Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 704.70 including GST
NZ$ 612.78 excluding GST
or four payments of $176.18
with
Learn More
each
S0137
S0194
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001241020Associated Numbers
0001241006 0001241015 0001241020 0001261007 0001261008 0001261012 0001261013 0001261044 0001261045 0001261069 0986022260 101420 101420B 101420P 101420R 114073 1667425 1688625 1739935 1826121 1843852 1876369 19741N 20401806BN 20401806OE 20401806RC 28.1420 28.1420M 31501N 45-4013 6010608 8202 88212774 8822260 CS1420 CST10608AS CST10608GS CST10608RS DRT2260 DRT2260X EAA-121210 LRS02341 M90R3544SE S0194 STR50443 STR50515Specifications
| Kilowatt | 5.5 kW |
| Length (L.1) | 321 mm |
| Mount Hole Center - Center (O.1) | 126.5 mm |
| Mount Hole Center - Center (O.2) | 126.5 mm |
| Mount Hole Center - Center (O.3) | 126.5 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | 13.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| No./Teeth (Replaces) | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 110 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BOVA | 122 12.9 | [MX300] | 10.2006- |
| BOVA | 130 12.9 | [MX340] | 07.2007- |
| BOVA | 130 12.9 | [MX375] | 07.2007- |
| BOVA | 131 12.9 | [MX340] | 07.2007- |
| BOVA | 141 12.9 | [MX340] | 07.2007- |
| BOVA | 141 12.9 | [MX375] | 07.2007- |
| DAF | CF 85.360 12.9 | [MX265] | 10.2006- |
| DAF | CF 85.380 12.6 | [XE280C] | 12.2005- |
| DAF | CF 85.410 12.9 | [MX300] | 10.2005- |
| DAF | CF 85.460 12.9 | [MX340] | 10.2005- |
| DAF | CF 85.510 12.9 | [MX375] | 10.2005- |
| DAF | FA 85.360 12.9 | [MX265] | 10.2006- |
| DAF | XF 105.410 12.9 | [MX300] | 10.2005- |
| DAF | XF 105.460 12.9 | [MX340] | 10.2005- |
| DAF | XF 105.510 12.9 | [MX375] | 10.2005- |
| DAF | XF 95.380 12.6 | [XE280C] | 12.2005- |
| DAF | XF 95.430 12.6 | [XE315C] | 12.2005- |
| SOLARIS | Vacanza 12 12.9 | [MX300] | 10.2005- |
| SOLARIS | Vacanza 13 12.9 | [MX300] | 10.2005- |
Reference Information
901.504.123.018 STR10200 901.504.123.215 STD1418R 28.1420M 331858 S0194 1956090 CST10608RS 115511 8EA738258-651 0001241020 2134698 PRSL730 114073 1688625 IS9458 0986022260 101420 901.504.123.011 CST10608AS 901.504.123.010 1739935 88212774 901.504.123.211 STR1865 0001261044 0001261045 31501N CGB-22260 MAV127140 0001261008 0001261007 45-4013 ANM24480X 220821 0001241015 943214201010 901.504.123.280 LRS02341 M90R3544SE 11.139.606 19084252 1843852 STRL730 STR50443 0001261013 1876369R 0001241006 STR1436 STM685 0001261012 101420B 20401806RC 2015153 72442834 DRT2260 CST10608GS 101420P 101420R STR50515 MS759 1667425 19741N S24BH0116 19084002 901.504.123.310 1826121 20401806OE 901.504.123.500 5110076 8202 DRT2260X 901.504.123.900 8822260 8EA012586-491 CS1420 MSRC1420 20401806BN AZF4877 28.1420 1876369 6010608.0 S24BH0116A2 6010608.2 6010608.1 LRS2341Video/Publications
