Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 229.68 including GST
NZ$ 199.72 excluding GST
or four payments of $57.42
with
Learn More
each
S0554
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001107009Associated Numbers
0001107009 0001113004 0001208233 0986015560 100.002.092 100.504.092 10131 10687 20401791RC 220153 25-2016 3605 547199 6010197 60537529 60562974 605629740 60875800 8EA725983-001 8EA730203-001 943251273010 944280155600 AES2133 CST10197 CST10197AS CST10197ES CST10197GS CST10197OS CST10197RS DRS4880 DRS5560 EAA-141257 EAA-151027 LRS00233 MSR901 SS506 UD12324SSpecifications
| Kilowatt | 1.1 kW |
| Length (L.1) | 220 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 28 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ALFA ROMEO | 145 1.6 | [AR33201] | 01.1994-12.1996 |
| ALFA ROMEO | 145 1.7 16V | [AR33401] | 01.1994-12.1996 |
| ALFA ROMEO | 146 1.6 | [AR33201] | 01.1995-12.1996 |
| ALFA ROMEO | 146 1.7 16V | [AR33401] | 01.1994-12.1996 |
| ALFA ROMEO | 33 1.2 | [AR30585] | 06.1983-12.1989 |
| ALFA ROMEO | 33 1.3 i.e. | [AR30753] | 01.1991-12.1994 |
| ALFA ROMEO | 33 1.5 | [AR30734] | 01.1990-04.1993 |
| ALFA ROMEO | 33 1.7 i.e. 16V | [AR30746] | 01.1990-12.1994 |
| ALFA ROMEO | 33 1.7 i.e. 16V | [AR30747] | 01.1990-12.1994 |
| ALFA ROMEO | 33 1.8 TD | [VM96A] | 07.1990-09.1994 |
| ALFA ROMEO | Alfasud Giardinetta 1.3 | [AR30180] | 01.1978-07.1979 |
| ALFA ROMEO | Alfasud Sprint 1.3 | [AR30184] | 09.1976-12.1981 |
| ALFA ROMEO | Alfasud Sprint 1.4 | [AR30164] | 05.1978-02.1980 |
| ALFA ROMEO | Alfasud Sprint 1.4 | [AR30168] | 07.1979-12.1989 |
| ALFA ROMEO | Alfasud Sprint 1.5 Veloce | [AR30146] | 01.1980-12.1987 |
| ALFA ROMEO | Alfasud Sprint 1.7 | [AR30550] | 03.1987-12.1989 |
| ALFA ROMEO | Alfasud Sprint 1.7 i.e. | [AR30558] | 10.1987-12.1989 |
| ALFA ROMEO | Arna 1.2 | [AR30500] | 01.1985-12.1986 |
| ALFA ROMEO | Arna 1.2 | [AR31000] | 01.1985-12.1986 |
| ALFA ROMEO | Arna 1.2 | [AR31002] | 03.1986-12.1986 |
| ALFA ROMEO | Arna 1.3 TI | [AR30168] | 03.1983-12.1986 |
| ALFA ROMEO | Arna 1.3 TI | [AR31010] | 01.1985-12.1986 |
| ALFA ROMEO | Arna 1.5 | [AR30182] |
Reference Information
605629740 CST10197OS 60875800 CST10197ES 0001113004 CST10197GS 100.504.092 CST10197AS STRS172 944280155600 UD12324S 100.002.092 LRS00233 AES2133 MSR901 6010197 60562974 ALT136060 ANM17780X 25-2016 CST10197 10131 8EA730203-001 STR10175 DRS5560 330839 SS506 STR1467 8EA725983-001 0986015560 MAV121970 0001208233 STRS702 330283 943251273010 220153 MAV321300 0001107009 20401791RC 547199 60537529 DRS4880 10687 3605 CST10197RS LRS233Video/Publications
