Associated Numbers
104210-5610 20132184RC 2040481.2 27060-30160 554570RI A6041 ALN3969 ALN7969 ALT30588 CAL40481RS UD12544A 65-8591 0986082010 Bosch ruil 0986JR1269 1042101860 Denso 1042101862 1042103410 show 1042103410OR +line 1042103410SEL 1042103411 1042103412 1042103413 1042104461 1042104462 1042105440 1042105441 1042105442 1042118740 1042118741 1042118742 112673 Cargo 113969 12060863 EuroTec 195574100 PSH 210775A Messmer 2351871002 DRI 24056 Lucas 2706030060 Toyota 270603006084 2706030130 270603013084 2706030131 270603013184 2706030210 285679 Elstock 2905622 PIC 57033 EAI 8EL011713121 Hella 9090514 Friesen 9090514F 930246 EDR 9447 CEVAM ALT5218 Unipoint ATA638 ATK CA2069IR HC DAN1070 DRA0246 Remy L83670 ATL LRA03067 LRA3067 N5111242 Nipparts TNA077 TWA 104210-1860 104210-3410 104210-3411 104210-5440 104210-5441 104211-8741 195.574.100 20132392 20132522 2040225 2040293 210775 24056R 27060-30060 27060-30080 27060-30130 27060-30131 27060-30210 28-5679 553219RI 553219RIM 89215342 ALT30464 CAL40225 CAL40225AS CAL40225ES CAL40225GS CAL40225OS CAL40225RS CAL40293 CAL40293AS CAL40293ES CAL40293GS CAL40293OS CAL40293RS DA1356 DENDAN1070 UD15310A 1042101861 104210-1862 104210-1861Specifications
Amp | 100 A |
Bottom Mounting Foot Width (B) | 60 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10 mm |
Length (L.1) | 174 mm |
OEM Product | No |
Plug Code | PL_4000 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 7 qty |
Pulley Outside Diameter (O.D.1) | 58 mm |
Pulley to Mount Distance (A) | 98 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Dyna 3.0 | [1KD-FTV] | 09.2006- |
TOYOTA | Dyna 3.0 | [1KD-FTV] | 10.2009- |
TOYOTA | Dyna 3.0 D-4D | [1KD-FTV] | 10.2009- |
TOYOTA | Hiace 2.5 | [1KD-FTV] | 06.2004- |
TOYOTA | Hiace 2.5 | [1KD-FTV] | 09.2006- |
TOYOTA | Land Cruiser 3.0 | [1KD-FTV] | 01.2011- |
TOYOTA | Land Cruiser Prado 3.0 | [1KD-FTV] | 07.2004-08.2009 |
TOYOTA | Land Cruiser Prado 3.0 | [1KD-FTV] | 08.2006-07.2009 |
TOYOTA | Land Cruiser Prado 3.0 | [1KD-FTV] | 08.2009- |
TOYOTA | Land Cruiser Prado 3.0 | [1KD-FTV] | 09.2002-08.2009 |
TOYOTA | Land Cruiser Prado 3.0 | [1KD-FTV] | 09.2002-12.2010 |
Alternatives >>>
A6025 - Aftermarket 80A option. not for HIACE
A6025SR - Remanufactured DENSO Alternator - not for HIACE
A6630(DENSO) OEM DENSO Alternator - Not for HIACE
A6041 Aftermarket 100A option, 'Tradie Hiace and Hilux' - Not for Hiace Minibus
A6352 Aftermarket 130A option, Best option for Hiace Minibus
Reference Information
2040293 0986082010 27060-30060 CAL40225AS 556155RI 2040293.1 210775A 20132392OE ALT6327 DENDAN1070 20132392BN 27060-30130-84 STX100443R 113969 ALN3969 24056R 2040225 ALTJ010 556155RID 27060-30130 57033 27060-30131 8EL011713-121 LRA3067 27060-30210 CAL40293GS 104210-5441 104210-5440 104210-5442 CA2069IR A12DE0120A2 UD12544A 89215342 ALTJ010U CAL40225GS 20132522OE 447190 27060-30080 9447 27060-30131-84 DRA0246 104210-3410 104210-3411 LRA03067 195.574.100.050 20132522BN 5540020 DAN1070 2040225.1 195.574.100.265 195.574.100.260 CAL40293AS 28-5679 STX100443 210775Video/Publications
A6041Related Items
