Associated Numbers
104210-6670 11624 11624R 290-10514 90-29-5799 A-80517 CL3T-10300-BA CL3Z-10346-B UD14172ASpecifications
| Amp | 225 A |
| Bottom Mounting Foot Width (B) | 15 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.5 mm |
| Length (L.1) | 161.5 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57 mm |
| OEM Product | No |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 57 mm |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | F-150 3.5 | 01.2011-12.2014 | |
| FORD | F-150 3.7 | 01.2011-12.2014 |
Reference Information
104210-6670 90-29-5799 11624 11624R CL3T-10300-BA CL3Z-10346-B UD14172A 290-10514 A-80517 11624NVideo/Publications
