S0066 - Brand new AS-PL Starter motor

Associated Numbers

0001218172 0001218772 0001223002 01180995KZ 069911023F 0986017430 0986018290 101185 101185B 10347 111855 1180180 18230N 20401241BN 20401241OE 20401344BN 20500534 20513069 22.1185 25-2321 25-2390 28.1185 33887 35261130 436038 510.501.112 6010142 6010443 8212215 8505 8817430 8EA737793-001 AEU1185 CS1185 CST10142AS CST10142GS CST10443AS DRS7430 EAA-121223 LRS01422 RNL1829 S0066 STR22027 70-2637 70-1793 MS30 00011109370 ARROWHEAD 410-24213 BOSCH SR9972N SR9972X GEHL 133557 JANNCO 410-24013R KHD 1118-0180 LESTER 18230 MAGNETON 443-115-142-726 9142726 VOLKSWAGEN B0001109370 B0001218772 B0001223002 IMI215-11 IS1072 ATLANTIC QUALITY PARTS 1300-0102 BOMAG 05710969R 5712911 5718062 0-001-218-172 0-001-218-772 0-001-223-002 SR0803X DELCO DEUTZ 0118-0180 1180995 132299 GENIE 37950 JLG 7016332 118-0180 118-0995 LETRIKA/ISKRA LIEBHERR 5990594 6905510 6905777 LUCAS ELECTRIC LRS01457 MAHLEM S30 MS619 MALAGUTI SCHAEFF INC 5411656441 5999999774 069-911-023F VOLVO 9002904386 WEIDEMANN 5030180181 Bosch show 0001218172SEL +line 01180180 VW ruil 11017430 EuroTec 11018290 11180180 Cargo 116128 120149 PIC GHEL Lester Prestolite 230847 252321 Elstock 3045250 EAI 510501112 PSH 8817430F Friesen 91157066 Wilson Magneton 917430 EDR 917430N A17430 ATL A18290 BX218772 (USA) HC DEM501185 ADI Remy EF10347 EF10347N F042002146 HCS1185 Lucas OSM11092 Optimum SM2613 Honda STR1162sa Electrolog STR1181sa STR7989sa STRB015 Unipoint 01180995 03045250 05718062 Bomag 1000000406 Kramer 11131109 Mahle 11131951 2000808899 2913173200 Atlas 2913175500 29619120010 Same 36190 Sparex 510522112 69311 Delco 72735658 72740700 8018290 808899 8EA737793001 Hella AZE4202 AZE4535 IS91072C LRS1457 MS30SEL STR218172 Stabeco 0001223002SEL 02934505 0986018291 0986018297 1180995KZ 120149A 252390 2934505 2934631 458884 Valeo 510504112 8018290F Volvo 91157142 9142900 918290 BX223002 CS1566 DRS8290 EF10928 HCS1566 0001109370 0001109370SEL 0001109461 2934613 510521112 snb8172 BXS0175 Volkswagen 18101072 AES 443115142726 Sando 688011112 DRI CEVAM Auto Electro EVESBE1078 Dapex LRS1422 NSM1001 Napa (UK) RNL1743 RNL RNLMS30A SG0075 Ghibaudi Wood STR22027AN WOOSTR22027 WOOSTR22027AN Newman Reman Old Service Europe 0-986-018-297 Deutz Genie Parts IAT S8172 Khd 120-149 Shelhurst 510501102 STR-B015 Group SNB8172 AIM SB-00276R Amsco VS-18230 Andre Niermann 01218172 Arrowhead SBO0091 Dixie Electric Ltd S-6174 New 260-22101 CARGO Industry J&N 410-24013 410-24114 MPA X X718230 X718230N Romaine 18230-UT 18230-UTROT 41-18230 Standard Starter Drive 422209 Voltux V1-18230 WAI 2-1946-BO Whatcom 47191 91-15-7066 ZM 80.130.11

Specifications

Kilowatt	2.2 kW
Length (L.1)	261 mm
Mount Hole Center - Center (O.1)	101 mm
Mount Hole Diameter (C.1)	11 mm
Mount Hole Diameter (C.2)	11 mm
No./Mount holes	2 qty
No./Mount holes with thread	0 qty
No./Teeth	11 qty
No./Teeth (Replaces)	11 qty
OEM Product	No
Pinion at Rest (B)	23 mm
Product Line	Standard Line
Product Type	Brand new
Rotation	CW
Spigot Diameter (A)	82.5 mm
Unit Type	BOSCH
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
KHD	Engine 1.4 Diesel	[F2L1011]	01.1995-
KHD	Engine 2.0 Diesel	[F3L1011]	01.1995-
KHD	Engine 2.7 Diesel	[BF4L1011][F4L1011]	01.1995-

Reference Information

01180995KZ 28.1185M MAV121420 S12ML0667A2 0986017430 1180180 8EA737793-001 18230N 9002904386 2934631 0986018290 LRS01422 8817430 0001109370 0001218172 STR22027 STR7873 0001218772 25-2390 ANM19650X 1180995KZ 02934613 510.501.112.605 CGB-27430 RNL1829 8212215 STA0341R VOE9002908534 MS 02934631 1180995 MS30 0001223002 20500534 CST10142AS 2934505 20401344BN 33887 6010142 STRS048 AEU1185 CST10443AS 02934505 069911023F S0066 STR1181 STX200236 10347 DRS7430 111855 STX210088 101185B 5010338 220333 35261130 03045250 510.501.112 S12BH0268 510.501.112.460 510.501.112.461 2934613 11.131.951 8505 20513069 30 01180995 IS1072 LRS1422 STX200236R 22.1185 28.1185 101185 20401241OE CST10142GS S12BH0268A2 S12BH0266A2 20401241BN 25-2321 CS1185 11180180 6010443 STR1162

Video/Publications

S0066
