Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 263.73 including GST
NZ$ 229.33 excluding GST
or four payments of $65.93
with
Learn More
each
S0530
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001107060Associated Numbers
0001107060 11.131.233 113480 18940N-IK 20401081OE 254195 254195B 5840203 6010180 690.514.092 AZE2642 CST10180 CST10180AS CST10180ES CST10180GS CST10180OS CST10180RS EAA-151736 IS1079 MAHMS413 MS413 UD12001SSpecifications
| Kilowatt | 1.1 kW |
| Length (L.1) | 208 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 27.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LOMBARDINI | Engine | ||
| RUGGERINI | Engine |
Reference Information
AZE2642 MAV121800 5010531 254195 0001107060 MAHMS413 18940N-IK 690.514.092 IS1079 UD12001S MS413 STRS610 CST10180RS 413 20401081OE 11.131.233 5840203 STR1470 S0530 113480 CST10180GS CST10180ES MS CST10180AS 6010180 CST10180 S12BH0722A2 254195B CST10180OS 220909 STR79148Video/Publications
