Associated Numbers
104211-0230 11081 A-80517 AL7674X CL3T-10300-BA CL3T10300BA CL3Z-10346-B CL3Z10346B FL3T-10300-HA FL3Z-10346-E UD15415ASpecifications
| Amp | 200 A |
| Bottom Mounting Foot Width (B) | 15 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | M10x1.5 mm |
| Length (L.1) | 163 mm |
| Mount Inside Length or Pad Mount C-C (C) | 58.5 mm |
| OEM Product | No |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 57 mm |
| Pulley to Mount Distance (A) | 43.5 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | F-150 3.5 | 01.2012-12.2014 | |
| FORD | F-150 3.7 | 01.2012-12.2014 |
Reference Information
UD15415A 11081 FL3Z-10346-E 104211-0230 AL7674X CL3T-10300-BA CL3T10300BA CL3Z-10346-B CL3Z10346B A-80517 FL3T-10300-HAVideo/Publications
