Associated Numbers
11.204.116 32008611 32008650 AAK5808 IA1211 MAHMG69 MG69 UD12123A 11204116 28V 55A MG 69 Available 11203913 AAK5771 Superseded unit see available P/N 11203441 AAK5584 11.203.913 11.203.441
11203913 11203441
JCB 320/08611, 320/08650
Lester 20722
MAHLE 11.203.441, 11.203.913, 11.204.116, AAK5584, AAK5771, AAK5808, IA1211, MG69
PIC Picture ID 282-746
65-2545-1
11203441 Mahle
11203913 Mahle
11204116 Mahle show
115899 Cargo
32008611 JCB
32008650 JCB
516506055 PSH
72735068 Mahle
AAK5584 Mahle
AAK5771 Mahle
AAK5808 Mahle show
IA1211 Mahle
IA1211SEL +line
MG69 Mahle show
Specifications
| Amp | 55 A |
| Bottom Mounting Foot Width (B) | 14.5 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | M10x1.5 mm |
| Length (L.1) | 201 mm |
| Mount Inside Length or Pad Mount C-C (C) | 77.5 mm |
| OEM Product | No |
| Plug Code | PL_9105 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 8 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 30.5 mm |
| Pulley Type | SOLID |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JCB | Engine 4.4 | ||
| JCB | Various Models |
Reference Information
11.204.116 32008650 69 UD13080A IA1211 32008611 441993 AAK5808 MAHMG69 ALT79530 MG69 MG UD12123AVideo/Publications
