Associated Numbers
27050-1112A A9047Specifications
| Amp | 35 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | M10x1.5 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Length (L.1) | 283 mm |
| Mount Inside Length or Pad Mount C-C (C) | 96.5 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 15 mm |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley Outside Diameter (O.D.2) | 85 mm |
| Pulley to Mount Distance (A) | 50 mm |
| Pulley Type | SOLID |
| Unit Type | HINO |
| Vacuum Pump | Yes |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HINO | Various Models |
Reference Information
27040-E0030 A9047 ALT9811 27050-1112AVideo/Publications
