or four payments of $59.49
with
Learn More
- Associated Numbers
- Specifications
- Vehicle Applications
- Alternatives >>>
- Reference Information
- Video/Publications
Associated Numbers
0001108208 12417525293 12417536690 12417537513 17923N 25-3372 254211 AEY2201 EAA-121477 LRS02201 STR50268
PRSL802 3EFFE
STRL802 3EFFE
CGB-53372 AINDE
UD17317S AS-PL
AEY2201 AUTOELECTRO
12417525293 BMW
12417525445 BMW
12417536690 BMW
12417610344 BMW
12417610351 BMW
7525293 BMW
7536690 BMW
0001108208 BOSCHList
0001108460 BOSCHList
0986021980 BOSCH
CST10003GS CASCO
DRS0087 DELCO
DS1197 DELCO
RAS31198 DELCO
S-6258 DIXIE
EAA-121477 EAA
25-3372 ELSTOCK
11090144 EUROTEC
STB4808 KRAUF
254211 KUHNER
LRS02201 LUCAS
LRS2201 LUCAS
88214285 POWERMAX
210.526.092 PSH
20401300OE REAL
S80277N ROTOVIS
6010003.1 SANDO
MAV120030 SIOM
458828 VALEO
17923N WAI / TRANSPO
BOS0001108460 WOODAUTO
STR50268 WOODAUTO
WRM10003OE WROOM
snb0072 70-1304 bxs0161
0001108208 Bosch show
0001108209 Bosch show
0001108460 Bosch show
0001108461 Bosch show
0986021157 Bosch ruil
0986021980 Bosch ruil
11090144 EuroTec
1206169 PIC
12160 EAI
12417525293 BMW show
12417525445 BMW
12417536690 BMW show
12417610344 BMW
12417610351 BMW show
17923 Lester
210526092 PSH
253372 Elstock
3186 CEVAM
7525293
7536690
8080277F Friesen
910087 EDR
DRS0087 Remy
LRS02201 Lucas
SR0809N Bosch (USA)
SR0809X Bosch (USA)
Bosch SR0809N
Wilson 91-15-7222
References:
BMW 12-41-7-525-293, 12-41-7-536-690, 12-41-7-537-513
Bosch 0001108208, SR0809N, SR0809X
Lester 17923
PIC Picture ID 120-6169
Wilson 91-15-7222
410-24117
Bosch 0001108208
Wilson 91-15-7222
References:
J&N 410-24117
Bosch 0001108208
Specifications
| Kilowatt | 1.7 kW |
| Length (L.1) | 236 mm |
| Mount Hole Center - Center (O.1) | 101 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 21 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BMW | 545 4.4 i | (E60)[M62B44] | 01.2003-12.2005 |
| BMW | 545 4.4 i | (E61)[M62B44] | 01.2003-12.2005 |
| BMW | 550 4.8 i | (E60)[N62B48B] | 01.2005- |
| BMW | 550 4.8 i | (E61)[N62B48B] | 01.2005- |
| BMW | 645 4.4 Ci | (E63)[M62B44] | 01.2004-12.2005 |
| BMW | 645 4.4 Ci | (E64)[M62B44] | 01.2004-12.2005 |
| BMW | 650 4.8 i | (E63)[N62B48B] | 01.2005- |
| BMW | 650 4.8 i | (E64)[N62B48B] | 01.2005- |
| BMW | 750 5.0 i | (E65)[N62B48B] | 01.2005- |
| BMW | X5 4.4 i | (E53)[N62B44] | 01.2003- |
| BMW | X5 4.8 i | (E53)[N62B48A] | 01.2004-12.2006 |
| BMW | X5 4.8 i | (E70)[N62B48A] | 01.2007- |
| BMW | X5 4.8 xDrive 48 i | (E70)[N62B48B] | 01.2008- |
Alternatives >>>
0001108460 - OEM Bosch Version
Reference Information
88214285 CST10003AS 5010475 315026092 CMA-621477 438538 S0391 458828 10010003AV STX210268 12417525445 160ST21 10439616 7610344 210.526.092.280 12417536690 H5010475 V20-12-08208 6010003.1 7536690 12160 20401300OE AZMT-53-010-1568 11090144 0001108461 WRM10003OE 0001108460 S-6258 1986S00711 12417525293 254211 7525445 DRS0087 49387 SBO003 STB4808 CST10003GS QRS2388 0986021980 LRS2201 20401300BN ST01414 BOS0001108460 A77770 STX210268R CGB-53372 17923N AEY2201 EAA-121477 7525293 3186 828100701 MAV120030 S12BH0606A2 3115138 8080277 3115139 12417610344 3115136 10010003OV 0001108209 STRL802 0001108208 254211B 0986021157 105588 UD17317S STR10317 331942 PRSL802 12417610351 828104101 LRS02201 RAS31198 STR50268 7610351 S80277N BM9031 210.526.092.215 6010003 STR1681 210.526.092.212 210.526.092.211 TT16315 DS1197 25-3372 210.526.092.010Video/Publications
