Associated Numbers
0001108237 UD16898S 0001108238 115996 CST10495GS 3179 S-6265 12335 25-4133 STB8237 255536 LRS02461 88214524 200.529.092 20401594OE 6010495.1 07C911023G 07C911023GX 07C911023H 07C911023HX 19004N BOS0001108237 STR50669
UD16898S AS-PL
0001108237 BOSCHList
0001108238 BOSCHList
115996 CARGO
CST10495GS CASCO
3179 CEVAM
S-6265 DIXIE
12335 EAI
25-4133 ELSTOCK
STB8237 KRAUF
255536 KUHNER
LRS02461 LUCAS
88214524 POWERMAX
200.529.092 PSH
20401594OE REAL
6010495.1 SANDO
07C911023G VW
07C911023GX VW
07C911023H VW
07C911023HX VW
19004N WAI / TRANSPO
BOS0001108237 WOODAUTO
STR50669 WOODAUTO
UD802871(BOSCH)S AS-PL
0001108237 BOSCHList
0001108238 BOSCHList
115996 CARGO
CST10495GS CASCO
3179 CEVAM
S-6265 DIXIE
12335 EAI
25-4133 ELSTOCK
STB8237 KRAUF
255536 KUHNER
LRS02461 LUCAS
88214524 POWERMAX
200.529.092 PSH
20401594OE REAL
6010495.1 SANDO
07C911023G VW
07C911023GX VW
07C911023H VW
07C911023HX VW
19004N WAI / TRANSPO
BOS0001108237 WOODAUTO
STR50669 WOODAUTO
Arrowhead SBO0228
Bosch 0001108228, 0001108229, 0001108237, 0001108238, SR0820X
Lester 19003, 19004
Lucas LRS02202, LRS02461
PIC Picture ID 120-6323, 120-6324
Volkswagen 07C911-023G, 07C911-023H, 07C911-023HX, 07C911023F
Wilson 91-15-7270, 91-15-7271
0001108237 Bosch
0001108238 Bosch
07C911023G VW
07C911023H VW
11090271 EuroTec
1206324 PIC
12335 EAI
19004 Lester
200529092 PSH
254133 Elstock
LRS02461 Lucas
Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 225 mm |
| Mount Hole Center - Center (O.1) | 115 mm |
| Mount Hole Center - Center (O.2) | 16 mm |
| Mount Hole Center - Center (O.3) | 121 mm |
| Mount Hole Diameter (C.1) | 12.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 4 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 23 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A6 2.0 TDi | [BVG] | 09.2005-06.2006 |
| AUDI | A6 2.0 TDi | [BVG] | 09.2005-06.2006 |
| AUDI | A8 6.0 W12 Quattro | [BHT] | 12.2003-07.2010 |
| AUDI | A8 6.0 W12 Quattro | [BSB] | 12.2003-07.2010 |
| AUDI | A8 6.0 W12 Quattro | [BTE] | 12.2003-07.2010 |
| AUDI | Q7 4.2 FSi Quattro | [BAR] | 03.2006-05.2010 |
| AUDI | RS6 5.0 Quattro | [BUH] | 04.2008-08.2010 |
| AUDI | RS6 5.0 Quattro | [BUH] | 09.2008-08.2010 |
| AUDI | S6 5.2 Quattro | [BXA] | 03.2006-03.2011 |
| AUDI | S6 5.2 Quattro | [BXA] | 03.2006-08.2011 |
| AUDI | S8 5.2 Quattro | [BSM] | 06.2006-07.2010 |
| VW | Touareg 4.2 V8 FSi | [CGNA] | 01.2011-03.2018 |
Reference Information
0001108238 0001108237 200.529.092.280 STX210262R STRF954 AEY2461 STX210262 115996 F032115996 255536 06-10223-SX 19004N SBO495 BOS0001108237 25-4133 106838 311260092 STR10371 CST10495GS 200.529.092.211 200.529.092.010 331251 S12BH0599 LRS02461 TT16816 20401594OE AC-CBS5926 6010495.1 335ST21 H5010468 10438308 11090271 UD16898S 3114722 255536B 3114723 200.529.092.018 MAV124950 IR9633 2S0506 3179 91-15-7271 07C911023GX 12335 VW9112 V10-12-08237 25-4133CT 07C911023G 07C911023H STB8237 5010468 10010495OV ST01648 1986S00698 STR50669 LRS2461 07C911023HX 88214524 S12BH0599A2Video/Publications
