Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
HITACHI
Price:
NZ$ 223.51 including GST
NZ$ 194.36 excluding GST
or four payments of $55.88
with
Learn More
each
S2002
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
S114808Associated Numbers
0986018331 11.139.409 111690 11811 1202157 18328N 201091 201091H 20445001BN 20445001OE 20510131 22.0753 22.1091 25-2190 42114808 438178 455940 6020100 8080018 8213339 88213339 8971502040 8971502041 8971502042 8EA011610-611 8EA737424-001 944280800180 97150204 9741 AES1231 AZD3517 CST20100 CST20100AS CST20100ES CST20100GS CST20100OS CST20100RS DRS3484 DRS3484N EAA-121088 IS9317 JS1091 LES0102 LRT00131 RNLS114-808 S114-808 S114-808A S114-808B S114-808C S114-808D S2002 SS421 STR3056 16-326Specifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 193 mm |
| Mount Hole Center - Center (O.1) | 119 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | M12x1.75 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 19.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 78 mm |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| OPEL | Astra F 1.7 TDS | [17DT(TC4EE1)] | 12.1991-01.1998 |
| OPEL | Astra F 1.7 TDS | [17DT(TC4EE1)] | 12.1991-03.1996 |
| OPEL | Astra F 1.7 TDS | [X17DT(TC4EE1)] | 04.1996-02.1998 |
| OPEL | Corsa A 1.5 TD | [15DT(T4EC1)] | 03.1988-03.1993 |
| OPEL | Kadett E 1.5 TD | [15DT(T4EC1)] | 07.1988-08.1991 |
| OPEL | Vectra A 1.7 TD | [17DT(TC4EE1)] | 03.1990-08.1995 |
| OPEL | Vectra A 1.7 TD | [X17DT(TC4EE1)] | 03.1990-08.1995 |
| OPEL | Vectra B 1.7 TD | [X17DT(TC4EE1)] | 09.1995-09.1998 |
| VAUXHALL | Astra F 1.7 TD | [17DT(TC4EE1)] | 12.1991-02.1998 |
| VAUXHALL | Astra MK III 1.7 TD | [17DT(TC4EE1)] | 09.1988-02.1998 |
| VAUXHALL | Cavalier 1.7 TD | [17DT(TC4EE1)] | 09.1988-11.1995 |
| VAUXHALL | Nova 1.5 TD | [15DT(T4EC1)] | 01.1990-02.1993 |
| VAUXHALL | Nova A 1.5 TD | [15DT(T4EC1)] | 01.1990-03.1993 |
| VAUXHALL | Vectra B 1.7 TD | [X17DT(TC4EE1)] | 10.1995-11.1996 |
Reference Information
944280800180 9741 136935 CST20100ES 22.1091 2506935 1202173 18328N 8080018 201091H 25-2190 DRS3484 8EA737424-001 STX200113R 455940 8EA011610-611 3U955 STR79650 STR3049 20510131 MS 0986018331 20445001OE 6020100 LRT00131 SS421 JS1091 AES1231 STX200009R 11.139.409 42114808 128 09512152 STX200152 201091 S2002 22.0753 STX200113 438178 88213339 20445001BN 8213339 S114-808C S114-808B S114-808A CST20100OS MAV5090 R1040031 CST20100 2172 90371773 1202157 CST20100GS STX200006R IS9317 STRL088 STR3056 STX200009 S114-808D 8971502040 09163638 8971502041 8971502042 STX200006 CST20100RS SX MTU955 S12HT0531A2 220046 AZD3517 1202963 97150204 11811 RNLS114-808 003-U955 CGB-23009 DRS3484N CST20100AS S114-808 111690 MAV371220 LES0102 STA0036RVideo/Publications
