Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 221.12 including GST
NZ$ 192.28 excluding GST
or four payments of $55.28
with
Learn More
each
S0131
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001107005Associated Numbers
0001107005 0001107006 02B911023B 02B911023BX 0986016750 10597 11.131.178 112306 11717 20401723BN 20401723OE 22.0597 25-1312 300.519.103 33031N 3654 42016750 455979 6010327 8016750 8213006 88213006 8EA726221-001 AEY2033 AZE2640 CS597 CST10327AS CST10327GS DRS6750 EAA-121456 LRS02033 S0131 SS314 STR50431Specifications
| Kilowatt | 1.1 kW |
| Length (L.1) | 243 mm |
| Mount Hole Center - Center (O.1) | 103 mm |
| Mount Hole Center - Center (O.2) | 103 mm |
| Mount Hole Center - Center (O.3) | 107 mm |
| Mount Hole Diameter (C.1) | 9 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| Mount Hole Diameter (C.3) | 9 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 52 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | ACW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VW | Caravelle 1.8 | [J] | 12.1990-07.1992 |
| VW | Transporter 1.8 | [PD] | 12.1990-07.1992 |
| VW | Transporter 2.0 | [AAC] | 07.1990-04.2003 |
| VW | Transporter 2.0 | [AAC] | 09.1990-04.2003 |
Reference Information
AZE2640 300.519.103.395 10439979 33031N BST2540 LRS02033 717ST11 V10-12-16750 ANM18970X 2B911023F PRSF047 IR8276 2B911023B BST2138 10439978 72736040 455979 0001121010 STM1085 22.0597 0001107006 112306 4716750 0001107005 CMA-621456 300.519.103.010 F032113677 6010327.0 6010327.1 S12BH0625A2 300.519.103.018 MAV123270 88213006 3654 S0131 8EA726221-001 10597 02B911023FX AEY2033 11016750 8213006 20401723OE ST00552 460531 CS597 IS1060 VW9023 STX200160R MQS597 MS412 SS314 S512406 A16750 943241009010 11.131.178 STRF047 AC-CBS0597 331328 STR78000 STR1707 MSR1009 CST10327GS 0986016750 063720597010 311040102 944280167500 11717 103415 330749 8016750 113677 0001108097 0001108096 02B911023B STB0597 3116700 011-001-000352R 02B911023F 2B911023BX STX200160 2B911023BV MSRC597 MRS16750 LRS2033 STR50431 943205971010 DRS6750 02B911023BX 2131438 02B911023BV CST10327AS 10015211OV 42016750 25-1312 QRS1636 WG2045182 20401723BNVideo/Publications
