Brand new AS-PL Alternator
STANDARD LINE
AS-PL
ISKRA / LETRIKA
Price:
NZ$ 258.12 including GST
NZ$ 224.45 excluding GST
or four payments of $64.53
with
Learn More
each
A9227
A9215
2
Associated Numbers
11.201.735 111036 111081 11572690 19025791 20100695 2021159 20696N 2518 2518028 2541135 28-6627 282-30102 30350RI 30350RIM 30572RI 46231657 46231659 46231660 46231675 505.017.045 505.017.055 553298RIM 55698 5999868 5999869 63320001 63320102 63321000 63321113 63321176 63321189 7713141 77305410 77347411 90-23-6523N A125-45C A13E1 A13E30 A13E50 AAK4580 ALT12105 CAL21159 CAL21159AS CAL21159ES CAL21159GS CAL21159OS CAL21159RS IA0735 LRA03517 MAHMG432 MAN342 MG432 UD13061A UNIT BOM 282-110Specifications
| Amp | 45 A |
| Bottom Mounting Foot Width (B) | 32 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 11.5 mm |
| Length (L.1) | 168 mm |
| OEM Product | No |
| Plug Code | PL_9105 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 10 mm |
| Pulley Outside Diameter (O.D.1) | 41 mm |
| Pulley Outside Diameter (O.D.2) | 65 mm |
| Pulley to Mount Distance (A) | 57.5 mm |
| Pulley Type | SOLID |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AGCO | Various Models | ||
| AUTOBIANCHI | Y10 1.0 | [156A2.246] | 10.1987-10.1995 |
| AUTOBIANCHI | Y10 1.0 4WD | [156A3.000] | 12.1986-10.1995 |
| FIAT | Panda 0.8 | [156A4.000] | 01.1986-01.1995 |
| FIAT | Panda 1.0 | [156A2.100] | 01.1986-02.1992 |
| FIAT | Panda 1.0 | [156A3.100] | 01.1986-02.1992 |
| FIAT | Panda 1.0 4x4 | [156A2.100] | 01.1986-07.1989 |
| FIAT | Panda 1.0 4x4 | [156A3.100] | 01.1986-07.1989 |
| FIAT | Panda 1.0 i.e. | [156A2.246] | 08.1992-02.2004 |
| FIAT | Tipo 1.1 Digit | [160A3.000] | 01.1988-10.1991 |
| FIAT | Uno 1.0 | [156A2.048] | 06.1986-12.1993 |
| FIAT | Uno 1.0 | [156A2.100] | 06.1986-12.1993 |
| GOLDONI | 45 SN | [LDW1603] | |
| HITTNER | 30 | [9LD625-2] | |
| HITTNER | 35 | [LDW1603] | |
| HITTNER | 40 | [LDW1603] | |
| LANCIA | Y10 1.0 Fire | [156A2.000] | 03.1985-06.1989 |
| LANCIA | Y10 1.0 Fire | [156A2.100] | 06.1985-06.1991 |
| LANCIA | Y10 1.0 Fire | [156A2.246] | 10.1987-02.1992 |
| LANCIA | Y10 1.0 Fire 4WD | [156A2.000] | 12.1987-02.1990 |
| LANCIA | Y10 1.0 Fire 4WD | [156A2.000] | 12.1987-02.1992 |
| LANCIA | Y10 1.0 Fire 4WD | [156A2.100] | 12.1986-02.1989 |
| LANCIA | Y10 1.0 Fire 4WD | [156A2.246] | 12.1987-02.1992 |
| LOMBARDINI | LDW 1204 1.3 | ||
| LOMBARDINI | LDW 1404 1.3 | ||
| LOMBARDINI | LDW 1503 | ||
| LOMBARDINI | LDW 1603 1.6 | ||
| LOMBARDINI | LDW 1603M 1.6 | ||
| LOMBARDINI | LDW 1603SD 1.6 | ||
| LOMBARDINI | LDW 2004 | ||
| LOMBARDINI | LDW 502 | ||
| LOMBARDINI | LDW 602 | ||
| LOMBARDINI | LDW 903 0.9 | ||
| STEINER | 440-34KO 1.0 | [CH904] | |
| STEINER | 440-40KO 1.0 | [CH1000] |
Reference Information
30572RI 20100695 505.017.045 46231675 111036 63321000 20696N 2541135 ALT7857 432 90-23-6523N 11.201.735 5999868 MG CAL21159RS 5999869 ALT1070 111081 210269 77305410 BOM LRA03517 63321113 UNIT ALTL274 63320102 30350RI CAL21159GS 11572690 A13E50 77347411 ED0011573600 STX100502 282-110 55698 28-6627 7713141 2518028 2518 CAL21159OS 63321189 ALT321390 A13E1 UD13061A 46231659 46231657 2021159 282-30102 30350RIM ALT2300 ALT79001 442219 11572630 5530107 505.017.055 CAL21159 CAL21159ES 63320001 46231660 63321176 MG432 CAL21159AS MAN342 A13E30 ALT12105 553298RIM MAHMG432 LRA3517 A125-45C ALTL698 19025791 A12MA0014A2 AAK4580 IA0735 11572700Video/Publications
