Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 427.70 including GST
NZ$ 371.91 excluding GST
or four payments of $106.93
with
Learn More
each
S0133
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001218155Associated Numbers
0001218010 0001218121 0001218155 0986013630 10504 11205 112125 20401111BN 20401111RC 20404351RC 22.0504 25-1216 30970R 3546 436029 46231604 5985182 6010111 6030153 63222000 63222030 63222130 7658554 77412430 8013630 8EA726152-001 AES6164 CS504 CST10111AS CST10111RS CST30153RS DRS3630 LRS00664 SS162 STR52041 VS290Specifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 272 mm |
| Mount Hole Center - Center (O.1) | 82 mm |
| Mount Hole Center - Center (O.2) | 116 mm |
| Mount Hole Center - Center (O.3) | 82 mm |
| Mount Hole Diameter (C.1) | 9 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| Mount Hole Diameter (C.3) | 9 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 23 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 81 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | Croma 1.9 TD | 01.1988-12.1996 | |
| FIAT | Regata 1.9 TD | 01.1988-12.1988 | |
| FIAT | Ritmo 1.9 TD | 01.1985-12.1987 | |
| FIAT | Tempra 1.9 TD | 01.1991-12.1993 | |
| FIAT | Tipo 1.9 TD | 01.1987-12.1988 | |
| LANCIA | Dedra 1.9 TD | ||
| LANCIA | Delta 1.9 TD | 01.1986-12.1988 | |
| LANCIA | Delta 1.9 TD | 01.1994-12.1995 | |
| LANCIA | Delta 1.9 TD | 01.1994-12.1996 | |
| LANCIA | Prisma 1.9 Diesel | 06.1984-12.1989 | |
| LANCIA | Prisma 1.9 TD | 05.1985-12.1989 |
Reference Information
MAV3250 STR52041 112125 MAV2160 76422610 VS290 0986013630 0001218010 ANM15850X LRS664 63222130 7642261 77412430 436029 25-1216 46231604 8013630 7680619 10504 7658554 8EA726152-001 60808773 5985182 AES6164 DRS3630 7642260 STR1992 7731823 STRS679 0001218155 30970R STX200521 11205 22.0504 63222030 CS504 0060808773 220122 330656 7565057 STR1888 RNL1363 STX200374 LRS00664 3546 SS162 7716195 STX200374R 0001218121 7716194 63222000Video/Publications
