Associated Numbers
R222-3701000 UD10970ASpecifications
| Amp | 55 A |
| Bottom Mounting Foot Width (B) | 19 mm |
| Diameter (D.1) | M10x1.25 mm |
| Diameter (D.2) | 12 mm |
| Diameter (D.3) | 12 mm |
| Length (L.1) | 184 mm |
| Mount Inside Length or Pad Mount C-C (C) | 62 mm |
| OEM Product | No |
| Plug Code | PL_9115 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Pulley Outside Diameter (O.D.1) | 48 mm |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | SOLID |
| Unit Type | UNIVERSAL |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| UAZ | 2104 | ||
| UAZ | 2105 | ||
| UAZ | 2107 |
Reference Information
UD10970A R222-3701000Video/Publications
