A6135 - Brand new AS-PL Alternator

Name: Brand new AS-PL Alternator
Brand: AS-PL
SKU: A6135
Price: 401.78 NZD
Availability: BackOrder

Brand new AS-PL Alternator

STANDARD LINE

Manufacturer:

AS-PL

Replacement For:

DENSO

Price:

NZ$ 401.78 including GST

NZ$ 349.37 excluding GST

UOM:

each

Product Code:

A6135

Quantity In Stock Nationally:

No stock in NZ

Availability:

This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**

Associated Numbers
Specifications
Vehicle Applications
Reference Information
Video/Publications

0986049840 100210-3270 100210-3350 100210-3360 100210-3400 100210-3460 100210-3580 100210-3680 100210-3770 100210-3810 100210-3820 100210-3821 11.0777 111483 20130103 20130104 20132101BN 20152301BN 2040101 2044103 22070N 27-1802 27020-54250 27020-54351 27020-54352 27020-54353 27020-54354 27020-54383 27030-54190 27030-54241 27030-54242 27030-54243 27030-54244 27030-54250 27030-54260 27030-54261 27030-54262 27030-54263 2703054241 40193 40777 56424 89212393 9051283 9253 A6135 AEB0777 ALN8868 ALT30052 CAL40101AS CAL44103AS EAA-211087 J2702054352 J2702054700 JA777 LRA01096

Ashdown Alternator 903-70830X
Auto Electrics Australia Alternator ALT2830 12v
Daihatsu Alternator 27030-87602-000
Denso Alternator 021000-0830 12v 55amps
Denso Alternator 021000-2680 12v
Denso Alternator 021000-8830 [27020-54021] 12v 40amps
Denso Alternator 021000-9950 [27020-56160] 12v
Denso Alternator 09816105 12v
Denso Alternator 100210-0283 [27030-68110] 12v 55amps
Denso Alternator 100210-0510 [27030-47033] 12v 55amps
Denso Alternator 100210-0512 [27030-47033] 12v 55amps
Denso Alternator 100210-1451 [27030-47034] 12v 50amps
Denso Alternator 100210-1461
Denso Alternator 100210-1555 [27030-54013] 12v 55amps
Denso Alternator 100210-1560 [27030-87311] 12v 35amps
Denso Alternator 100210-1562 [27030-87311] 12v 35amps
Denso Alternator 100210-1573 [27030-54022] 12v 40amps
Denso Alternator 100210-1951
Denso Alternator 100210-2260 12v 40amps
Denso Alternator 100210-2350 [27030-54090] 12v 40amps
Denso Alternator 100210-2380 [27030-54120] 12v 55amps
Denso Alternator 100210-2461 12v 40amps
Denso Alternator 100210-2600 [27030-54130] 12v 55amps
Denso Alternator 100210-2620 [27030-64040] 12v 40amps
Denso Alternator 100210-2660 [27030-54140] 12v 40amps
Denso Alternator 100210-2700 [27030-54150] 12v 45amps
Denso Alternator 100210-2750 [27030-54160] 12v 50amps
Denso Alternator 100210-2830
Denso Alternator 100210-2840 [27030-87602-000] 12v 45amps
Denso Alternator 100210-2850 12v 40amps
Denso Alternator 100210-2870 12v 60amps
Denso Alternator 100210-2871 12v 60amps
Denso Alternator 100210-3080 [27030-54218] 12v 45amps
Denso Alternator 100210-3270 [27030-54190] 12v 50amps
Denso Alternator 100210-3360
Denso Alternator 100210-3400 [27030-54241] 12v 50amps
Denso Alternator 100210-3460 [27030-54242] 12v 55amps
Denso Alternator 100210-3720 [27030-87603] 12v 45amps
Denso Alternator 100210-9920 12v 55amps
Denso Alternator 100211-1460 [MD089595] 12v 40amps
Denso Alternator 100211-1461 [27030-47034] 12v 40amps
Denso Alternator 100213-0130 [27040-54020] 12v 55amps
Denso Alternator 121000-0090 [27030-54090] 12v 40amps
Denso Alternator 121000-0451 [2702016040] 12v
Denso Alternator 121000-0820 [27020-54190] 12v 55amps
Denso Alternator 121000-1690 12v 55amps
Denso Alternator 121000-1700 12v 55amps
Denso Alternator 121000-2310 12v 55amps
Ingram Alternator 843522
Toyota Alternator 27030-47033
Toyota Alternator 27030-47034
Toyota Alternator 27030-54120
Toyota Alternator 27030-54140
Toyota Alternator 27030-54160
Toyota Alternator 27030-54241
Toyota Alternator 27030-54242
Toyota Alternator 27030-57663
Toyota Alternator 27030-64040
Toyota Alternator 27030-68010
Toyota Alternator 27030-87311
Toyota Alternator 27030-87602-C
Toyota Alternator 27040-54020

