Associated Numbers
0001121003 17758N 20401983BN 20401983OE 25-3124 254372 254372B 6010389 98660410400 AEY1604 CST10389AS CST10389GS EAA-121476 LRS01604 SS638 STR50494 Bosch show 0986020210 ruil 11090017 EuroTec 115942 Cargo 120374 PIC 12127 EAI 17758 Lester 253124 Elstock 458535 Valeo 480505092 PSH 8080099F Friesen 91157130 Wilson A29950 ATL DRS0075 Remy Lucas STR1330sa Electrolog SR0431X 91-15-7130 References: Arrowhead SBO0128 Picture ID 120-374 &N 410-24120 BSR0431X J&N S7285 Porsche SBN052Specifications
| Kilowatt | 1.1 kW |
| Length (L.1) | 211 mm |
| Mount Hole Center - Center (O.1) | 112 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 52.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| PORSCHE | Boxster 2.5 | [M96.20] | 01.1996-12.1999 |
| PORSCHE | Boxster 2.7 | [M96.22] | |
| PORSCHE | Boxster 2.7 | [M96.23] | 01.2002-12.2004 |
| PORSCHE | Boxster 3.2 | [M96.24] | |
| PORSCHE | Boxster 3.2 S | [M96.21] |
Alternatives >>>
S0289 - 1.7kW version, Slightly longer (233mm overall length)
Reference Information
20401983OE SS638 17758N STR1330 254372 98660410400 115942 331210 CST10389AS AEY1604 EAA-121476 25-3124 CST10389GS STRF040 254372B 986604104X STR50494 LRS1604 20401983BN 6010389 LRS01604 0001121003 S0400Video/Publications
