A9093(MANDO) - Brand new OEM MANDO Alternator

Specifications

Amp	75 A
Bottom Mounting Foot Width (B)	13 mm
Diameter (D.1)	M8x1.25 mm
Diameter (D.2)	8.5 mm
Diameter (D.3)	8.5 mm
Length (L.1)	161 mm
Mount Inside Length or Pad Mount C-C (C)	54.5 mm
OEM Product	Yes
Plug Code	PL_2004
Product Line	Premium Line
Product Type	Brand new
Pulley Grooves	4 qty
Pulley Outside Diameter (O.D.1)	60 mm
Pulley to Mount Distance (A)	35 mm
Pulley Type	SOLID
Unit Type	MANDO
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
HYUNDAI	Accent 1.3	[G4E-A]	01.2000-
HYUNDAI	Accent 1.3	[G4EH]	08.2002-
HYUNDAI	Accent 1.3	[G4EH]	10.1994-01.2000
HYUNDAI	Accent 1.5	[G4EB]	01.2000-11.2005
HYUNDAI	Accent 1.5	[G4EC-G]	09.2000-11.2005
HYUNDAI	Accent 1.5	[G4EK]	01.1998-01.2001
HYUNDAI	Accent 1.5	[G4EK]	01.2002-01.2002
HYUNDAI	Accent 1.5	[G4EK]	10.1994-01.2000
HYUNDAI	Accent 1.5	[G4EK]	10.1994-07.1999
HYUNDAI	Accent 1.5		01.1995-01.1996
HYUNDAI	Accent 1.5 GL		01.1995-01.1995
HYUNDAI	Accent 1.5 GL		01.1997-01.1997
HYUNDAI	Accent 1.5 GS		01.1997-01.1997
HYUNDAI	Accent 1.5 GT		01.1996-01.1997
HYUNDAI	Accent 1.5 L		01.1995-01.1997
HYUNDAI	Accent 1.6		01.2001-01.2001
HYUNDAI	Accent 1.6		01.2002-01.2002
HYUNDAI	Elantra 1.6	[G4ED-G]	05.2003-
HYUNDAI	Elantra 1.6	[G4ED-G]	06.2000-
HYUNDAI	Elantra 1.8	[G4BB]	06.2000-
HYUNDAI	Elantra 2.0	[G4GC]	06.2000-07.2006
HYUNDAI	Elantra 2.0	[G4GC]	10.2003-07.2006
HYUNDAI	Elantra 2.0	[G4GC-G]	06.2000-
HYUNDAI	Elantra 2.0	[G4GC-G]	06.2000-07.2006
HYUNDAI	Elantra 2.0 GLS	[G4CP]	01.2002-01.2002
HYUNDAI	Elantra 2.0 GT	[G4CP]	01.2002-
HYUNDAI	Excel 1.3	[G4DG]	01.1990-01.1995
HYUNDAI	Excel 1.5		01.1991-01.1994
HYUNDAI	Excel 1.5 CX		01.1993-01.1994
HYUNDAI	Excel 1.5 CXL		01.1992-01.1994
HYUNDAI	Excel 1.5 GL		01.1990-01.1994
HYUNDAI	Excel 1.5 GLS		01.1990-01.1991
HYUNDAI	Excel 1.5 GS		01.1992-01.1994
HYUNDAI	Excel 1.5 L		01.1991-01.1992
HYUNDAI	Lantra 1.5	[G4EK]	04.1997-
HYUNDAI	Lantra 1.5	[G4EK]	12.1996-09.2000
HYUNDAI	Lantra 1.6	[4G61]	02.1996-
HYUNDAI	Lantra 1.6	[4G61]	11.1995-09.2000
HYUNDAI	Lantra 1.6	[G4GR]	02.1996-
HYUNDAI	Lantra 1.6	[G4GR]	11.1995-09.2000
HYUNDAI	Lantra 1.8	[G4GM]	02.1996-
HYUNDAI	Lantra 1.8	[G4GM]	11.1995-09.2000
HYUNDAI	Lantra 2.0	[G4GF]	08.1996-09.2000
HYUNDAI	Lantra 2.0	[G4GF]	12.1996-
HYUNDAI	Matrix 1.8	[G4GB-G]	06.2001-
HYUNDAI	Scoupe 1.5	[G4EK-TC]	04.1991-05.1996
HYUNDAI	Scoupe 1.5		01.1993-01.1995
HYUNDAI	Scoupe 1.5 LS		01.1993-01.1993
HYUNDAI	Scoupe 1.5 LS		01.1994-01.1995
PROTON	Persona 315 1.5 GLi / GLSi	[4G15M]	03.1996-
PROTON	Persona 315 1.5 GLSi	[G15B]	09.1996-
PROTON	Persona 316 1.6	[4G92]	03.1996-
PROTON	Persona 316 1.6 GLXi	[4G92]	03.1996-
PROTON	Persona 415 1.5	[4G15]	01.1994-
PROTON	Persona 416 1.6	[4G92]	12.1995-
PROTON	Persona 416 1.6 GLXi	[4G92]	01.1994-

Reference Information

002-C964 ALC964 9.44391E+11 A2T39991 37300-22023 37300-22020 40879RI DRA3465 CAL32102AS ALT8704 UD02536A 2C964 0986042871 437336 3730022023 210282 9034 ALC354 9213014 3730022650SJ 111309 37300-22011 20110232 20193201OE DRA3438 2C338 8EL732725-001 439346 002-C338 37300-22600 JA879IR 56632 20193201RE 401126RI CAL32102GS ALC338 3730022600 002-C354 9090121 2032102 A2T39991A STX100169 ALT8734 28-1955 STX100200 STX100169R 3730022011 3730022010 13701N 2C354
