Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 512.84 including GST
NZ$ 445.95 excluding GST
or four payments of $128.21
with
Learn More
each
S1188S
No stock in NZ
No stock in NZ
Associated Numbers
1107557 1107582 12301332 1998337 UD16525S 110472 CST60108AS CST60108GS CST60147AS 8536 DRZ5125 DZ6235 EAA-111408 33626 25-1223 US835 135125 136125 3001265 3001265R 3004684R 3042511 3137440 326460 345433 60835 LRS01188 23450A 88213182 640.011.103 20409741BN 20409801BN 20409801OE 140-27105 120-30168 6060108.0 6060108.1 6060147.0 4398N 4398R 91-01-4054 91-01-4054N STR80172 STR50582Specifications
| Kilowatt | 3 kW |
| Length (L.1) | 345 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
| Wet Clutch | Yes |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYSTER | H-110 3.9 | [4.236] | 01.1972-12.1977 |
| HYSTER | H-130 3.9 | [4.236] | 01.1972-12.1977 |
| HYSTER | H30 | [4.203] | 01.1971-12.1978 |
| HYSTER | H40 | [4.203] | 01.1971-12.1978 |
| HYSTER | H50 | [4.203] | 01.1971-12.1978 |
| HYSTER | H60 | [4.203] | 12.1978- |
| HYSTER | H70 | [4.203] | 12.1978- |
| HYSTER | H80 | [4.203] | 12.1978- |
| HYSTER | H90 | [4.203] | 12.1978- |
| HYSTER | S100 | [4.203] | 12.1976- |
| HYSTER | S60 | [4.203] | 12.1976- |
| HYSTER | S70 | [4.203] | 12.1976- |
| HYSTER | S80 | [4.203] | 12.1976- |
Reference Information
4398R LRS1188 EAA-111408 4398N 1107582 135125 STR80172 CST60147AS 6060147 DRZ5125 3137440 STRW194 91-01-4054 3001265 140-27105 UD16525S 25-1223 91-01-4054N LRS01188 110472 20409741BN 345433 640.011.103 3042511 1998337 DZ6235 STR2610 STR10315 8EA730313-001 3004684R 136125 3001265R US835 23450A 12301332 88213182 338985 60835 326460 1998331 33626 1107557 PRSW194Video/Publications
