Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 747.47 including GST
NZ$ 649.97 excluding GST
or four payments of $186.87
with
Learn More
each
S0021
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001417065Associated Numbers
0001417065 0001417075 0986017050 101161 101161P 10962 10962P 11.139.107 112116 120-40123 1547049 18392N 19024085 19024180 1986S00063 20401056BN 20401056EL 220225 220263 260-47281 33904 45-2116 455871 6010650 811.201.123 860511GB 8642 88212547 8EA737108-001 8EA737108-021 90-15-7184 AZK5456 CS962 CST10650 CST10650AS CST10650ES CST10650GS CST10650OS CST10650RS DRS7050 DS8160 EAA-121374 IS9096 LRS01891 LRS1891 MS466 PRE860511GB SG0521 STB0962 STR50136Specifications
| Insulated Earth | Yes |
| Kilowatt | 6.6 kW |
| Length (L.1) | 407 mm |
| Mount Hole Center - Center (O.1) | 126.5 mm |
| Mount Hole Center - Center (O.2) | 126.5 mm |
| Mount Hole Center - Center (O.3) | 126.5 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | 13.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| No./Teeth (Replaces) | 12 qty |
| OEM Product | No |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VOLVO | FH 12/340 12.1 | [D12A340] | 01.1995- |
| VOLVO | FH 12/340 12.1 | [D12A340] | 08.1993- |
| VOLVO | FH 12/340 12.1 | [D12C340] | 01.1995- |
| VOLVO | FH 12/340 12.1 | [D12C340] | 08.1993- |
| VOLVO | FH 12/340 12.1 | [D12D340] | 01.1995- |
| VOLVO | FH 12/340 12.1 | [D12D340] | 08.1993- |
| VOLVO | FH 12/380 12.1 | [D12A380] | 01.1995- |
| VOLVO | FH 12/380 12.1 | [D12A380] | 03.1998-09.2003 |
| VOLVO | FH 12/380 12.1 | [D12A380] | 08.1993- |
| VOLVO | FH 12/380 12.1 | [D12A380] | 12.2001-08.2006 |
| VOLVO | FH 12/380 12.1 | [D12C380] | 01.1995- |
| VOLVO | FH 12/380 12.1 | [D12C380] | 03.1998-09.2003 |
| VOLVO | FH 12/380 12.1 | [D12C380] | 08.1993- |
| VOLVO | FH 12/380 12.1 | [D12C380] | 12.2001-08.2006 |
| VOLVO | FH 12/380 12.1 | [D12D380] | 01.1995- |
| VOLVO | FH 12/380 12.1 | [D12D380] | 03.1998-09.2003 |
| VOLVO | FH 12/380 12.1 | [D12D380] | 08.1993- |
| VOLVO | FH 12/380 12.1 | [D12D380] | 12.2001-08.2006 |
| VOLVO | FH 12/420 12.1 | [D12A340] | 08.1993- |
| VOLVO | FH 12/420 12.1 | [D12A420] | 01.1995- |
| VOLVO | FH 12/420 12.1 | [D12A420] | 05.1999-09.2003 |
| VOLVO | FH 12/420 12.1 | [D12A420] | 08.1993- |
| VOLVO | FH 12/420 12.1 | [D12A420] | 10.2003-08.2006 |
| VOLVO | FH 12/420 12.1 | [D12C420] | 01.1995- |
| VOLVO | FH 12/420 12.1 | [D12C420] | 05.1999-09.2003 |
| VOLVO | FH 12/420 12.1 | [D12C420] | 08.1993- |
| VOLVO | FH 12/420 12.1 | [D12C420] | 10.2003-08.2006 |
| VOLVO | FH 12/420 12.1 | [D12D340] | 08.1993- |
| VOLVO | FH 12/420 12.1 | [D12D420] | 01.1995- |
| VOLVO | FH 12/420 12.1 | [D12D420] | 05.1999-09.2003 |
| VOLVO | FH 12/420 12.1 | [D12D420] | 08.1993- |
| VOLVO | FH 12/420 12.1 | [D12D420] | 10.2003-08.2006 |
| VOLVO | FH 12/460 12.1 | [D12C460] | 08.1998- |
| VOLVO | FH 12/460 12.1 | [D12C460] | 10.2003-08.2006 |
| VOLVO | FH 12/460 12.1 | [D12D460] | 10.2003-08.2006 |
| VOLVO | FH 12/500 12.1 | [D12D500] | 09.2001- |
| VOLVO | FL 12/380 12.1 | [D12A380] | 09.1995-09.1998 |
| VOLVO | FL 12/420 12.1 | [D12A420] | 09.1995-09.1998 |
| VOLVO | FL 12H/380 12.1 | [D12A380] | 09.1995-09.1998 |
| VOLVO | FL 12H/420 12.1 | [D12A420] | 09.1995-09.1998 |
| VOLVO | FM 12/340 12.1 | [D12C340] | 02.2000-09.2003 |
| VOLVO | FM 12/340 12.1 | [D12D340] | 02.2000-09.2003 |
| VOLVO | FM 12/420 12.1 | [D12C420] | 03.2000-09.2003 |
| VOLVO | FM 12/420 12.1 | [D12D420] | 03.2000-09.2003 |
| VOLVO | FM 12/460 12.1 | [D12C460] | 08.1998-09.2005 |
| VOLVO | NH 12/380 12.1 | [D12C380] | 05.1999- |
| VOLVO | NH 12/420 12.1 | [D12C420] | 05.1999- |
Reference Information
455871 8112615 20401056RC 811.207.123.018 S24BH0101A2 AZK5582 20401056EL 3095060 CS962 1516824R 0001330016 VOE9003964839 811.207.123.016 811.207.123.010 0986018090 811.207.123.210 1516670R IS9096 8113918 112116 18392N 20536466 ANM19270 6010650.0 8121267 MAHMS466 PRE860511GB 6010650.3 6010650.2 8113165 81139180 STB0962 LRS01891 0986017050 45-2116 S0021 19024085 20451445 STR1314 19024180 860511GB 3964839 CST10650ES STRS590 EJD1.8/12R71 S24BH0104A2 1547049 811.207.123.311 0001417075 STR79536 1986S00063 PTC-4022 1986S00064 11.139.541 LRS1891 120-40123 8642 72492702 220225R 20401056BN CGB-11665 MS466 PRSS590 85000186 MAV126500 CST10650AS CST10650RS SG0521 DRS7050 0001417065 33904 8EA012586-601 88212547Video/Publications
