Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 320.28 including GST
NZ$ 278.50 excluding GST
or four payments of $80.07
with
Learn More
each
S0770S
No stock in NZ
No stock in NZ
Associated Numbers
0001170625 0001170628 0001170629 12398 20401365 20401365OE 220997 23300-00Q2C 23300-4868R 23300-7689R 23300-9323R 25-5092 255438B 255438R 255438V 30535-OS 3283 570.576.123 6010563.1 88214637 CST10563GS LRS03929 STM1401 UD90366SSpecifications
| Kilowatt | 1.7 kW |
| Length (L.1) | 199 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 1 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 64 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DACIA | Dokker 1.5 DCi | [K9K612] | 01.2012- |
| DACIA | Duster 1.5 DCi | [K9K?] | 01.2010- |
| DACIA | Duster 1.5 DCi 90 | [K9K?] | 01.2017- |
| DACIA | Lodgy 1.5 DCi | [K9K?] | 01.2012- |
| DACIA | Logan 1.5 DCi | [K9K?] | 01.2012- |
| DACIA | Logan MCV 1.5 DCi | [K9K612] | 01.2013- |
| DACIA | Sandero 1.5 DCi | [K9K?] | 01.2012- |
| NISSAN | Pulsar 1.5 DCi | [K9K..] | 01.2014- |
| NISSAN | Qashqai 1.5 DCi | [K9K636] | 01.2014- |
| RENAULT | Captur 1.5 DCi | [K9K?] | 01.2013- |
| RENAULT | Clio 1.5 DCi | [K9K608] | 01.2013- |
| RENAULT | Clio 1.5 DCi | [K9K612] | 01.2013- |
| RENAULT | Clio 1.5 DCi | [K9K618] | 01.2013- |
| RENAULT | Clio 1.5 DCi Grandtour | [K9K608] | 01.2013- |
| RENAULT | Clio 1.5 DCi Grandtour | [K9K612] | 01.2013- |
| RENAULT | Clio 1.5 DCi Grandtour | [K9K618] | 01.2013- |
| RENAULT | Dokker 1.5 DCi | [K9K612] | 01.2013- |
| RENAULT | Fluence 1.5 DCi | [K9K?] | 01.2010- |
| RENAULT | Grand Scenic 1.5 DCi | [K9K?] | 01.2014- |
| RENAULT | Grand Scenic 1.5 DCi | [K9K646] | 01.2016- |
| RENAULT | Grand Scenic 1.5 DCi | [K9K647] | 01.2016- |
| RENAULT | Kadjar 1.5 DCi | [K9K?] | 01.2015- |
| RENAULT | Kangoo 1.5 DCi | [K9K?] | 01.2014- |
| RENAULT | Logan 1.5 DCi | 01.2013- | |
| RENAULT | Megane 1.5 DCi | [K9K?] | 01.2014- |
| RENAULT | Megane 1.5 DCi | [K9K?] | 01.2015- |
| RENAULT | Sandero 1.5 DCi Stepway | [K9K?] | 01.2013- |
| RENAULT | Scenic 1.5 DCi | [K9K?] | 01.2014- |
| RENAULT | Scenic 1.5 DCi | [K9K646] | 01.2016- |
| RENAULT | Scenic 1.5 DCi | [K9K647] | 01.2016- |
| RENAULT | Talisman 1.5 DCi | [K9K646] | 01.2015- |
| RENAULT | Talisman 1.5 DCi | [K9K647] | 01.2015- |
| RENAULT | Talisman 1.5 DCi Grandtour | [K9K646] | 01.2016- |
| RENAULT | Talisman 1.5 DCi Grandtour | [K9K647] | 01.2016- |
Reference Information
11041004 LRS03929 CST10563AS UD90366S 23300-0379R 23300-7689R 23300-9323R VAL438319 3121836 3283 10010563AV 5010352 220997 DRS1107 S12BH0120 RNL170629 88214637 6010563.1 SG2138 12398 H5010352G STB7604 23300-6508R 108814 WG2226319 S0770S STM1401 STR10374 TR9089 8EA011612-441 570.594.122.282 MQS6375 570.594.122.281 0001170629 330069112 20401365OE RSM14-11 570.594.122.000 398ST21 0001170628 0001170625 0001170624 CST10563GS 23300-8223R 116367 SBO563 23300-00Q2H QRS2542 DRS1051 20401365BN AEX1207 H5010352 255438R 23300-4868R 255438V 25-5092 10438190 101573 LRS3929 570.594.122.010 570.594.122.211 23300-4868C 10010563OV 063725624010 S12BH0120A2 570.594.122.500 STRE450 331306 AC-CBS5983 30535-OS STR50828 PRSE450 570.594.122.460 0001170605 570.594.122.461 4739002 0001170604 255438B A92680 CGB-21107 UD19700S WOOSTR50828 ST02056 S-50828 63726375010 6010563Video/Publications
