Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 501.57 including GST
NZ$ 436.15 excluding GST
or four payments of $125.39
with
Learn More
each
A6513S
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
104210-1960Associated Numbers
104210-1960 104210-1961 104210-1962 11682N 1202323 1202369 135.912.150 13592811 209137 22892569 90-29-5827 95519894 A-80605 A6513S DA2910 DRA1800 UD15185ASpecifications
| Amp | 150 A |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 8 mm |
| Diameter (D.3) | 10 mm |
| Length (L.1) | 183 mm |
| Mount Inside Length or Pad Mount C-C (C) | 55 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 79 mm |
| Pad mount thickness (E.2) | 79 mm |
| Pad mount thickness (E.3) | 79 mm |
| Plug Code | PL_2201 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 40 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| OPEL | Insignia 2.0 Turbo | [A20NFT] | 07.2008-03.2017 |
| OPEL | Insignia 2.0 Turbo | [A20NFT] | 10.2010-03.2017 |
| OPEL | Insignia 2.0 Turbo | [A20NHT] | 04.2014-03.2017 |
| OPEL | Insignia 2.0 Turbo | [A20NHT] | 07.2008-03.2017 |
| OPEL | Insignia 2.0 Turbo | [A20NHT] | 10.2010-03.2017 |
| OPEL | Insignia 2.0 Turbo | [B20NHT] | 04.2014-03.2017 |
| OPEL | Insignia 2.0 Turbo 4x4 | [A20NFT] | 07.2011-03.2017 |
| OPEL | Insignia 2.0 Turbo 4x4 | [A20NHT] | 07.2008-03.2017 |
| OPEL | Insignia 2.0 Turbo 4x4 | [A20NHT] | 07.2011-03.2017 |
| OPEL | Insignia 2.0 Turbo 4x4 | [B20NHT] | 07.2011-03.2017 |
| OPEL | Insignia 2.0 Turbo 4x4 Sports Tourer | [A20NHT] | 07.2008-06.2011 |
| OPEL | Insignia 2.0 Turbo 4x4 Sports Tourer | [A20NHT] | 09.2011-06.2013 |
| OPEL | Insignia 2.0 Turbo 4x4 Sports Tourer | [B20NHT] | 09.2011-06.2013 |
| OPEL | Insignia 2.0 Turbo Sports Tourer | [A20NFT] | 09.2010-11.2011 |
| OPEL | Insignia 2.0 Turbo Sports Tourer | [A20NHT] | 04.2014-11.2014 |
| OPEL | Insignia 2.0 Turbo Sports Tourer | [A20NHT] | 07.2008-06.2013 |
Reference Information
104210-1962 135.912.150 104210-1961 104210-1960 90-29-5827 209137 1202369 A6513S UD15185A 1202323 13592811 DA2910 11682N 95519894 DRA1800 22892569 A-80605Video/Publications
