Associated Numbers
20460111 220545 230.504.102 25-3437 31100-86Z00 31100-86Z01 6046111 8000225 8000307 96473783 96647521 96843581 CST46111 CST46111AS CST46111ES CST46111GS CST46111OS CST46111RS DRS0487 LRS02266 PXPSC-011 STD0216 STR80197 UD02080S
20460111 220545 230.504.102 25-3437 31100-86Z00 31100-86Z01 6046111 8000225 8000307 96473783 96647521 96843581 CST46111 CST46111AS CST46111ES CST46111GS CST46111OS CST46111RS DRS0487 LRS02266 S1100S STD0216 STR80197 UD15027S
114503 Cargo
230504102 PSH
253437 Elstock
647004102 DRI
8000225 Remy
8000307 Remy
96294039 Chevrolet
96473783 Daewoo
96647521 Delphi
96843581 Daewoo
DRS0487 Remy
F042S0H110 Bosch
F042S0H110HBC Bosch
LRS02266 Lucas
STRH110 Unipoint
trs150 TWA
snd044gq snd044 70-6214-2
WAI Old 6751R
ACE Zorkos CM6751N
Alltech 104-6751
American Power Systems APS6751
Armature G Roy 6751
Atelier Dynamo S6751
Beck Arnley Remanufactured 187-0844
Bepco 80-6751
EGI S-6751
Excel 21422
GM 96473783
Lester 6751
Metron 6751
MFR Series - Family Type PG170
Mondial 70-406-670
Nastra 6751
Nastra New 886751
Our Part Number 6751R
Part # 6751
PASCO S-5006067
Power Select 6751R
Powerite Automotive 6751
Precision Parts & Remanufacturing SKS510
Quality Rebuilders 6751
Raw Power 6751R
Rayloc 2465167
Road Warrior 6751R
Rotex 6751
Stratoline 80-6751
Suzuki 31100-86Z00, 31100-86Z01
Techno CVC AME-6751
TSA 6751N
UCP Remanufactured 6751
USA Industries 6751
Zorko 6751
Specifications
| Kilowatt | 1.5 kW |
| Length (L.1) | 210 mm |
| Mount Hole Center - Center (O.1) | 116.5 mm |
| Mount Hole Diameter (C.1) | M12x1.75 mm |
| Mount Hole Diameter (C.2) | 11.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| OEM Product | Yes |
| Pinion at Rest (B) | 19 mm |
| Product Line | Premium Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82.5 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | Epica 2.0 | [C20SED] | 01.2005- |
| CHEVROLET | Epica 2.0 | [T20SED] | 01.2005- |
| CHEVROLET | Epica 2.0 | [X20D1] | 01.2005- |
| CHEVROLET | Epica 2.5 24V V6 | [X25D1] | 01.2005- |
| SUZUKI | Verona 2.5 | 01.2004-12.2006 |
Reference Information
3130209 STR80197 8000307 96843581 230.504.102 96294039 CST46111 STR2108 20460111 CST46111RS UD02080S MT130209 CST46111AS CST46111ES CST46111GS 220545 CST46111OS 96473783 DRS0487 25-3437 LRS02266 003-130209 31100-86Z00 96647521 31100-86Z01 6046111 STD0216 8000225 LRS2266 PXPSC-011Video/Publications
