSTOCK
CA2122IR HC PARTS
3730025201 HYUNDAI / KIA List
3730025301 HYUNDAI / KIA List
3730025310 HYUNDAI / KIA List
11.2122 LAUBER
LRA03236 LUCAS
021319130 POONGSUNG List
021319131 POONGSUNG
9212254 POWERMAX
20193841OE REAL
2655544 VALEO List
TG11C076 VALEO List
11189N WAI / TRANSPO
11202N WAI / TRANSPO
11202R WAI / TRANSPO
ALT14404 WOODAUTO
021319130 Kia
021319131 Kia
021319132 Kia
11189N Lester
11202 EAI
11202N Lester
155581110 PSH
2655544 Valeo
285848 Elstock
2905282A PIC
3730025201 Kia
3730025301 Kia
3730025310 Kia
600029 Valeo
655544 Valeo
930453 EDR
A0002655544 Valeo
ALT6140sa Electrolog
CA2122IR HC
DRA0453 Remy
F042A02180 Unipoint
J5110533 Nipparts
KTR311162220 KTR
LRA03236 Lucas
TG11C076 Valeo
TRA089 TWA
155574110 PSH
2606446 Valeo
373002G400 Kia
373002G500 Kia
440374 Valeo
600196 Valeo
600878
606446 Valeo
607928 Valeo
930988 EDR
A0002606446 Valeo
A0002607928 Valeo
ACA415 ATK
DRA0988 Remy
N5110528 Nipparts
TRA085 TWA
vxa008 656670 anj528 anj528GQ
J&N 40040062
Bosch AL4065X
Hyundai 3730025201
Lester 11189
PIC Picture ID 208736
Valeo 2655544
Wilson 90225551 tg11c076
Hyundai 37300-2G100
PIC Picture ID 208-893
Remy Light Duty 11137
Valeo 2606128A, 426128, TG11C076
021319130 Denso
021319131 Denso
021319132 Denso
0986CR0143 Bosch ruil
0986CR6248 Bosch ruil
0986CR6400 Bosch ruil
0986UR0143 Bosch ruil
11202 EAI
114827 Cargo
12060975 EuroTec
155581110 PSH
2655544 Valeo show
285848 Elstock
2905282A PIC
3730025201 Kia
3730025301 Kia
3730025310 Kia
600029 Valeo
655544 Valeo
930453 EDR
9440 CEVAM
A0002655544 Valeo
AL4065X Bosch (USA)
AL4107X Bosch (USA)
ALT5141 Unipoint
ALT6140sa Electrolog
CA2122IR HC
DRA0453 Remy
F042206024 Bosch
F042A02180 Bosch
J5110533 Nipparts
LRA03236 Lucas
TG11C076 Valeo show
TRA089 TWA
Specifications
| Amp | 140 A |
| Bottom Mounting Foot Width (B) | 20 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | M10x1.25 mm |
| Diameter (D.4) | M10x1.25 mm |
| Length (L.1) | 193 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57 mm |
| OEM Product | No |
| Plug Code | PL_3304 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 60 mm |
| Pulley to Mount Distance (A) | 43 mm |
| Pulley Type | CLUTCH |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | Sonata 2.4 | [G4KC] | 01.2005- |
| KIA | Carens 2.0 CWT | [G4KA] | 01.2006- |
| KIA | Magentis 2.0 | [G4KA] | 01.2005- |
Alternatives >>>
A3239(VALEO) - Brand new VALEO version - ** with C terminal, which is not used in all applications**
A3239 - Brand new aftermarket version - ** with C terminal, which is not used in all applications**
A3195R - Remanufactured version
A3195(VALEO) - Brand new VALEO version
Reference Information
114827 11.2122 AEK3236 CA2122IR 37300-2G501 9440 LRA3236 A12VA0676A2 A3195 37300-25201 37300-25301 TG11C076 28-5848 11202R 11189N 553661RIV 11202N LRA03236 DRA0453 ALT14404 STX101699 A12VA0676 2655544 37300-25310 446964 UD10816A 37300-2G100 ALT8776 02131-9130 ANM32673X 02131-9131 ALTF776Video/Publications
A3195< Critical Notes >
Does NOT have a C terminal -
