Associated Numbers
11155R 12656 421000-0360 421000-0363 553983RI 56044380AC 56044380AF 56044380AH 90-29-5559 A-80319 ALT30370 DRA1005 UD11522A
Denso 210-0586
Wilson 90-29-5559
References:
Arrowhead AND0405
J&N 400-52114
Chrysler 56044380AC, 56044380AH
Denso 210-0586, 421000-036, 421000-0360, 421000-0361, 421000-0362, 421000-0363
Lester 11155
PIC Picture ID 290-5201
Wilson 90-29-5559
JANNCO 400-52114R
Wilson 90-29-5559
References:
J&N 400-52114
JANNCO 400-52114R
Denso 421000-0360, 421000-0363
JANNCO 400-52114R
Denso 210-0586
Wilson 90-29-5559
References:
Chrysler 56044380AC, 56044380AH
Denso 421000-036, 421000-0360, 421000-0361, 421000-0362, 421000-0363
PIC Picture ID 290-5201
son 90-29-5559
421000-0361
421000-0362
anj230
Specifications
| Amp | 160 A |
| Bottom Mounting Foot Width (B) | 13.5 mm |
| Diameter (D.1) | 11.5 mm |
| Diameter (D.2) | 11.5 mm |
| Diameter (D.3) | M10x1.5 mm |
| Length (L.1) | 173 mm |
| Mount Inside Length or Pad Mount C-C (C) | 60.5 mm |
| OEM Product | No |
| Plug Code | PL_2802 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 53 mm |
| Pulley to Mount Distance (A) | 21 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JEEP | Commander 5.7 | [EZB] | 01.2006- |
| JEEP | Grand Cherokee 5.7 V8 | [EZB] | 01.2005-12.2006 |
| JEEP | Grand Cherokee 6.1 | [ESF] | 01.2006- |
Reference Information
56044380AF ALT30370 56044380AH 11155R 90-29-5559 UD11522A 421000-0360 421000-0363 2013291ABN ALT6712 553983RI DRA1005 CAL40A19AS 56044380AC 12656 2040A19.0 A-80319Video/Publications