dxa4102 65-8402 ANJ278 14-004

Amp	55 A
Bottom Mounting Foot Width (B)	13.5 mm
Diameter (D.1)	M8x1.25 mm
Diameter (D.2)	10 mm
Diameter (D.3)	10 mm
Length (L.1)	271 mm
Mount Inside Length or Pad Mount C-C (C)	97 mm
OEM Product	No
Plug Code	PL_3601
Product Line	Standard Line
Product Type	Brand new
Pulley Grooves	2 qty
Pulley Groove Width (W.1)	12 mm
Pulley Outside Diameter (O.D.1)	51 mm
Pulley Outside Diameter (O.D.2)	77 mm
Pulley to Mount Distance (A)	52 mm
Pulley Type	SOLID
Unit Type	DENSO
Vacuum Pump	Yes
Voltage	12 V

Make	Model	Type	Year
TOYOTA	Dyna 100 2.4 D	[2L]	05.1995-07.2001
TOYOTA	Dyna 100 2.4 Diesel	(LH80)[2L]	01.1984-05.1995
TOYOTA	Dyna 150 2.4 D	[2L]	09.1988-04.1995
TOYOTA	Dyna 150 2.8 Diesel	(LY61)[3L]	08.1985-05.1995
TOYOTA	Hiace 2.2 Diesel	(H5G)[L]	03.1983-11.1989
TOYOTA	Hiace 2.2 Diesel	[L]	03.1983-11.1989
TOYOTA	Hiace 2.4 Diesel	[2L]	05.1984-11.1989
TOYOTA	Hiace 2.4 Diesel	(H5G)[2L]	08.1984-08.1989
TOYOTA	Hiace 2.4 Diesel	(LH102)[2L]	08.1989-08.1995
TOYOTA	Hiace 2.4 Diesel 4WD	(H5F)[2L]	01.1987-01.1988
TOYOTA	Hilux 2.4 D	[2L]	03.1995-08.1997
TOYOTA	Hilux 2.4 D	[2L]	08.1997-04.2005
TOYOTA	Hilux 2.4 D	[2L]	09.1988-08.1997
TOYOTA	Hilux 2.4 D	[2L]	10.1988-07.1997
TOYOTA	Hilux 2.4 D	[2L]	10.1991-07.1997
TOYOTA	Hilux 2.4 D 4WD	[2L]	01.1994-12.1997
TOYOTA	Hilux 2.4 D 4WD	[2L]	09.1988-08.1997
TOYOTA	Hilux 2.4 D 4WD	[2L]	09.1994-07.1997
TOYOTA	Hilux 2.4 Diesel	[2L]	08.1988-07.2005
TOYOTA	Hilux 2.4 Diesel 4WD	[2L]	08.1988-07.2005
TOYOTA	Hilux 2.4 TD 4WD	[2L-T]	08.1988-08.1997
TOYOTA	Land Cruiser 2.4 TD	[2L-T]	10.1985-05.1990
VW	Taro 2.4	[22]	06.1989-03.1997
VW	Taro 2.4 D	[2L]	06.1989-03.1997
VW	Taro 2.4 D	[2L]	07.1994-03.1997
VW	Taro 2.4 D	[2L]	09.1991-07.1994
VW	Taro 2.4 D 4x4	[2L]	04.1989-03.1997
VW	Taro 2.4 D 4x4	[2L]	07.1994-03.1997
VW	Taro 2.4 Diesel	[2L]	07.1994-03.1997
VW	Taro 2.4 Diesel 4x4	[2L]	07.1994-03.1997

10021-03821 LRA1096 SA054250-A 27020-54700 27030-54263 27030-54262 27020-54383 27020-54354-84 27-1802 27030-54261 20132101BN 27030-54260 27060-54100 27060-54101 445826 STX101222 111483 J2702054700 2T916 2.70205E+11 10021-03460 ALT421010 10021-03580 10021-03770 10021-03810 ALT30052 40777 AEB0777 210768A 2040101 ALN0777 LRA01096 27020-54250 56424 J2702054352 A6135 SA991 ALT916 A12DE0374A2 10021-15900 89212393 27030-54190 437705 2702054250 10021-03400 CGB-13518 ALT1019 ALTS055 12100-05100 27030-54241 0986049840 002-T916 ALT6469 27030-54244 5540301 27030-54243 ALT6468 27030-54242 STX100232 195.807.055.058 10021-03680 CAL40101AS 10021-03360 195.807.055.395 195.807.055.050 ANM35738 J5112083 STX100957 2703054190 8EL012429-271 27030-54252 JA777 27030-54251 27030-54250 10021-08160 27020-54353 27020-54354 27020-54351 27020-54352 27030-54253 10021-03350

A6135
